Process Optimization of Space Science Mission Concurrent Design
-
摘要: 为了对概念设计阶段空间科学任务协同设计过程进行合理规划, 减少设计反馈, 降低系统耦合度, 提出了设计结构矩阵(DSM)过程建模和遗传算法(GA) 过程优化算法. 该方法采用DSM对空间科学任务设计活动序列进行建模, 通过DSM描述设计活动间的信息依赖关系, DSM上三角之和代表该设计活动序列设计反馈次数; 将 DSM对应的设计活动序列视为染色体, 采用GA进行序列优化, 最小化设计反馈次数. 通过过程优化算法获取最佳设计活动序列, 优化设计过程, 降低系统耦合度. 空间科学任务实例分析结果表明, 该方法能够有效应用于空间科学任务协同设计的过程建模和过程优化, 指导设计过程的制定.Abstract: To optimize the process of space science mission concurrent design, an approach based on the Design Structure Matrix (DSM) modeling and Genetic Algorithm (GA) optimization method is proposed. In this approach, main design activities and dependencies relationship between the activities during the process of space science mission concurrent design are analyzed, and then the DSM model of the process is established. The design activities sequence corresponding to the DSM is treated as the chromosome and is optimized by the GA method. The optimal goal is to reduce the iterative times and to improve the parallel extent. A practical example of space science mission shows that the proposed approach can be applied to modeling and optimization of the process for space science concurrent design.
-
[1] Wang L, Shen W, Xie H. Collaborative conceptual design-state of the art and future trends[J]. Comp. Aided Design, 2002, 34:981-996 [2] Pei Xiaoqiang, Huang Hai. Multidisciplinary design optimization of satellite using collaborative optimization[J]. J. Astron., 2006, 27(5):1054-1058. In Chinese (裴晓强, 黄海. 协同优化在卫星多学科设计优 化中的初步应用[J]. 宇航学报, 2006, 27(5):1054-1058) [3] Tu Xinying, Yang Lei. Overview of satellite concurrent design center[J]. Spacecr. Eng., 2009, 18(1):83-88. In Chinese (涂歆滢, 杨雷. 国外航天器协同设计中心现状分析[J]. 航天器工程, 2009, 18(1):83-88) [4] Donald W M, Willian M P. Aerospace system design in NASA's collaborative engineering environment[J], Acta Astron., 2000, 47(2-9):255-264 [5] Karpati G, Martin J, Steiner M, et al. The Integrated Mission Design Center (IMDC) at NASA Goddard Space Flight Center[C]//Proceedings of the 2003 IEEE Aerospace Conference, Montana: IEEE Publications, 2003:3657-3667 [6] Meng Xin, Yang Zhen. The space science mission concurrent design platform[J]. e-Sci. Tech. Appl., 2011, 2(3):55-65. In Chinese (孟新, 杨震. 空间科学探测任务集同论证平台[J]. 科研信息化技术与应 用, 2011, 2(3):55-65) [7] Steward D V. The design structure system: a method for managing the design of complex systems[J]. IEEE Trans. Eng. Manag., 1981, 28(3):71-74 [8] Zhang Hanpeng, Qiu Wanhua. Product development two-factor risk model and simulation based on DSM[J]. J. Beijing Univ. Aeron. Astron., 2007, 33(5):627-630. In Chinese (张汉鹏, 邱菀华. 基于DSM优化的产品开发 两因素风险建模及仿真[J]. 北京航空航天大学学报, 2007, 33(5):627-630) [9] Mark S A, Annalisa L W. An application of the design structure matrix to integrated concurrent engineering[J]. Acta Astron., 2010, 66:937-949 [10] Smith R, Eppinger S D. Deciding between sequential and concurrent tasks in engineering design[J]. Conc. Eng.: Res. Appl., 1998, 6(1):16-26 [11] Yassine A A, Falkenburg D, Chelst K. Engineering design management: An information structure approach[J]. Int. J. Product. Res., 1999, 37(13):2957-2975 [12] Tang Dunbing, Qian Xiaoming, Liu Jiangang. Product Design and Development Based on Design Structure Matrix of DSM[M]. Beijing: Science Press, 2009. In Chinese (唐敦兵, 钱晓明, 刘建刚. 基于设计结构矩阵DSM的产品设 计与开发[M]. 北京: 科学出版社, 2009) [13] Xu Luning, Zhang Heming, Zhang Yongkang. DSM applied to planning process in cooperative design for complex products[J]. Eng. Sci., 2005, 7(6):41-44. In Chinese (徐路宁, 张和明, 张永康. 设计结构矩阵在 复杂产品协同设计过程的应用[J]. 中国工程科学, 2005, 7(6):41-44) [14] Xu Luning, Zhang Heming, Zhang Yongkang. Research on process reconfiguration with DSM in collaborative design[J]. Eng. Sci., 2006, 8(5):52-57. In Chinese (徐路宁, 张和明, 张永康. 协同设计中基于DSM过程重 构的研究[J]. 中国工程科学,2006, 8(5):52-57) [15] Wen Yuejie, Zhao Sheng. Method and application of DSM-based spacecraft parametric modeling[J]. Spacecr. Eng., 2012, 21(1):83-88. In Chinese (温跃杰, 赵晟. 基于DSM的航天器信息建模方法及 应用[J]. 航天器工程, 2012, 21(1):83-88) [16] Liu Ling, Hu Dengyu. Survey of optimal algorithm of design process model based on DSM[J]. Comp. Eng. Appl., 2009, 45(11):22-25. In Chinese (柳玲, 胡登宇, 李百战. 基于设计结构矩 阵的过程模型优化算法综述[J]. 计算机工程与应用, 2009, 45(11):22-25)
