Impact Dynamics of Flexible Space Manipulator Capturing a Satellite, Stabilization Control and Flexible Vibration Linear Quadratic Optimal Suppression
-
摘要: 研究空间机械臂系统捕获卫星过程的碰撞动力学及受碰撞后不稳定系统的控制问题. 利用第二类拉格朗日方程推导得到空间机械臂系统的动力学模型. 在空间机械臂捕获卫星而受碰撞冲击过程中,利用动量冲量法评估碰撞冲击对空间机械臂系统运动状态变化的影响效应. 为使受碰撞冲击后不稳定的空间机械臂与被捕获卫星组合体系统恢复稳定,设计了线性反馈和线性二次最优复合控制算法对受碰撞冲击后空间机械臂系统进行镇定控制和柔性杆振动抑制,所提出的控制算法无需控制漂浮基的位置,从而可以节省漂浮基位置控制推进器燃料消耗. 通过数值算例模拟了碰撞冲击对空间机械臂系统运动状态的影响效应并验证上述控制算法的效果.Abstract: The impact dynamics of space manipulator system capturing a satellite, and control of post-impact unstable system were discussed. The dynamics model of space manipulator system was derived by the second Lagrange equation. At the impact moment when the space manipulator capturing a satellite, the impact effect for the space manipulator was calculated by momentum impulse method. For stabilizing the post-impact unstable space manipulator and satellite combination system, the linear feedback and linear quadratic optimal composite control algorithm was proposed for the space manipulator stabilization control and flexible link vibration suppression, and there was no need for the position control of the free-floating base under the proposed control algorithm employed, which would save the fuel consumption of free-floating base thruster. Finally, numerical examples are proposed to simulate the impact effect for space manipulator motion state which is caused by the impact, and the effectiveness of above control algorithm is verified.
-
[1] Dubowsky S, Papadopoulos E. The kinematics, dynamics, and control of free-flying and free-floating space robotic systems[J].IEEE Trans. Robot. Autom., 1993, 9(5):531-543 [2] Evans L. Canadian space robotics on board the international space station[C]//2005 CCToMM Symposium on Mechanisms, Machines, and Mechatronics. Montreal, Canada: Canadian Space Agency, 2005 [3] Iwata T. Recent Japanese activities in space automation & robotics an overview[C]//Proceeding of the 6th International Symposium on Artificial Intelligence and Robotics and Automation in Space. Quebec, Canada: Canadian Space Agency, 2001 [4] Li Junfeng, Wang Zhaolin. Study on attitude dynamics of a liquid-filled spacecraft with manipulators[J]. J. Astron., 1999, 20(2):81-86. In Chinese (李俊峰, 王照林. 带空间机械臂的充液航天器姿态动力学研究[J]. 宇航学报, 1999, 20(2):81-86) [5] Wang Congqing, Zhang Chenglong. Dynamic control of a free-floating flexible dual-arm space robotic system[J]. Chin. J. Mech. Eng., 2007, 43(10):196-200. In Chinese (王从庆, 张承龙. 自由浮动柔性双臂空间机器人系统的动力学控制[J]. 机械工程学报, 2007, 43(10):196-200) [6] Dong Qiuhuang, Chen Li. Impact effect evaluation and RBF neural network control for stabilizing a free floating space manipulator during capturing a satellite[J]. Robot, 2013, 35(6):744-749. In Chinese (董楸煌, 陈力. 漂浮基空间机械臂捕获卫星过程的碰撞冲击效应评估与镇定运动的RBF神 经网络控制[J]. 机器人, 2013, 35(6):744-749) [7] Hong Zaidi, Yun Chao, Chen Li. Modeling of trajectory tracking control of free-floating space robot with flexible manipulators[J]. Robot, 2007, 29(1):92-96. In Chinese (洪在地, 贠超, 陈力. 柔性臂漂浮基空间机器人建模与轨迹跟踪控制[J]. 机器人, 2007, 29(1):92-96) [8] Li Qing, Wang Tianshu. Adaptive mode method in inverse dynamics of a rotating flexible manipulator with high-frequency excitation[J]. Chin. J. Space Sci., 2008, 28(4):345-349. In Chinese (李青, 王天舒. 高频激励下旋转柔性臂逆动力学模态自适应方法研究[J]. 空间科学学报, 2008, 28(4):345-349) [9] Chen Zhihuang, Chen Li. Design of fuzzy variable structure controller of hybrid position and force control for dual-arm coordinate space robot systems[J]. Chin. J. Space Sci., 2011, 31(2):260-268. In Chinese (陈志煌, 陈力. 漂浮基闭链 双臂空间机器人抓持系统动力学及载荷力/位置混合控制的模糊变结构控 制器设计[J]. 空间科学学报, 2011, 31(2):260-268) [10] Wee L B, Walker M W. On the dynamics of contact between space robots and configuration control for impact minimization[J]. IEEE Trans. Robot. Autom., 1993, 9(5):581-591 [11] Yoshikawa S, Yamada K. Impact estimation of a space robot at capturing a target[J]. Intell. Robots Syst., 1994, 3:1570-1577 [12] Jalon J G, Bayo E. Kinematic and Dynamic Simulation of Multibody Systems[M]. New York: Springer-Verlag, 1993
