Characteristic analysis of ionosphere TEC at Wuhan station during 23rd solar cycle
-
摘要: 利用武汉站(30.5°N, 114.4°E)1997年1月1日至2007年12月31日电离层TEC、太阳黑子数及地磁指数等资料, 分析了第23周武汉站TEC的周日变化、季节变化、半年变化以及与太阳活动的相关性等特征; 以2006年4月13-17日发生的磁暴为例, 讨论了武汉站TEC对磁暴的响应以及可能的机理. 结果表明,武汉站电离层TEC在太阳活动高、低年均呈典型的周日变化特征; 冬季异常和半年异常特征明显, 且受太阳活动强弱影响; TEC和太阳黑子数年均值相关系数为0.9611; TEC对磁暴的响应可能是由磁层穿透电场和中性风共同作用导致的, 具体影响机制有待深入研究.Abstract: By using Total Electron Content (TEC) at Wuhan station (30.5°N, 114.4°E), sunspot numbers and geomagnetic index from 1997 to 2007, some typical characters such as diurnal variation, seasonal variation, and semiannual variation, correlation with solar activity were analyzed. A case study was made on the responses and possible mechanism of ionosphere TEC to the magnetic storm during 13-17 April 2006. Analysis results show that diurnal variation exists constantly in high and low solar activity. Some features like semiannual anomaly and winter anomaly in TEC had been reported, but changed with solar activity. The correlation coefficient for yearly sunspot number with TEC is 0.9611. TEC correlates with the geomagnetic AE well. The response of TEC to geomagnetic storm may be caused by penetrating electric fields and neutral winds, and the specific mechanism needed to be analyzed in the future.
-
Key words:
- Ionospheric TEC /
- Semiannual anomaly /
- Winter anomaly /
- Geomagnetic storm
-
[1] Yu You, Wan Weixing, Liu Libo, et al. A global ionospheric TEC perturbation index[J]. Chin. J. Geophys., 2009, 52(9):2189-2194. In Chinese (余优, 万卫星, 刘立波, 等. 全球电离层TEC起伏特征分析[J]. 地球物理学报, 2009, 52(9):2189-2194) [2] Aitchison G J, Weekes K. Some deductions of ionospheric information from the observations of emissions from satellite 1957 a2-I: The theory of the analysis[J]. J. Atmos. Terr. Phys., 1959, 14(3/4):236-243 [3] Weekes K. The ionosphere and the radio emission from the satellites[J]. Proc. Royal Soc. London. Math. Phys. Sci.: Ser. A, 1958, 248(1252):77-80 [4] Gulyaeva T L. Regional analytical model of ionospheric total electron content: monthly mean and standard deviation[J]. Radio Sci., 1999, 34(6):1507-1512 [5] Chen Yanhong, Wan Weixing, Liu Libo, et al. A statistical TEC model based on the observation at Wuhan ionospheric observatory[J]. Chin. J. Space Sci., 2002, 22(1):27-35. In Chinese (陈艳红, 万卫星, 刘立波, 等. 空间科学 学报, 2002, 22(1):27-35) [6] Mao Tian, Wan Weixing, Liu Libo, et al. An EOF- based empirical model of TEC over Wuhan[J]. Chin. J. Geophys., 2005, 48(4):751-758. In Chinese (毛田, 万卫星, 刘立波. 用经验正交函数构造武汉地区电子浓度总含量的 经验模式[J]. 地球物理学报, 2005, 48(4):751-758) [7] Yu Tao, Wan Weixing, Liu Libo, et al. Using IGS data to analyse the global TEC annual and semiannual variation[J]. Chin. J. Geophys., 2006, 49(4):943-949. In Chinese (余涛, 万卫星, 刘立波, 等. 利用IGS数据分析全球TEC的周年 和半年变化特性[J]. 地球物理学报, 2006, 49(4):943-949) [8] Meng Yang, An Jiachun, Wang Zemin, et al. Research on characteristic of TEC at Antarctic Zhongshan station based on GPS[J]. J. Geod. Geodyn., 2010, 30(1):43-47. In Chinese (孟泱, 安家春, 王泽民, 等. 基于GPS的南极中山站电离层TEC特 征研究[J]. 大地测量与地球动力学, 2010, 30(1):43-47) [9] Shweta Mukherjee, Shivalika Sarkar, Purohit P K, et al. Seasonal variation of total electron content at crest of equatorial anomaly station during low solar activity condition [J]. Adv. Space Res., 2010, 46:291-295 [10] Wu C C, Fry C D, Liu J Y, et al. Annual TEC variation in the equatorial anomaly region during solar minimum: September 1996-August 1997[J]. J Atmos. Terr. Phys., 2004, 66(3/4):199-207 [11] Krankowsky D, Kasprzak W T, Nier A O. Mass spectrometric studies of the composition of the lower thermosphere during summer 1967[J]. J. Geophys. Res., 1968, 73(23):7291-7306 [12] Zhu Zhengping, Ning Baiqi, Wan Weixing, Zhao Biqiang, Wang Min. An investigation of ionospheric responses during the magnetic storm of 13-17 April 2006 at Western Pacific area[J]. Chin. J. Geophys., 2007, 50(4):957-968. In Chinese (朱正平, 宁百齐, 万卫星, 赵必强, 王敏. 2006年4月13-17日西 太平洋地区电离层暴时特性研究[J]. 地球物理学报, 2007, 50(4):957-968)
