双级螺旋式重复折展锁解太阳翼设计与展开特性分析

胡明; 袁伟东; 陈文华; 孔菲; 钱萍; 陈昌足

doi:10.11728/cjss2013.01.108

双级螺旋式重复折展锁解太阳翼设计与展开特性分析

doi: 10.11728/cjss2013.01.108

浙江理工大学机电产品可靠性技术研究浙江省重点实验室杭州 310018

基金项目: 国家自然科学基金重点项目(50935002);浙江省自然科学基金重点项目(LZ12E05004);2011年度省级公益性技术应用研究计划项目(2011C31G2060082);2010年度省级公益性技术应用研究计划项目(2101C31076)和2011浙江省重点科技创新团队项目(2010R50005)共同资助

详细信息

中图分类号: V423.6,TH132.1
计量
- 文章访问数: 2196
- HTML全文浏览量: 83
- PDF下载量: 2429
- 被引次数: 0
出版历程
- 收稿日期: 2011-11-22
- 修回日期: 2012-09-16
- 刊出日期: 2013-01-15

Design and deploying characteristics analysis on two-stage helical repeated fold-unfold and lock-unlock solar wing

Zhejiang Province's Key Laboratory for Reliability Technology of Mechanical & Electrical Products, Zhejiang Sci-Tech University, Hangzhou 310018

摘要

摘要: 提出了双级螺旋式重复折展锁解太阳翼, 通过分析其工作原理, 根据双级螺旋式重复折展锁解太阳翼设计需求, 完成了其功能分析以及技术参数和结构尺寸的确定. 通过双级螺旋式重复折展锁解太阳翼展开特性分析, 研究了重复折展锁解太阳翼运动传递关系, 建立了其展开运动特性分析模型, 包括正运动学和逆运动学模型. 利用仿真求解计算获取获得了太阳翼各基板展开的同步度与平面度值. 仿真结果表明, 所提出的双级螺旋式重复折展锁解太阳翼满足设计指标要求, 为其进一步研究提供了重要理论依据.
- 太阳翼 /
- 双级螺旋机构 /
- 重复折展锁解 /
- 展开运动学
Abstract: Two-stage helical repeated fold-unfold and lock-unlock solar wing is designed. Its function analysis is conducted. Firstly, its working principle is analyzed. Based on the requirement of two-stage helical repeated fold-unfold and lock-unlock solar wing, technological parameters and specific structural parameters are determined. The fold-unfold and lock-unlock solar wing unfolding characteristic is analyzed. According to the transitive relation analysis of repeated fold-unfold and lock-unlock solar wing, the analysis modeling on its deploying kinetic characteristics, including forward kinematics and inverse kinematics, are derived. Simulation results show that plane degree and synchronization degree of the solar wing can meet the requirements of specifications, which lays the theoretical foundation to further research the fold-unfold and lock-unlock solar wing in the future.
- Solar wing /
- Two-stage helical mechanism /
- Repeated fold-unfold and lock-unlock /
- Deploying kinematics

HTML全文

参考文献(8)

[1]	Ding Feng. Typical mast-liked deployment mechanism with truss structure[J]. Aerosp. Shanghai, 2006, 26(1):35-40. In Chinese (丁锋．典型杆状构架式展开机构[J]. 上海航天, 2006, 26(1):35-40)
[2]	Usaro R L. Space Mechanisms Need for Future NASA Long Duration Space Missions: Space Mechanisms Technology Workshop[R]. USA Washington D C: NASA Glenn Research Center, 2000
[3]	Barret R, Campbell D, Lake M S, et al. Development of a passively deployed roll-out solar array[J]. AIAA J., 2006, 26(4):4002-4011
[4]	Murphy D M. Thin film and crystalline solar cell array system performance comparisons[C]//The 29th IEEE PVS, LA: New Orleans, 2002, 20-4
[5]	Yu Dengyun, Sun Jing, Ma Xingrui. Deployment and hold-down and release mechanism of large space component[J]. Spacecr. Eng., 2007, 16(1):23-27. In Chinese (于登云, 孙京, 马兴瑞. 大型构件伸展与锁(压)紧释放技术[J]. 航天器工程, 2007, 16(1):23-27)
[6]	Bai Zhengfeng, Tian Hao, Zhao Yang. Dynamics simulation of deployment and locking of spacecraft solar panel using ADAMS[J]. Mach. Design Manuf., 2006, 47(11):124-126. In Chinese (白争锋, 田浩, 赵阳. 基于ADAMS航天器太阳帆板展开与锁定动力学仿真[J]. 机械设计与制造, 2006, 47(11):124-126)
[7]	Zhang Peng, Gao Haibo, Deng Zongquan, et al. Dynamic analysis of deployable solar panel[J]. J. Astron., 2009, 30(4):1359-1364. In Chinese (张朋, 高海波, 邓宗全, 等. 展开式太阳板的动力学分析[J]. 宇航学报, 2009, 30(4):1359-1364)
[8]	An Yuan, Gu Song, Jin Guang. Analysis and simulation of deployment motion of satellite solar array[J]. Chin. J. Opt. Appl. Opt., 2009, 2(1):29-35. In Chinese (安源, 谷松, 金光. 卫星太阳翼展开运动的分析及仿真[J]. 中国光学与应用光学, 2009, 2(1):29-35)
