Application in predicting the geomagnetic storm with variation characteristics of cosmic ray
-
摘要: 利用宇宙线中子探测数据定性分析了地面宇宙线多台站之间的相互联系以及大磁暴与宇宙线之间的响应关系. 以Irkutsk和Oulu宇宙线台站为例, 运用小波去噪技术提高数据的稳定性. 结果表明, 相同世界时条件下, 两站宇宙线通量相关性在事件发生时较高; 而相同地方时条件下, 相关性则在平静期较高. 进一步采用相同地方时条件对不同宇宙线台站的通量在平静期和扰动期的相对变化进行分析, 选取2004年7月强地磁暴典型事例进行直观分析, 发现大地磁暴前Irkutsk和Oulu台站的宇宙线相对通量发生明显差异, 可以尝试作为强地磁暴宇宙线先兆特征. 通过对2001年3月至2005年5月的强磁暴和中强磁暴进行统计, 得到与强地磁暴相关的适当宇宙线相对差异阈值. 将得到的阈值对2005年9月至2011年12月所有强磁暴及中强磁暴进行验证, 总成功率达到87.5%, 误报率为35.7%, 结果较好.Abstract: An algorithm is introduced to use the cosmic ray neutron detector data to predict great geomagnetic storms. The connection between cosmic ray and great geomagnetic storms and the relationship between cosmic ray stations are qualitatively analyzed. The neutron detector data from Irkutsk and Oulu stations are employed and wavelet denoising technology is used to improve the stability of the data. It is found that under the same conditions of universal time the correlation of the two stations is higher than quiet days during geomagnetic disturbances, while it is contrary under the same local time. Thus the variation in disturbed time and quiet time can be used to predict geomagnetic storms. The algorithm is specifically used to analyze the geomagnetic storm events in July 2004. It is found that before geomagnetic storm, relative fluxes of cosmic rays of Irkutsk and Oulu station became different. It can be used as a precursor of strong geomagnetic storms. Statistics with all relative events during March 2001 to May 2005 support an appropriate threshold related to the relative difference of cosmic ray about strong geomagnetic storms. It is tested with all events during September 2005 to December 2011 with the threshold. The result turned out to be encouraging with the accuracy rate reaching 87.5% (7 out of 8) and false forecast rate reaching 35.7% (5 out of 14).
-
Key words:
- Cosmic ray /
- Geomagnetic storms /
- Forecast
-
[1] Adams J. Cosmic Ray Effects on Micro-Electronics (CREME)(Part IV)[R]. Naval Research Laboratory Memorandum Report 5901, 1986 [2] Zong Hai Ye. Cosmic ray observatory in China[J]. Astron. Res. Tech., 1989, S1:23-28 [3] Wang Jialong. Solar coronal mass ejection in space weather[J]. Prog. Geophys., 1999, 14(supp.):8-19. In Chinese (王家龙.日冕物质抛射elax——elax空间天气的扰动源[J]. 地球物理学进展, 1999, 14(增):8-19) [4] Lara A, Gopalswamy N, Caballero-Lopez R A, et al. Coronal mass ejections and galactic cosmic-ray modulation[J]. Astrophys. J., 2005, 625:441-450 [5] Dorman L I. Space dangerous phenomena and their possible prediction by cosmic rays[C]//Proceeding of 23rd International Cosmic Ray Conference. Calgary: International Union of Pure and Applied Physics, 1992: 699-702 [6] Kudela K. Cosmic rays in relation to space weather[J]. Space Sci. Rev., 2000, 93(1):153-174 [7] Xue Bingsen, Ye Zonghai, Gong Juhong. Preliminary attempt in prediction the geomagnetic storm with ground cosmic ray data[J]. Chin. J. Space Sci., 2007, 27(3):218-222. In Chinese (薛炳森,叶宗海,龚菊红. 利用地面宇宙线强度变化预报地磁暴方法初步 研究[J]. 空间科学学报, 2007, 27(3):218-222) [8] Kudela K. On the indices of cosmic ray variability[J]. Cosmic Ray Conf., 1999(6):448-460 [9] Dorman L I. Cosmic rays and space weather: effects on global climate change[J]. Ann. Geophys., 2012, 30:9-19 [10] Wang Xinlou. Wavelet denoising method analysis and Matlab simulation[J]. Indust. Cont. Comp., 2008, 21 (6): 55-56. In Chinese (王新楼. 小波去噪方法分析与Matlab仿真[J]. 工业控制计算机, 2008, 21(6):55-56) [11] Wu Hao, Lu Zhouxun. Speech recognition based on combined enhancement of Symlets wavelet and subspace[J]. Comp. Eng. Appl., 2011, 47(5):141-145. In Chinese (吴昊,鲁周迅. Symlets小波和子空间联合增强下的语音识别[J]. 计算机工程与应用, 2011, 47(5):141-145.) [12] Jin Tao, Gu Wenjing. Power system harmonic detection and restraining based on Symlet wavelet[J]. J. Fuzhou Univ.: Nat. Sci., 2012(6):769-774. In Chinese (金涛, 谷文静. 基于Symlet小波的电力系统谐波检测与治理[J]. 福州大学学报自然科学版, 2012(6):769-774) [13] Lu Minxiang, Zhang Guangqiong, Chen Yanrong. Automatic lung sound analysis using features extracted from wavelet coefficients[J]. J. Lunghwa Univ. Sci. Tech., 2012(6):101-114. In Chinese (吕敏详, 张光琼, 陈彦融. 使用小波系数所萃取的特征自动化分析肺音[J]. 龙华科技大学学报, 2012(6):101-114)
