Surveying performance analysis of the new generation satellite navigation signals
-
摘要: 导航信号的测量性能最终影响系统定位、测速、授时等服务精度, 是系统顶层设计的重要论证内容之一. 结合COMPASS系统新一代卫星导航信号体制框架设计, 分析了各种应用条件下的伪距、载波相位和多普勒测量精度, 并以典型设计参数为例进行了数值计算. 结果表明, 在接收机典型设计参数和工作条件下, 各信号分量均能够实现0.1m的伪距测量精度、0.006周的载波相位测量精度以及0.005m·s-1的多普勒测量精度. 首次给出的针对新信号体制各项测量性能的研究结果可为卫星导航系统信号体制设计、 导航接收机关键参数设计以及卫星导航系统用户测距误差预算等顶层设计提供参考.Abstract: Surveying performance of navigation signal affects the precision of position, velocity and timing, and it is one of the important factors for system design. Combining with the new signals system frame design of COMPASS, measuring precisions of pseudorange, carrier phase and Doppler frequency of new generation satellite navigation signals are analyzed, and numerical calculation is carried out taking typical design parameters as example. Results indicate that all the signals can achieve the following surveying performances under typical receiver design parameters and using environments: 0.1m of pseudorange precision, 0.006 cycles of carrier phase precision and 0.005m·s-1 of Doppler frequency precision. The study can offer references for the design of satellite navigation system signals, the key parameters design of navigation receivers and the budget of user ranging errors.
-
Key words:
- Carrier noise ratio /
- Pseudorange /
- Carrier phase /
- Doppler frequency
-
[1] Global Positioning System Wing. Navstar GPS Space Se-gment/Navigation User Interfaces[R], IS-GPS-200E, 2010 [2] Global Positioning System Wing. Navstar GPS Space Segment/User Se-gment L5 Interfaces[R], ICD-GPS-705, 2005 [3] Global Positioning System Wing. Navstar GPS Spaces Se-gment/User Segment L1C Interfaces[R], IS-GPS-800A, 2010 [4] European Union. European GNSS (Galileo) Open Service Signal in Space Interface Control Document Issue 1[S]. Luxembourg:Publications Office of the European Union, 2010 [5] Li Bao, Xu Jiangning, Cao Kejin, et al. Analysis and simulation on anti-multipath performance of Beidou2 navigation[J]. J. Chin. Inert. Techn., 2012, 20(3):339-347. In Chinese (李豹, 许江宁, 曹可劲, 等. 北斗二代导航信号抗多径性能分析 与仿真[J]. 中国惯性技术学报, 2012, 20(3):339-347) [6] Huang Lei, Mo Yun. Acquisition algorithm for GNSS multi-constellation signals[J]. Sci. China: G., 2011, 41(5):645-652. In Chinese (黄磊, 莫钧. GNSS信号兼容捕获算法[J]. 中国科学: G辑, 2011, 41(5):645-652) [7] Chen Xialan, Huang Zhigang, Geng Shengqun, et al. Research and implementation of tracking algorithm for CBOC modulation navigation signal[J]. Sci. China: G., 2011, 41(5):640-644. In Chinese (陈夏兰, 黄智刚, 耿生群, 等. CBOC调制导航信号跟踪算法研 究及实现[J]. 中国科学: G辑, 2011, 41(5):640-644) [8] Kaplan E D, Hegarty C J. Understanding GPS Principles and Applications (Second Edition)[M]. American: Artech House, 2006. 185-199 [9] Tan Shusen, Zhou Bing, Guo Shengtao, et al. Research on COMPASS navigation signals of China[J]. Chin. Space Sci. Techn., 2011, 31(4):9-14 -
