基于光学测量的大型天线测试方法研究

王宏建; 郝齐焱; 易敏; 陈雪; 刘广; 刘世华; 赵鑫

doi:10.11728/cjss2013.01.115

基于光学测量的大型天线测试方法研究

doi: 10.11728/cjss2013.01.115 cstr: 32142.14.cjss2013.01.115

1.
中国科学院空间科学与应用研究中心北京 100190
2.
中国科学院微波遥感技术重点实验室北京 100190

详细信息

中图分类号: V44
计量
- 文章访问数: 3042
- HTML全文浏览量: 244
- PDF下载量: 1052
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2011-10-28
- 修回日期: 2012-03-25
- 刊出日期: 2013-01-15

Radiation patterns of big antennas based on optics measurement

1.
Center for Space Science and Applied Research, Chinese Academy of Sciences, Beijing 100190

摘要

摘要: 提出了一种基于光学照相的电磁场数值计算测试电大尺寸天线辐射特性的新方法. 根据光学照相实测大型天线的形面三维坐标计算出天线表面电流分布, 利用物理光学计算得到天线远场方向图和增益. 采用该方法得到的海洋二号校正辐射计观测天线和充气天线的辐射特性与平面近场测试结果的对比验证了其具有足够的准确性. 该方法具有快速、灵活的特点, 可以推广到电大尺寸天线测试.
- 光学照相 /
- 电大尺寸天线 /
- 平面近场测试
Abstract: A new method to measure the large-aperture antenna radiation patterns was proposed. It is difficult for far-field, near-field and CATR measurement to meet the measurement requirements of electrically large antenna. Surface measurement of parabolic reflector antenna by photogrammetry at multiple points can achieve high accuracy, even electronic theodolite and laser interferometer can achieve more accuracy to meet surface measurement requirement of large-aperture terahertz antenna. This method used the data obtained by actual optical measurement to simulate the real antenna radiation by physical optics method. Because of using the real antenna measured data, this simulation method gave the actual antenna gain and radiation results. The simulation results agreed well with the antennas patterns obtained by the real near-field tests. This method was fast and much adaptable for the large-aperture antenna.
- Photogrammetry /
- Big aperture antenna /
- Near-field testing

HTML全文

参考文献(6)

[1]	Huang J. The development of large flat inflatable antenna for deep-space communications[C]//AIAA Space 2004 Conference and Exposition. San Diego: American Institute of Aeronautics and Astronautics, 2004. 2254-2267
[2]	Paguay M H, Daddato R J, Parian J A, et al. Terahertz antenna technology and verification: Herschel and Planck-A review[J]. IEEE Trans. Micr. Theory Tech., 2010, 58(7):2046-2063
[3]	Ruze J. Antenna tolerance theory-A review[J]. IEEE Proc., 1966, 54(4):633-640
[4]	Pappa R S, Giersch L R, Quagliaroli J M. Photogrammetry of a 5m inflatable space antenna with consumer-grade digital cameras[J]. Exp. Tech., 2001, 25(4):21-29
[5]	Wang Hongjian, Liu Heguang. Antenna subsystem of Haiyang-2 microwave calibration radiometer[J]. Chin. J. Radio Sci., 2009, 24(6):1168-1171. In Chinese (王宏建, 刘和光. 海洋二号微波定标辐射计天线子系统[J]. 电波科学学报, 2009, 24(6):1168-1171)
[6]	Wang Hongjian. The surface measurement of inflatable parabolic antenna[J]. Remote Sens. Technol. Appl., 2010, 25(2):268-271. In Chinese (王宏建. 充气天线形面测试方法研究[J]. 遥感技术与应用, 2010, 25(2):268-271)
