基于斜向探测最高可用频率反演电离层参数

王健; 姬生云; 王洪发; 卢冬鸣; 王先义

doi:10.11728/cjss2014.02.160

基于斜向探测最高可用频率反演电离层参数

doi: 10.11728/cjss2014.02.160

中国电波传播研究所青岛 266107

基金项目: 国家自然科学基金项目（40904040）和国家重点实验室基金项目（CEMEE2014K0101A）共同资助

详细信息

通讯作者:
王健,E-mail:wangjian@criep.com

中图分类号: P352.3
计量
- 文章访问数: 1427
- HTML全文浏览量: 51
- PDF下载量: 2034
- 被引次数: 0
出版历程
- 收稿日期: 2013-04-23
- 修回日期: 2013-09-06
- 刊出日期: 2014-03-15

Method for determining the critical frequency and propagation factor at the path midpoint from maximum usable frequency and its propagation delay based on oblique sounder

China Research Institute of Radiowave Propagation, Qingdao 266107

摘要

摘要: 提出了一种利用斜向探测F₂层最高可用频率及其对应时延反演传播路径中点临界频率f₀F₂和3000km传输因子M（3000）F₂的新方法.该方法从工程实用角度出发，利用射线传播理论直接反演得到临界频率和3000km传输因子.通过对长春-径阳和新乡-赤峰两条斜向探测链路中点电离层参数的反演分析，验证了方法的稳定性；利用反演结果与北京垂直探测数据对比，验证了方法的准确性；通过与Smith方法的对比，验证了方法的实用性.统计分析显示，此方法具有与Smith方法可比的精度，明显优于参考电离层模型给出的结果，其均方误差为0.48MHz，相对误差为10.50%；具有较好的稳定性，对不同距离的探测链路有较好的适应性，反演精度差异为0.03MHz；具有可操作性强，易于实现的特点.本研究成果可用于短波通信频率实时预报、动态频率管理及其相关领域.
- 电离层 /
- 斜向探测 /
- 临界频率 /
- 传输因子
Abstract: Accurately determining critical frequency and propagation factor of ionosphere was important to frequency forecast and management of short-wave communication. Oblique sounder provide a valid method for real-time observation of it. A new practicable method was presented for determining f₀F₂ and M(3000)F₂ at the path midpoint from the oblique sounding data, which was based on simple oblique ray theory and only rely on maximum observation frequency and its propagation delay. The inversion from oblique sounding data on the Changchun-Jingyang and Xinxiang-Chifeng path, were compared with the vertical sounding data in Beijing during October 2009. According to analysis, the stability, accuracy and practicability of the new method are validated. The results show that the root-mean-square error of the new inverse method is 0.48MHz, and the relative root-mean-square error is 10.50%. It is obvious that the new inverse method is better than Smith's method and reference ionosphere of China. Moreover, the method is simple and easy to use. It provides the basis for frequency forecast and management of short-wave communication, and help to know ionospheric variational characteristics.
- Ionosphere /
- Oblique sounding /
- Critical frequency /
- Propagation factor

HTML全文

参考文献(24)

[1]	Chen Gang, Zhao Zhengyu, Zhang Yuannong, et al. Application of the oblique ionogram as vertical ionogram[J]. Sci. China. 2012, 55(5):1240-1244
[2]	Rao N N. Inversion of sweep-frequency sky-wave backscatter leading edge for quasiparabolic ionospheric layer parameters[J]. Radio Sci., 1974, 9(10):845-847
[3]	Liu Wen, Jiao Peinan, Wang Junjiang. An inverse algorithm of oblique ionogram and its stability[J]. Chin. J. Radio Sci., 2003, 18(6):597-601. In Chinese (柳文, 焦培南, 王俊江. 斜测电离图反演及其不稳定性研究[J]. 电波科学学报, 2003, 18(6):597-601)
[4]	Xu Tong. Study on Genetic Inverse Method for Ionospheric Parameters from VI and Oblique Ionograms[D]. Xi'an:Xidian University, 2006. In Chinese (徐彤. 垂直和斜向探测电离层参数反演遗传算法研究[D]. 西安: 西安电子科技大学, 2006)
[5]	Kotovich G V, Kim A G, Ya S, et al. Determining the f₀ F₂ critical frequency at the path midpoint from oblique sounding data based on the Smith method[J]. Geomag. Aeron., 2006, 46(4):517-521
[6]	Chang Mei, Liu Xuanmou. Calculation of electron density profiles from oblique ionogram[J]. Wuhan Univ. J. Nat. Sci., 1993(1):119-121. In Chinese (常梅, 刘选谋. 用斜电离图反演电离层电子密度剖面[J]. 武汉大学学报:自然科学版, 1993(1):119-121)
[7]	CCIR. CCIR Atlas of Ionospheric Characteristics[R]. Geneva: CCIR, 1991
[8]	International Telecommunication Union. Definitions of maximum and minimum transmission frequencies[R], Rec. ITU-R P. 373-1. Geneva: ITU, 2008
[9]	Wang Jian, Feng Xiaozhe, Cheng Li. Basic MUF observation and comparison of HF radio frequency prediction based on different ionosphere models[C]//The 9th International Symposium on Antennas, Propagation, and EM Theory. Guangzhou: IEEE, 2010
[10]	International Telecommunication Union. Method for the prediction of the performance of HF circuits[R], Rec. ITU-R P.533-10. Geneva: ITU, 2009
[11]	International Telecommunication Union. Methods of basic MUF, operational MUF and ray-path prediction[R], Rec. ITU-R P.1240-1. Geneva: ITU, 2007
[12]	International Telecommunication Union. Reference ionospheric characteristics[R], Rec ITU-R P.1239-1. Geneva: ITU, 2008
[13]	Chen Chun, Wu Zhensun, Sun Shuji, et al. MUF variability at Haikou[C]//The 8th International Symposium on Antennas, Propagation, and EM Theory. Kunming: IEEE, 2008
[14]	Liu Ruiyuan, Quan Kunhai, Dai Kailiang, et al. A corrected method of the International Reference Ionosphere to be used in Chinese region[J]. Chin. J. Geophys., 1994, 37(4):422-432. In Chinese (刘瑞源, 权坤海, 戴开良, 等, 国际参考电离层用于中国地区时修正计算方法[J]. 地球物理学报, 1994, 37(4):422-432)
[15]	Wang Jian, Zhao Hongmei, Fu Wei. Further comparison of basic MUF prediction based on different ionosphere models during medium solar activity epochs[C]//The 10th International Symposium on Antennas, Propagation, and EM Theory. Xi'an: IEEE, 2012
[16]	Wang Jian, Feng Xiaozhe, Zhao Hongmei, et al. Refined study of HF frequency prediction method in China region[J]. Chin. J. Geophys., 2013, 56(6):1797-1808. In Chinese (王健, 冯晓哲, 赵红梅, 等. 高频频率预测方法中国区域的精细化研究. 地球物理学报, 2013, 56(6):1797-1808)
[17]	Xu Bin, Wu Yonghong, Liu Yimin. Maximum usable frequency adaptive prediction[J]. Chin. J. Radio Sci., 2010, 26(4):699-703. In Chinese (徐彬, 吴永宏, 刘毅敏. 最高可用频率自适应预报算法研究[J]. 电波科学学报, 2011, 26(4):699-703)
[18]	Liu Yanan, Liu Xuecai, Wang Jian, et al. Adaptive prediction of maximum usable frequency in high-frequency communication[J]. Chin. J. Space Sci., 2013, 33(3):285-291. In Chinese (刘亚南, 刘学才, 王健, 等. 高频通信最大可用频率的自适应预报[J]. 空间科学学报, 2013, 33(3):285-291)
[19]	Huo Jinhai, Wang Jian, Wu Liqiang, et al. Short-term forecasting method of maximum usable frequency for HF communication based on oblique sounder[C]//The 2nd international conference on Measurement, Instrumentation and Automation. Switzerland: Trans. Tech. Public., 2013: 1676-1681
[20]	Zhu Zhenfei, Liu Yimin, Wu Yonghong, et al. A method of link status inquiry for HF network dynamic frequency management[J]. Chin. J. Radio Sci., 2013, 28(3):467-471. In Chinese (朱振飞, 刘毅敏, 吴永宏, 等. 短波网动态频率管理系统的状态查询设计[J]. 电波科学学报, 2013, 28(3):467-471)
[21]	Wang Jian, Hui Shouqiang, Fu Wei, et al. Error characteristic analysis and accuracy optimizing idea of HF single site location[J]. Chin. J. Radio Sci., 2010, 25(5):925-933. In Chinese (王健, 惠守强, 付炜, 等. 高频单站定位误差特性分析及精度优化构想[J]. 电波科学学报, 2010, 25(5):925-933)
[22]	Wang Jian, Fu Wei, Feng Xiaozhe, et al. Technique on high-frequency single-site location in short distance[J]. Elect. Inf. Warf. Tech., 2009, 24(1):25-28. In Chinese (王健, 付炜, 冯晓哲, 等. 近距离高频单站定位技术[J]. 电子信息对抗技术, 2009, 24(1):25-28)
[23]	Feng Xiaozhe, Huang Changli. Quasi-parabolic ionospheric layer parameters realtime data modification in support of single station location for HFDF system[J]. Elect. Inf. Warf. Tech., 2008, 23(5):22-26. In Chinese (冯晓哲, 黄昌理. 短波单站定位中的准抛物电离层参数实时修正[J]. 电子信息对抗技术, 2009, 23(5):22-26)
[24]	Wieder B. Some results of a sweep-frequency propagation experiment over a 1150 km east-west path[J]. J. Geophys. Res., 1955, 60(4):395-400
