Fuzzy Robust Sliding Mode Control and Flexible Vibration Active Suppression of Flexible-joint Space Robot Based on Flexibility Compensation
-
摘要: 针对参数不确定的漂浮基柔性关节空间机器人系统,研究了其动力学建模过程、运动控制律设计及柔性振动的主动抑制.利用系统动量、动量矩守恒关系和拉格朗日方程建立了系统的动力学方程.为克服传统奇异摄动法仅适用于关节弱柔性系统这一局限性,设计了柔性补偿项来等效提高空间机器人系统中柔性关节的刚度.在此基础上,利用奇异摄动法将系统分解为相互独立的慢变子系统和快变子系统,并分别进行控制律设计.所设计的慢变子系统模糊鲁棒滑模控制律可补偿系统中的不确定参数,减小柔性关节引起的转角传动误差,实现系统期望运动轨迹的渐近跟踪;快变子系统控制律可主动抑制柔性关节引起的系统柔性振动.仿真实验结果证明了该混合控制律的有效性.Abstract: For free-floating flexible-joint space robot system with uncertain parameters, the dynamics modeling, motion controller design and flexible vibration active suppression are developed. Dynamic equations of the system are established by the system's linear and angular momentum conservation and Lagrange equation. In order to overcome the limitations of that the traditional singular perturbation method only applies to the system with weak joint flexibility, a joint flexibility compensator is designed to improve the flexible-joint's stiffness of space robot system equivalently. On the above basis, the system is decomposed into a slow subsystem and a fast subsystem by singular perturbation method, and the controllers of the subsystems are designed. The slow subsystem's fuzzy robust sliding mode controller can compensate the uncertain parameters, decrease the rotation angle transmission errors caused by the flexible-joint, and realize the asymptotic tracking of the system desired trajectory. The fast subsystem controller can suppress the flexible vibration caused by flexible-joint actively. The simulation experimental results prove the efficiency of the hybrid controller.
-
Key words:
- Space robot /
- Flexible-joint /
- Singular perturbation /
- Flexibility compensation /
- Fuzzy /
- Robust /
- Sliding mode
-
[1] Li Qing, Wang Tianshu. Adaptive mode method in inverse dynamics of a rotation flexible manipulator with high-frequency excitation[J]. Chin. J. Space Sci., 2008, 28(4):345-349. In Chinese (李青, 王天舒. 高频激励下旋转柔性臂逆动力学模态自适应方 法研究[J]. 空间科学学报, 2008, 28(4):345-349) [2] Kumar A, Pathak P, Sukavanam N. Reduced model based control of two link flexible space robot[J]. Intell. Contr. Autom., 2011, 2(2):112-120 [3] Chen Zhiyong, Chen Li. Coordinated motion control and vibration suppression of rigid-flexible space robot based on neural network[J]. Chin. J. Space Sci., 2012, 32(1):147-153. In Chinese (陈志勇, 陈力. 刚柔空 间机器人基于神经网络的协调运动控制及柔性振动抑制[J]. 空间科学学报, 2012, 32(1):147-153) [4] Ge Xinsheng, Jiang Bingli, Liu Yanzhu. The LQ optimal control method for vibration suppression of rigid flexible space manipulator[J]. J. Vibr. Shock, 1999, 18(1):49-52. In Chinese (戈新生, 姜兵利, 刘延柱. 空间刚柔性机械臂振动抑制的LQ最 优控制方法[J]. 振动与冲击, 1999, 18(1):49-52) [5] Hong Zhaobin, Chen Li. Active vibration control and fuzzy control of free-floating space flexible manipulator based on singular perturbation theory[J]. Chin. J. Mech. Eng., 2010, 46(7):35-41. In Chinese (洪昭斌, 陈力. 漂浮基柔性空间机械臂基于奇异摄动法的模糊控制和柔性振动主动控制[J]. 机械工程学报, 2010, 46(7):35-41) [6] Lightcap C A, Banks S A. An extended Kalman filter for real-time estimation and control of a rigid-link flexible-joint manipulator[J]. IEEE Trans. Control Syst. Technol., 2010, 18(1):91-103 [7] Yoo S J, Park J B, Choi Y H. Adaptive output feedback control of flexible-joint robots using neural networks: Dynamic surface design approach[J]. IEEE Trans. Neural Networks, 2008, 19(10):1712-1726 [8] Li Xiaoqin, Zhang Dingguo. Dynamics simulation of flexible-joint robots[J]. J. Syst. Simul., 2008, 20(10):2550-2552. In Chinese (李小琴, 章定国. 柔性铰机器人动力学仿真[J]. 系统仿真学报, 2008, 20(10):2550-2552) [9] Yan R H, George V. Modeling and Control of Free-flying Flexible Joint Coordinated Robots. International Conference on Advanced Robotics. Monterey, CA: IEEE, 1997. 1013-1020. [10] Xie Limin, Chen Li. Singular Perturbation and fuzzy variable structure sliding mode control of space robot system with flexible joint in inertial space[C]//62nd International Astronautical Congress. Cape Town: International Astronautical Federation, 2011 [11] Spong M W. Robot Dynamics and Control[M]. New York, USA: JohnWiley & Sons, 1989 [12] Ghorbel F, Hung J Y, Spong M W. adaptive control of flexible-joint manipulators[J]. IEEE Control Syst. Mag., 1989, 9(7):9-13 [13] Slotin J E, Li W P. On the adaptive control of robot manipulators[J]. Int. J. Robot. Res., 1987, 6(3):49-59
