Inversion Algorithms and Precision Analysis of ROPP
-
摘要: 介绍了ROPP反演软件中无线电掩星反演的算法与精度分析. 采用COSMIC卫星2008年1 月1日全天的附加相位数据, 反演得到折射率、温度、压强与湿度等参数, 并与CDAAC 相应结果进行对比. 实验结果表明, 在30km高度以下, 折射率、压强和湿度的相对 误差在2%以内, 温度误差不超过2K.Abstract: The unique combination of global coverage, high precision, high vertical resolution, long-term stability and all-weather viewing of radio occultation will enhance the data sets of numerical weather prediction and improve the precision of Numeric Weather Prediction (NWP). And data assimilation requires preprocessing of the raw radio signals into the bending angles and refractivity. Then the atmospheric parameters such as temperature, pressure and humidity can be retrieved through data variational assimilation. The procedures for processing of radio occultation data, especially several important steps are introduced. And comparative analysis between these results and those from CDAAC shows that below the altitude of 30km, the relative errors of refractivity, pressure and humidity are within 2% and the deviation of temperature is below 2K. The results are also compared with the data from ERA-interim model of ECMWF and similar conclusion is obtained.
-
Key words:
- Radio occultation inversion /
- Refractivity /
- Atmospheric parameters /
- ROPP
-
[1] Fischbach F F. A satellite method for pressure and temperature below 24km[J]. Bull. Am. Meteor. Soc., 1965, 46:528-532 [2] Rocken C, Anthes R, Exner M, et al. Analysis and validation of GPS/MET data in the neutral atmosphere[J]. J. Geophys. Res.:Atmos., 1997, 102(D25):29849-29866 [3] Gorbunov M E, Gurvich A, Bengtsson L. Advanced Algorithms of Inversion of GPS/MET Satellite Data and Their Application to Reconstruction of Temperature and Humidity[R]. Hamburg, Germany: Max-Planck-Institut für Meteorologie, 1996 [4] Mostert S, Koekemoer J A. The science and engineering payloads and experiments on SUNSAT[J]. Acta Astron., 1997, 41(4-10):401-411 [5] Gars S. The Radio Occultation Processing Package (ROPP) user guide. II: Forward model and 1D-Var modules[EB/OL]. [2015-03-15]. http://www.romsaf.org/romsaf_ropp_ug_1dvar.pdf [6] Tan Xingang, Sun Yueqiang, Bai Weihua, et al. ROPP software in inverting occultation data and accuracy analysis[J]. Sci. Tech. Eng., 2013, 13(20):5898-5902. In Chinese (谭鑫刚, 孙越强, 白伟华, 等. ROPP掩星数据反演软件及其精度分析[J]. 科学技术与工程, 2013, 13(20):5898-5902) [7] Gorbunov M E, Lauritsen K B, Rhodin A, et al. Radio holographic filtering, error estimation, and quality control of radio occultation data[J]. J. Geophys. Res., 2006, 111(D10), D10105 [8] Kuo Y H, Wee T K, Sokolovskiy S, et al. Inversion and error estimation of GPS radio occultation data[J]. J. Meteor. Soc. Japan. Ser. II, 2004, 82(1B):507-531 [9] Wang X, Lü D R. Comparative analysis of inversion methods of retrieving atmospheric profiles with GPS occultation measurements[J]. Chin. J. Geophys., 2007, 50(2):329-338 [10] Gorbunov M E. Ionospheric correction and statistical optimization of radio occultation data[J]. Radio Sci., 2002, 37(5):1084, doi: 10.1029/2000RS002370 -
