空间材料科学实验中的X光三维成像仿真

于强; 童方圆; 周炳红

doi:10.11728/cjss2014.02.242

空间材料科学实验中的X光三维成像仿真

doi: 10.11728/cjss2014.02.242

于强^1, ,,
童方圆^1,2,
周炳红¹

1.
中国科学院空间科学与应用研究中心北京 100190
2.
中国科学院大学北京 100049

详细信息

通讯作者:
于强,E-mail:yuqiang@nssc.ac.cn

中图分类号: V447
计量
- 文章访问数: 1357
- HTML全文浏览量: 76
- PDF下载量: 1584
- 被引次数: 0
出版历程
- 收稿日期: 2013-03-15
- 修回日期: 2013-12-26
- 刊出日期: 2014-03-15

Simulation of 3D X-ray imaging for space material science experiments

1.
Center for Space Science and Applied Research, Chinese Academy of Sciences, Beijing 100190
2.
University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 用于空间材料科学研究的X射线观察设备已列入空间站材料科学实验规划，仿真实现X光三维成像的流程可为X射线观察设备的研制提供设计依据.仿真流程主要包括三个步骤：使用锥束X光照射被扫描对象并旋转对象，获取多角度下的投影影像；根据投影影像和几何信息重建扫描对象，获取对象空间点数据；将扫描对象三维显示出来.使用线衰减系数不同且相互重叠的多个椭球组成的三维Shepp-Logan模型对算法进行了仿真测试，仿真结果能很好地将模型重建并显示出来.
- X射线 /
- 三维显示 /
- 空间材料科学实验
Abstract: Developing X-ray observation facility has been planned in the Chinese space station. Simulating the process of three-dimensional X-ray imaging can offer valuable reference for the facility development. The simulation process can be divided into three steps. Firstly, to use the cone beam X-ray to scan an object, and rotate the object to obtain projection images at enough number of views; Secondly, to reconstruct the scanned object according to the projection images and the geometrical information; Finally, to visualize the reconstruction object. By employing a 3D Shepp-Logan model consisting of 10 interlapped ellipsoids with different linear attenuation coefficients as the object, the processes of projection, back projection and 3D visualization are realized by simulation, and through image reconstruction, the stereo structure of the scanned object can be well displayed.
- X ray /
- 3D display /
- Space material science experiment

HTML全文

参考文献(13)

[1]	Eyer A, Kolbesen B O, Nitsche R. Floating zone growth of silicon single crystals in a double-ellipsoid mirror furnace[J]. J. Cryst. Growth, 1982, 57(1):145-154
[2]	Yuko I, Atul S, Hisao S, et al. Real-time optical system for observation crystallization in levitated silicate melt droplets[J]. Rev. Sci. Instr., 2010, 81(7): 073708, doi: 10.1063/1.3462968
[3]	Garcia-Moreno F, Manas M, Catalina J, et al. X-Ray radioscopy of liquid metal foams under microgravity[J]. Trans. Indian Inst. Met., 2009, 62(4/5):451-454
[4]	Yu J, Koshikawa N, Yasutomo A, et al. Containerless solidification of oxide material using an electrostatic levitation furnace in microgravity[J]. J. Cryst. Growth, 2001, 231:568-576
[5]	Shepp L A, Logan B F. Reconstructing interior head tissue from x-ray transmissions[J]. IEEE Trans. Nucl. Sci., 1974, 21:228-236
[6]	Ramos C D, Ye E, Gonen M, et al. FDG-PET standardized uptake values in normal anatomical structures using iterative reconstruction segmented attenuation correction and filtered back-projection[J]. Eur. J. Nucl. Med., 2001, 28(2):155-164
[7]	Gao Shangkai. Medical Imaging System[M]. Beijing: Tsinghua University Press, 2010: 1-3, 11-20. In Chinese (高上凯. 医学成像系统[M]. 北京: 清华大学出版社, 2010: 1-3, 11-20)
[8]	Shi Jiaoying, Cai Wenli. Algorithm and System of Visualization in Scientific Computing[M]. Beijing: Science Press, 1996: 153-154. In Chinese (石教英, 蔡文立. 科学计算可视化算法与系统[M]. 北京: 科学出版社, 1996: 153-154)
[9]	Brian S K, David G H, Donald F B, et al. Skeletal 3-D CT: Advantages of volume rendering over surface rendering[J]. Skeletal Radiol., 1996, 25(3):207-214
[10]	Lee T Y, Weng T L, Lin C H, et al. Interactive voxel surface rendering in medical applications[J]. Comput. Med. Imaging Graph., 1999, 23(4):193-200
[11]	Zhang Guoqing. Research and Application of Dividing Cubes and Shear-warp 3D Restruction Algorithm[D]. Harbin: Harbin Engineering University, 2008. In Chinese (张国庆. Dividing Cubes和Shear-Warp三维重构算法研究与应用[D].哈尔滨: 哈尔滨工程大学, 2008)
[12]	Harvey R, HansPeter P. Ray casting architectures for volume visualization[J]. IEEE Trans. Visual. Comp. Graph., 1999, 5(3):210-223
[13]	Laeroute P, Levoy M. Fast volume rendering using a shear-warp factorization of the viewing transformation[J]//Proceedings of the 21st Annual Conference on Computer Graphics and Interactive Techniques. New York: ACM, 1994: 451-458
