一种巡视器惯性/视觉组合导航新方法

徐勇志; 宁晓琳

doi:10.11728/cjss2015.06.721

一种巡视器惯性/视觉组合导航新方法

doi: 10.11728/cjss2015.06.721

徐勇志^,,
宁晓琳

北京航空航天大学仪器科学与光电工程学院惯性技术国防重点实验室北京 100191

基金项目: 国家自然科学基金项目资助(61233005)

详细信息

通讯作者:
徐勇志,E-mail:buaaxyz@yeah.net

中图分类号: V412
计量
- 文章访问数: 1510
- HTML全文浏览量: 109
- PDF下载量: 1204
- 被引次数: 0
出版历程
- 收稿日期: 2014-09-16
- 修回日期: 2015-03-14
- 刊出日期: 2015-11-15

A New INS/VNS Integrated Navigation Method for Planetary Exploration Rover

Xu Yongzhi^,,
Ning Xiaolin

Science and Technology on Inertial Laboratory, School of Instrument Science and Opto-electronics Engineering, Beihang University, Beijing 100191

摘要

摘要: 在以运动参数误差为状态量、视觉导航与惯导导航相对运动参数差为观测量的传统惯性/视觉组合导航方法中, 为解决相对运动参数同时与前后两个时刻状态相关的问题, 采用将前一时刻位置和姿态误差增广到状态量中的方法, 并且假设增广的状态量为常值, 导致状态模型中引入了较大的误差. 基于真实位置、姿态建立观测量误差模型, 导致观测量同时与前后两个时刻的状态相关. 本文以惯导误差方程为状态模型, 采用四元数差形式的相对运动参数差作为观测量, 基于上一时刻组合导航位置、姿态估计值建立观测量误差模型, 实现了状态的增广, 并使得量测信息仅与当前时刻的位置误差和平台失准角相关, 克服了状态模型误差较大的问题. 月面仿真和地面模拟实验均表明, 该方法能够达到较高的位置和姿态估计精度.
- 惯导误差方程 /
- 视觉导航 /
- 组合导航 /
- 巡视器 /
- 卡尔曼滤波
Abstract: In traditional INS/VNS integrated navigation, the motion errors are usually used as the state vector, and relative motion errors between the inertial and vision navigation are used as the measurement. Since the relative motion is related to both the last and current states, traditional methods augment the position and attitude errors at the last time to the state vector to build the measurement model. The augmented states are considered as constant, and it generates new errors into the state model. Meanwhile, the measurement errors are analyzed based on ideal positions and attitudes at both the last and current time, which results in the measurement relationship with both the last and the current states. In this paper, a new INS/VNS model uses INS error equation as the state model, relative motion errors as the measurement, and attitude errors are described as quaternion error in the measurement model. The analyses of measurement errors are based on the integrated navigation estimation positions and attitudes at the last time, hence it does not need to augment the state, so the measurement only relates to the current state. The lunar surface simulation and experiment on the ground both show that the represented INS/VNS method can achieve high position and attitude estimation accuracy.
- INS error equation /
- Visual navigation /
- Integrated navigation /
- Exploration rover /
- Kalman filter

HTML全文

参考文献(18)

[1]	Titterton D H, Weston J L. Strapdown Inertial Navigation Technology (2nd Edition)[M]. UK: Institution of Engineering and Technology, 2004
[2]	Sun Shouming, Zheng Wei, Tang Guojian. Research on X-ray pulsars/SINS integrated navigation[J]. Chin. J. Space Sci., 2010, 30(6):579-583. In Chinese (孙守明, 郑伟, 汤国建. X射线脉冲星/SINS组合导航研究[J]. 空间科学学报, 2010, 30(6):579-583)
[3]	Lu W, Xiang Z, Liu J. High-performance visualodometry with two-stage local binocular BA and GPU[C]//Intelligent Vehicles Symposium (IV). Gold Coast, QLD: IEEE, 2013:1107-1112
[4]	Yao Rongbin, Ding Shangwen, Li Shengquan, et al. Measure for relative position and pose of RVD spacecraftsbased on trinocular vision method[J]. Chin. J. Space Sci., 2011, 31(4):527-33. In Chinese (姚荣斌, 丁尚文, 李生权, 等. 基于三目视觉的航天器交会对接位姿测量方法研究[J]. 空间科学学报, 2011, 31(4):527-533)
[5]	Wang Baofeng, Zhou Jianliang, Tang Geshi, et al. Research on visual localization method of lunar rover[J]. Sci. China: Inf. Sci., 2014, 44(4):452-60. In Chinese (王保丰, 周建亮, 唐歌实, 等. 嫦娥三号巡视器视觉定位方法[J]. 中国科学: 信息科学, 2014, 44(4):452-460)
[6]	Maimone M, Cheng Y, Matthies L. Two years of visualodometry on the Mars exploration rovers[J]. J. Field Robot., 2007, 24(3):169-186
[7]	Grotzinger J P, Crisp J, Vasavada A R, et al. Mars Science Laboratory mission and science investigation[J]. Space Sci. Rev., 2012, 170(1-4):5-56
[8]	Liu Chuankai, Wang Baofeng, Wang Jia, et al．Integrated INS and vision based orientation determination and positioning of CE-3 lunar rover[J]. J. Spacec. TT&C Tech., 2014, 33(3):250-257. In Chinese (刘传凯, 王保丰, 王镓, 等. 嫦娥三号巡视器的惯导与视觉组合定姿定位[J]. 飞行器测控学报, 2014, 33(3):250-257)
[9]	Mourikis A I, Trawny N, Roumeliotis S I, et al. Vision-aided inertial navigation for spacecraft entry, descent, and landing[J]. IEEE Trans. Robot., 2009, 25(2):264-280
[10]	Mourikis A I, Roumeliotis S I. A multi-state constraint Kalman filter for vision-aided inertial navigation[C]//Proceedings of International Conference on Robotics and Automation. Roma: IEEE, 2007:3565-3572
[11]	Tardif J P, George M, Laverne M, et al. A new approach to vision-aided inertial navigation[C]//2010 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS). Taipei: IEEE, 2010:4161-4168
[12]	Chilian A, Hirschmuller H, Gorner M. Multisensor data fusion for robust pose estimation of a six-legged walking robot[C]//2011 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS). San Francisco, CA: IEEE, 2011:2497-2504
[13]	Di Corato F, Innocenti M, Pollini L. An entropy-like approach to vision-aided inertial navigation[C]//Preprints of 18th International Federation of Automatic Control (IFAC)World Congress. Milano, Italy: IFAC, 2011: 13789-13794
[14]	Roumeliotis S I, Johnson A E, Montgomery J F. Augmen-ting Inertial Navigation with Image-Based Motion Estimation[C]//Proceedings of the IEEE International Conference on Robotics and Automation. Washington: IEEE, 2002:4326-4333
[15]	Badino H, Yamamoto A, Kanade T. Visual odometry by multi-frame feature integration[C]//IEEE International Conference on Computer Vision for Autonomous Driving. Sydney, Australia: IEEE, 2013
[16]	Olson C F, Matthies L H, Schoppers M, et al. Rover navigation using stereo ego-motion[J]. Robot. Auton. Syst., 2003, 43(4):215-229
[17]	Geiger A, Lenz P, Urtasun R. Are we ready for Autono-mous Driving? The KITTI Vision Benchmark Suite[C]//IEEE Conference on Computer Vision and Pattern Recognition (CVPR). Providence, RI: IEEE, 2012:3354-3361
[18]	Geiger A, Lenz P, Stiller C, et al. Vision meets robotics:The KITTI dataset[J]. Int. J. Robot. Res., 2013, 11: 1231-1237
