基于NOAA卫星数据的辐射带质子投掷角分布研究

杨世超; 张贤国; 王月; 王春琴; 常峥; 秦慕荣; 王世金

doi:10.11728/cjss2014.03.390

基于NOAA卫星数据的辐射带质子投掷角分布研究

doi: 10.11728/cjss2014.03.390

杨世超^1,2, ,,
张贤国^2, ,,
王月²,
王春琴^1,2,
常峥^1,2,
秦慕荣^2,3,
王世金²

1.
中国科学院大学北京 100049
2.
中国科学院空间科学与应用研究中心北京 100190
3.
山东大学空间科学与物理学院威海 264209

基金项目: 国家自然科学基金项目资助（41204119）

详细信息

通讯作者:
杨世超,E-mail:chao-1987@163.com

张贤国,E-mail:zhangxg@nssc.ac.cn

中图分类号: P353.4
计量
- 文章访问数: 1099
- HTML全文浏览量: 23
- PDF下载量: 1449
- 被引次数: 0
出版历程
- 收稿日期: 2013-07-08
- 修回日期: 2013-10-14
- 刊出日期: 2014-07-15

Pitch Angle Distribution Research of Radiation Belt Protons Based on the NOAA Data

Yang Shichao^{1,2
, ,},
Zhang Xianguo^{2
, ,},
Wang Yue²,
Wang Chunqin^1,2,
Chang Zheng^1,2,
Qin Murong^2,3,
Wang Shijin²

1.
University of Chinese Academy of Science, Beijing 100049
2.
Center for Space Science and Application Research, Chinese Academy of Sciences, Beijing 100190
3.
School of Space Science and Physics, Shandong University at Weihai, Weihai 264209

摘要

摘要: 利用NOAA-12卫星数据对空间环境平静时期太阳同步轨道处辐射带质子投掷角分布进行了研究. 根据投掷角分布的经验公式，计算出90°投掷角的质子方向强度和各向异性指数n. 质子投掷角分布按n的取值范围可分为三类，即90°峰值分布、平顶分布和蝴蝶形分布. 观测证实，对于辐射带质子，三种分布类型均存在并且具有明显的空间区域特征. 在内辐射带边缘地区90°峰值分布占主要优势；在外辐射带高L值区域，90°峰值分布明显减少，平顶分布和蝴蝶形分布逐渐增多. 针对90°峰值分布，研究了质子强度各向异性的区域分布特征，对于内辐射带区域，n值随L值的增大而增大，对于外辐射带，n值表现为逐渐下降的趋势. 为了研究质子投掷角分布对磁地方时的依赖关系，分析了能量为250～800keV的质子在两个不同磁地方时范围的投掷角分布规律. 结果显示，在内辐射带，质子强度的投掷角分布相对稳定，随磁地方时的变化并不显著；而在外辐射带的高L值区域，质子强度的投掷角分布随磁地方时变化明显，与磁地方时之间有明显的依赖关系.
- 辐射带 /
- 质子强度 /
- 投掷角 /
- 各向异性
Abstract: Using the NOAA-12 satellite data, a study on the Pitch Angle Distributions (PADs) of energetic protons is performed during the quiet period of space environment in the Sun-synchronous orbit. The 90° pitch angled proton flux and the anisotropy index n are calculated based on the empirical formula. According to the n values, it's found that the distributions can be classified into three categories: 90° peaked, flattop, and butterfly. For the radiation belt protons, the three types are all existed and have a significant spatial character. The 90° peaked distributions dominate at the edge of inner radiation belt; while at the higher L values region of outer radiation belt, the 90° peaked distributions decrease obviously and the flattop distribution and butterfly distribution gradually increase with the increase of L values. For the 90° peaked distributions, relationship between the anisotropy exponent n and the L values is studied. For inner radiation belt, the n values increase rapidly with the L values increasing; for outer radiation belt, the n values decrease gradually with the L values increasing. The distributions of the radiation belt protons are also studied in two different Magnetic Local Time (MLT) regions for the 250～800keV protons. The results show that the PADs are very similar at the inner radiation belt, but have obvious differences at the higher L values region of outer radiation belt. It indicates that the PADs of radiation belt protons have little dependency on the MLT at the inner radiation belt, while have more dependency on the MLT at the higher L values region of outer radiation belt.
- Radiation belts /
- Proton intensity /
- Pitch angle /
- Anisotropies

HTML全文

参考文献(26)

[1]	Chen Guozhen, Lin Guocheng. The influence of charged particle radiation environment on the spacecrafts at LEO[J]. Chin. Space Sci. Tech., 1994(6):43-48. In Chinese (陈国珍, 林国成. 低地球轨道带电粒子辐射环境对航天器的影响[J]. 中国空间科学技术, 1994(6):43-48)
[2]	Wang Tongquan, Shen Yongping. The radiation effects of the space radiation environment[J]. J. Natl. Univ. Def. Tech., 1999, 21(4):36-39. In Chinese (王同权, 沈永平. 空间辐射环境中的辐射效应[J]. 国防科技大学学报, 1999, 21(4):36-39)
[3]	Sawyer D M, Vette J I. AP-8 Trapped Proton Environment for Solar Maximum and Solar Minimum[R]. NTIS 77-18983, 1976
[4]	Vette J I. The AE-8 Trapped Electron Model Environment[R]. Greenbelt, Maryland: National Space Sience Data Center, 1991
[5]	Daly E, Lemaire J, Heynderickx D, et al. Problems with models of the radiation belts[J]. Nucl. Sci., IEEE Trans., 1996, 43(2):403-415
[6]	Heynderickx D, Quaghebeur B, Wera J, et al. New radiation environment and effects models in the European Space Agency's Space Environment Information System (SPENVIS)[J]. Space Weather, 2004, 2(10), doi: 10.1029/2004SW000073
[7]	Huston S. Space environments and effects: Trapped proton model[J]. NASA STI/Recon Tech. Report N, 2002, 2:63598
[8]	Meffert J D, Gussenhoven M S. CRRESPRO documentation[R]. Phillips Lab Hanscom AFB MA, 1994
[9]	Brautigam D H, Bell J T. CRRESELE Documentation[R]. Phillips Lab Hanscom AFB MA, 1995
[10]	Reeves G D.Radiation Belt Storm Probes: A new mission for space weather forecasting[J]. Space Weather, 2007, 5(11):S11002
[11]	Tverskaya L. Dynamics of the Earth's radiation belts[J]. Moscow Univ. Phys. Bull., 2010, 65(4):246-251
[12]	Yang Xiaochao, Wang Shijin, Liang Jinbao, et al. Multi-directional design research of the sun-synchronous orbit electron detectors[J]. J. Astron., 2012, 33(2):281-284. In Chinese (杨晓超, 王世金, 梁金宝, 等. 太阳同步轨道电子探测器的多方向设计研究[J]. 宇航学报, 2012, 33(2):281-284)
[13]	Armstrong T W, Colborn B L, Watts J W. Characteristics of Trapped Proton Anisotropy at Space Station Freedom Altitudes[R]. National Aeronautics and Space Administration, Huntsville, AL (USA). George C. Marshall Space Flight Center, 1990
[14]	Badhwar G D, Konradi A. Conversion of omnidirectional proton fluxes into a pitch angle distribution[J]. J. Spacecr. Rock., 1990, 27(3):350-352
[15]	Glauert S A, Richard B H. Calculation of pitch angle and energy diffusion coefficients with the PADIE code[J]. J. Geophys. Res.: Space Phys., 2005, 110(A4)
[16]	Kuznetsov N V, Nikolayeva N I. Empirical model of pitch-angle distributions of trapped protons on the inner boundary of the Earth's radiation belt[J]. Cosmic Res., 2012, 50(1):13-20
[17]	Søraas F, Aarsnes K, Lundblad J Å, Evans D S. Enhanced pitch angle scattering of protons at mid-latitudes during geomagnetic storms[J]. Phys. Chem. Earth Part C: Solar, Terr. Planet. Sci., 1999, 24(1):287-292
[18]	Leonov A, Cyamukungu M, Cabrera J, Leleux P, et al. Pitch angle distribution of trapped energetic protons and helium isotope nuclei measured along the Resurs-01 No.4 LEO satellite[C]//Annales Geophysicae. European Geosciences Union, 2005:2983-2987
[19]	Evans H, Daly E. Anisotropies in the low altitude radiation environment[J]. J. Brit. Interplanet. Soc., 1995, 48:149-151
[20]	Le Guiming. The anisotropic characteristics analysis of energetic proton intensity in the inner radiation belts at low height[J]. Manned Spacefl., 2006(03):62-64. In Chinese (乐贵明. 低高度内辐射带高能质子强度各向异性特征分析[J]. 载人航天, 2006(03):62-64)
[21]	Raben V. TIROS/NOAA Satellite Space Environment Monitor Data Archive Documentation: 1995 Update[R]. NOAA Technical Memrandum ERL SEL-86, 1995
[22]	Parker E N. Newtonian development of the dynamical properties of ionized gases of low density[J]. Phys. Rev., 1957, 107(4):924-933
[23]	Gannon J, Li X, Heynderickx D. Pitch angle distribution analysis of radiation belt electrons based on Combined Release and Radiation Effects Satellite Medium Electrons A data[J]. J. Geophys. Res.: Space Physics, 2007, 112(A5):A05212
[24]	Siegl M, Evans H D, Daly E J, et al. Inner belt anisotropy investigations based on the Standard Radiation Environment Monitor (SREM)[J]. Nucl. Sci., 2010, 57(4):2017-2023
[25]	Roederer J G. Dynamics of geomagnetically trapped radiation[M]//Physics and Chemistry in Space. Berlin: Springer, 1970
[26]	Selesnick R, Blake J. Relativistic electron drift shell splitting[J]. J. Geophys. Res., 2002, 107(A9):1265
