Image matching analysis and experiment of spaceborne camera swayed in the end of orbit life
-
摘要: 通过分析卫星轨道末期星载TDI CCD相机成像面临的数据读出频率过大、像移失配严重等瓶颈问题, 提出了轨道末期卫星侧摆成像匹配方案. 依据轨道衰减高度, 设计侧摆成像匹配模型, 计算出轨道高度与匹配成像侧摆角度之间的变化关系, 对侧摆成像时的像移速度矢量、偏流角度、成像畸变等进行了定量的可行性分析, 并利用蒙特卡洛方法分析了满足侧摆成像的卫星姿态指向精度和稳定度. 利用基于小型三轴气浮台的小卫星姿态控制系统和TDI CCD相机成像系统进行仿真试验, 结果表明, 仿真图像的MTF函数和互相关相似性测度均在0.85以上, 侧摆成像匹配方案能较好地满足轨道末期成像需求.Abstract: Satellite sways matching image is established by analyzing the bottlenecks problem of that the data read-out frequency is too large, and the serious mismatch shift which spaceborne TDI CCD camera might face in the end of orbit life. Based on orbital decay height, the model of swaying match image is designed, the relation between orbit height and angle of the matching image is calculated, quantitative analysis on the feasibility of image motion vector, deviant angle, image distortion are carried out, and then satellite attitude pointing accuracy and stability which meet the requirement of imaging are analyzed through Monte Carlo methods. Finally, physical simulation of TDI CCD camera swaying-imaging is conducted on the mini-type three-axis air bearing table constructed for attitude control simulation of small satellite. Simulation results suggest that the MTF simulation and cross-correlation function of the similarity measurement are both more than 0.85, and satellite swaying to match image can meet the imaging requirement well in the end of the orbit life.
-
Key words:
- TDI CCD camera /
- Resolution /
- Deviant angle /
- MTF /
- Image motion /
- Read-out frequency
-
[1] He Xiaojun, Jin Guang, Yang Xiubin. Imaging model and image recovering algorithms of spaceborne camera in the end of orbit life[J]. Acta Geodaet. Cartogr. Sin., 2010, 39(6):579-584. In Chinese (贺小军, 金光, 杨秀彬. 星载相机轨 道末期成像模型及图像复原算法[J]. 测绘学报, 2010, 39(6):579-584) [2] Zhou Chunping, Gong Huili, Li Xiaojuan, et al. The Summary of MTF restoration on remote sensing image[J]. Spacecr. Recov. Rem. Sens., 2009, 30(1):27-32. In Chinese (周春平, 宫辉力, 李小娟, 等. 遥感图像MTF复原国内研究现状[J]. 航天返回与 遥感, 2009, 30(1):27-32) [3] Li Qingzhen, Zhu Xiaoping, Zhou Zhou. Research on UAV motion-blurred image restoration[J]. Fire Cont. Comm. Cont., 2009, 34(2):51-54. In Chinese (李庆震, 祝小平, 周洲. 无人机运动模糊图像复原技术[J]. 火力与指挥控制, 2009, 34(2):51-54) [4] Sun Zhiyuan, Zhang Liu, Jin Guang. Simulation and experiment on attitude tracking control of small TV satellite[J]. Opt. Prec. Eng., 2006, 14(4):697-703. In Chinese (孙志远, 张刘, 金光. 视频小卫星凝视姿态跟踪的仿真与实验[J]. 光学精密工程, 2011, 19(11):2715-2723) [5] Jiao Binliang, Yan Xuhui. Image motion analysis and image restoration based on TDI-CCD imaging[J]. J. Astron., 2008, 29(2):675-678. In Chinese (焦斌亮, 闫旭辉. 基于TDI-CCD成像像移分析及图像复原[J]. 宇航学报, 2008, 29(2):675-678) [6] Yang Xiubin, Jin Guang, Zhang Liu. Satellite swaying to compensate Earth speed research and imaging simulation analysis[J]. J. Astron., 2008, 29(2):675-678. In Chinese (杨秀彬, 金光, 张刘. 卫星后摆补偿地速研究及成像仿真分析[J]. 宇航学报, 2010, 31(3):912-917) [7] Wang Jiaqi, Yu Ping, Yan Changxiang, et al. Space optical remote sensor image motion velocity vector computational modeling, error budget and synthesis[J]. Chin. Opt. Lett., 2003, 3(7):414-417 [8] Wu Xingxing, Liu Jinguo. Image motion compensation of three line stereo mapping camera using earth ellipsoid[J]. Opt. Prec. Eng., 2011, 19(8):1794-1800. In Chinese (武星星, 刘金国. 应用地球椭球的三线阵立体测绘相机像移 补偿[J]. 光学精密工程, 2011, 19(8):1794-1800) [9] Zhang Liu, Sun Zhiyuan, Jin Guang. Design of physical simulation system for TDI CCD dynamic imaging[J]. Opt. Prec. Eng., 2011, 19(3):641-650. In Chinese (张刘, 孙志远, 金光. 星载TDI CCD 动态成像全物理仿真系 统设计[J]. 光学精密工程, 2011. 19(3):641-650) [10] Zhang L, Li S J, Jin G, et al. Modeling of satellite borne TDI CCD pitching imaging image motion velocity vector[C]//IEEE International Conference on ICAL. Shenyang: IEEE, 2009. 1587-1591 [11] Yang Xiubin, He Xiaojun, Zhang Liu, Jin Guang. Effect and simulate of the deviant angle error on TDI CCD cameras image[J]. Opto-Electr. Eng., 2008, 35(11):45-50. In Chinese (杨秀彬, 贺小军, 张刘, 金光. 偏流角误差对TDI CCD相机成像的 影响与仿真[J]. 光电工程, 2008, 35(11):45-50)
