CAS-DIS数字电离层测高仪系统研制

王顺; 陈紫微; 张锋; 宫兆前; 方广有

doi:10.11728/cjss2014.06.849

CAS-DIS数字电离层测高仪系统研制

doi: 10.11728/cjss2014.06.849

中国科学院电磁辐射与探测技术重点实验室北京 100190

基金项目: 国家高技术研究发展计划项目资助(SS2012AA120505)

详细信息

通讯作者:
王顺,swang@mail.ie.ac.cn

中图分类号: P352
计量
- 文章访问数: 1297
- HTML全文浏览量: 61
- PDF下载量: 1276
- 被引次数: 0
出版历程
- 收稿日期: 2013-10-17
- 修回日期: 2014-05-19
- 刊出日期: 2014-11-15

A New Design for Digital Ionosonde

Key Laboratory of Electromagnetic Radiation and Sensing Technology, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190

摘要

摘要: 提出了将射频直接采样数字化的接收方式应用于数字电离层测高仪系统的设计方案, 并详细介绍了该方案在CAS-DIS (Chinese Academy of Sciences, Digital Ionosonde)电离层测高仪系统的应用, 给出了CAS-DIS电离层测高仪在中国武汉电离层探测标校试验场和武汉-北京斜向电离层探测系统中的实验结果. 观测结果表明, 采用本文提出的数字化方案设计的电离层测高仪系统性能优越, 且可以分别工作在垂直和斜向探测模式, 满足了电离层探测的多种应用需求.
- 数字电离层测高仪 /
- 数字下变频 /
- 脉冲压缩 /
- 相位编码 /
- 相干积分
Abstract: In this paper a new design for digital ionosonde is presented based on the concept of directly sampling in the RF domain, and the real time digital down-conversion processing is implemented in FPGA device, which improves the signals identity of I and Q, and enhances the dynamic range of the receiver. In addition, since the digital waveform generation in transmitting path, the digital down-conversion processing in receiving path, data pre-processing, and timing control functions of the whole system are integrated in one FPGA chip, which improved the flexibility of the ionosonde. To verify the design, a high quality digital ionosonde called CAS-DIS (Chinese Academy of Sciences, Digital Ionosonde) has been developed. This paper describes the details of CAS-DIS, its main features and testing results in the ionosphere detection, including in Wuhan ionospheric sounding and calibration station and Wuhan-Beijing oblique ionospheric sounding system, and the observations show that performance of the iononsonde using the proposed design is superior, and the ionosonde can operate in both vertical and oblique sounding mode, to meet a variety of applications in ionospheric detection.
- Digital ionosonde /
- Digital down-conversion /
- Pulse compression /
- Phase encoding /
- Coherent integration

HTML全文

参考文献(14)

[1]	Bibl K. Evolution of the ionosonde[J]. Ann. Geophys., 1998, 41:5-6
[2]	Zhu Zhengping, Ning Baiqi, Wan Weixing. Measurement and analysis of ionospheric virtual height with high precision[J]．Chin. J. Space. Sci., 2007. 27(3):204-210. In Chinese (朱正平, 宁百齐, 万卫星. 电离层虚高的高精度测量与分析[J]. 空间科学学报, 2007, 27(3):204-210)
[3]	Zhu Zhengping, Ning Baiqi, Sun Fenglou, Chen Kun. Study of passive receiving observation mode for ionospheric digital ionosonde[J]. Chin. J. Space Sci., 2009, 29(4):389-396. In Chinese (朱正平, 宁百齐, 孙奉娄, 陈锟. 电离层数字测高仪被动接收观测模式研究[J]. 空间科学学报, 2009, 29(4):389-396)
[4]	Zuccheretti E, Tutone G, Sciacca U. The new AIS-INGV digital ionosonde[J]. Ann. Geophysi., 2003, 46(4):647-659
[5]	Reinisch B W,Galkin I A, Khmyrov G M, et al. New Digisonde for research and monitoring applications[J]. Radio Sci., 2009, 44:1-15
[6]	Bassem R Mahafza. Radar System Analysis and Design Using Matlab[M]. London:Chapman and Hall/CRC, 2000:263
[7]	Bianchi C, Sciacca U, Zirizzotti A, Zuchheretti E, Baskaradas J A. Signal processing techniques for phase-coded HF-VHF radars[J]. Ann. Geophys., 2003, 46(4):697-705
[8]	Cabrera M A, Zuccheretti E, Ezquer R G, et al. Some considerations for different time domain signal processing in pulse compression radars[J]. Ann. Geophys., 2010, 53(5/6):1-11
[9]	Wang Shun, Chen Ziwei, Zhang Feng, et al. A method for separating O wave and X wave in digital ionosonde[J]. Chin. J. Space Sci., 2014, 34(2):186-193. In Chinese (王顺, 陈紫微, 张锋, 等. 一种数字电离层测高仪系统中O波与X波的分离方法[J]. 空间科学学报, 2014, 34(2):186-193
[10]	Devies K. Ionospheric Radio[M]. London: Peter Peregrinus Ltd., 1990:92
[11]	Huang X, Reinisch B W. Vertical electron density profiles from the digisonde network[J]. Adv. Space Res., 1996, 18:121-129
[12]	Pezzopane M, Scotto C. Automatic scalling of critical frequency f₀ F₂ and MUF(3000)F₂: A comparison between Autoscala and ARTIST 4.5 on Roma data[J]. Radio Sci., 2007, 42:RS4003
[13]	Carlo S. Elecron density profile calculation technique for Autoscala ionogram analysis[J]. Adv. Space Res., 2009, 44:756-766
[14]	Krasheninnikov M, Pezzopane C, Scotto C. Application of Autoscala to ionograms record by the AIS-Parus ionosonde[J]. Comput. Geosci., 2010, 36:628-635
