一种数字电离层测高仪系统中O波与X波的分离方法

王顺; 陈紫微; 张锋; 宫兆前; 方广有; 王云冈

doi:10.11728/cjss2014.02.186

一种数字电离层测高仪系统中O波与X波的分离方法

doi: 10.11728/cjss2014.02.186

1.
中国科学院电子学研究所电磁辐射与探测技术重点实验室北京 100190
2.
国家卫星气象中心北京 100081

基金项目: 国家高技术研究发展计划项目资助（SS2012AA120505）

详细信息

通讯作者:
王顺,E-mail:swang@mail.ie.ac.cn

中图分类号: P352
计量
- 文章访问数: 1938
- HTML全文浏览量: 115
- PDF下载量: 1558
- 被引次数: 0
出版历程
- 收稿日期: 2013-03-26
- 修回日期: 2013-10-12
- 刊出日期: 2014-03-15

A method for separating O wave and X wave in digital ionosonde

1.
Key Laboratory of Electromagnetic Radiation and Detection Technology, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190
2.
National Center for Space Weather, Beijing 100081

摘要

摘要: 电离层测高仪系统中，O波与X波的分离非常重要.本文提出一种新的O波与X波分离的实现方法，根据电离层回波的极化特性，通过在接收电路上采用数字方法合成圆极化波的方式，实现了对O波与X波的有效分离.与现有DPS-4测高仪系统采用模拟域电信号合成圆极化波的方法相比，本文方法通过在数字下变频处理过程中引入±90°相移，消除了在模拟域电信号合成方法中相移器的带宽限制和非线性问题.另外，该方法在实现发射和接收信号的极化状态转换时不需要连续切换多个模拟开关，从而提高了整个系统的稳定性.
- 电离层测高仪 /
- 频高图 /
- O波和X波 /
- 圆极化天线
Abstract: Separation for O wave and X wave is an important job in ionosphere detection. A new digital method for separating O wave and X wave is presented in this paper, being different from using image recognition technique to separate trace O and trace X in ionograms or electrical method to synthesize circularly polarized signals to separate O wave and X wave from echoes of the ionosphere. A numerical synthesizing method is employed in the new method. By introducing phase shifters of ±90° in digital domain, circularly polarized signals are synthesized digitally within the range of 1～ 30MHz, which eliminates the nonlinearity and expands the bandwidth of the ionosonde compared with DPS-4, and there is no need to switch the analog switches continuously. The new method has been successfully applied to CAS-DIS ionosonde and testing results show that the new digital method is capable of separating O wave and X wave well.
- Ionosonde /
- Ionogram /
- O wave and X wave /
- Circularly polarized antenna

HTML全文

参考文献(12)

[1]	Titheridge J E. The real height analysis of ionograms: A generalized formulation[J]. Radio Sci., 1998, 23:831-849
[2]	Huang X, Reinisch B W. Vertical electron density profiles from the digisonde network[J]. Adv. Space Res., 1996, 18:121-129
[3]	Pezzopane M, Scotto C. Automatic scalling of critical frequency f₀F₂ and MUF(3000)F2: A comparsion between Autoscala and ARTIST 4.5 on Roma data[J]. Radio Sci., 2007, 42:RS4003
[4]	Scotto C. Elecron density profile calculation technique for Autoscala ionogram analysis[J]. Adv. Space Res., 2009, 44:756-766
[5]	Krasheninnikov M, Pezzopane C, Scotto C. Application of Autoscala to ionograms record by the AIS-Parus ionosonde[J]. Comput. Geosci., 2010, 36:628-635
[6]	Bullett T, Malagnini A, Pezzoane M, Scotto C. Application of autoscala to ionograms recorded by the VIPIR ionosonde[J]. Adv. Space Res., 2010, 45:1156-1172
[7]	Reinisch B W, Galkin I A, Khmyrov G M, et al. New Digisonde for research and monitoring applications[J]. Radio Sci., 2009, 44:1-15
[8]	Bibl K. Evolution of the ionosonde[J]. Ann. Geophys., 1998, 41:5-6
[9]	Zuccheretti E, Tutone G, Sciacca U. The new AIS-INGV digital ionosonde[J]. Ann. Geophys., 2003, 46(4):647-659
[10]	Zhu Zhengping, Ning Baiqi, Wan Weixing. Measurement and analysis of ionospheric virtual height with high precision[J]．Chin. J. Space. Sci., 2007, 27(3):204-210. In Chinese (朱正平, 宁百齐, 万卫星. 电离层虚高的高精度测量与分析[J]. 空间科学学报, 2007, 27(3):204-210)
[11]	Zhu Zhengping, Ning Baiqi, Sun Fenglou, Chen Kun. Study of passive receiving observation mode for ionospheric digital ionosonde[J]. Chin. J. Space Sci., 2009, 29(4):389-396. In Chinese (朱正平, 宁百齐, 孙奉娄, 陈锟. 电离层数字测高仪被动接收观测模式研究[J]. 空间科学学报, 2009, 29(4):389-396)
[12]	Devies K. Ionospheric Radio[M]. London: Peter Peregrinus Ltd., 1990:92
