Chang’E-3 Lander’s scientific payloads
-
摘要: 嫦娥三号着陆器配置了地形地貌相机、月基光学望远镜、极紫外相机、降落相机等四种科学探测有效载荷.介绍了有效载荷的科学探测任务、系统设计方案和系统组成,描述了各有效载荷的方案设计和主要技术指标等.Abstract: Four kinds of scientific instruments are chosen as the payloads on Chinese Chang'E-3 Lander, including topography camera, lunar astronomical optical telescope, extreme ultraviolet imager and descending camera. Topography camera is to acquire the optical image of lunar surface topography around the landing area, and observe the rover moving process on the lunar surface. Lunar astronomical optical telescope operates in the near ultraviolet spectrum, which can observe the brightness variations of various stars. Extreme ultraviolet imager works on the wavelength of 30.4nm, and the observation target is the resonance scattering between Earth's plasma He+ layer and 30.4nm solar radiation. Descending camera is to acquire the lunar optical image in the landing region during descending. In this paper, Chang'E-3 Lander's scientific exploration missions, as well as the payloads' system design are introduced. Each payload's design and main technical specifications are also described in detail.
-
Key words:
- Chang’E-3 /
- Payload /
- Topography camera /
- Lunar optical telescope /
- Extreme ultraviolet imager /
- Landing camera
-
[1] Jia Yingzhuo. System design for CE-3 Lander's payloads[R]. Beijing: Center for Space Science and Applied Research, Chinese Academy of Sciences, 2011. In Chinese (贾瑛卓. CE-3着陆器有效载荷分系统设计报告[R]. 北京: 中国科学院空间科学与应用研究中心, 2011) [2] Luo Zongfu, Meng Yunhe, Tang Guojian. Lunar soft-landing trajectory design based on evolutionary strategy[J]. Chin. J. Space Sci., 2012, 32(1):92-98. In Chinese (罗宗富, 孟云鹤, 汤国建. 基于进化策略的月球软着陆探测器轨道设计[J]. 空间科学学报, 2012, 32(1):92-98) [3] Gong Dezhu, Jia Jinzhong, Liu Yang. Research of circuit system in CCD ultraviolet sensor for probing moon[J]. Chin. J. Space Sci., 2006, 26(2):132-141. In Chinese (龚德铸, 贾锦忠, 刘洋. 紫外CCD敏感器头部电路系统的研究[J]. 空间科学学报, 2006, 26(2):132-141) [4] Wang Jie, Zeng Zuoxun, Yu Zongyu, et al. Research of lunar tectonic features: Primary results from Chang'E-1 lunar CCD image[J]. Chin. J. Space Sci., 2011, 31(4):482-491. In Chinese (王杰, 曾佐勋, 岳宗玉, 等. 月球主要构造特征: 嫦娥一号月 球影像初步研究[J]. 空间科学学报, 2011, 31(4):482-491) [5] Chen Chao, Qin Qiming, Lu Yan, et al. Research on photometric correction of lunar image from CCD stereo camera onboard Chang'E-1 satellite[J]. Chin. J. Space Sci., 2013, 33(1):120-127. In Chinese (陈超, 秦其明, 卢燕, 等. 嫦娥一号CCD立体相机数据光度校正[J]. 空间科学学报, 2013, 33(1):120-127) [6] Bell J F Ⅲ, Squyres S W, Herkenhoff K E, et al. Mars Exploration Rover Athena Panoramic Camera (Pancam) investigation[J]. J. Geophys. Res., 2003, 108(E12):8063, doi: 10.1029/2003 JE002070 [7] Sandel B R, Broadfoot A L, Curtis C C, et al. The extreme ultraviolet imager investigation for the IMAGE mission[J]. Space Sci. Rev., 2000, 91:197-242 [8] Morris O G. Apollo 16 Mission Report[R], MSC-07230. USA: National Aeronautics and Space Administration, 1972
