Post-Newtonian Model of High-precision Inertial Navigation in Space ormalsize
-
摘要: 将广义相对论中的惯性系概念引入惯性导航, 根据后牛顿引力理论, 提出一种 新的航天器惯性导航模型.以地球周围的测地运动物体为随动惯性参考系, 利 用航天器机载加速度计测量的比力和引力梯度作为观测量, 通过求解航天器 相对于随动惯性系的状态量达到导航定位目的.该方法用于高轨卫星时可以 获得较高的测量精度, 误差主要来源于惯性元件的测量以及随动惯性系测地轨 迹设计, 不存在现有惯性导航模型中随时间而累积的误差.Abstract: The concept of inertial system in general theory of relativity is introduced to inertial navigation using post-Newtonian theory of gravity, and a new model of inertial navigation of spacecraft is proposed. It utilizes the geodesic motion objects around the Earth as the follow-up inertial frame of reference. The special force and gravity gradient measured by accelerometers in spacecraft are employed as the observable, and navigation can be realized by solving the status of the spacecraft relative to the follow-up inertial frame. The method used for high orbit satellite can obtain high measurement accuracy, and its errors mainly come from the measurement accuracy of inertial components as well as the design of geodesic trajectory. There is no error accumulated over time which has existed in current inertial navigation model.
-
[1] LUO Ziren, ZHONG Min, BIAN Xing, et al. Mapping Earth's gravity in space: review and future perspective[J]. Adv. Mech., 2014, 44:291-336 (罗子人, 钟敏, 边星, 等. 地球重力场空间探测: 回顾与展望[J]. 力学进展, 2014, 44:291-336) [2] VISSER P.Exploring the possibilities for star-tracker assisted calibration of the six individual GOCE accelerometers[J]. J. Geod., 2008, 82(10):591-600 [3] VISSER P. GOCE gradiometer: estimation of biases and scale factors of all six individual accelerometers by precise orbit determination[J]. J. Geod., 2009, 83(1):69-85 [4] BAI Yanzheng, TIAN Wei, ZHOU Zebing, et al. High-precision space-borne accelerometer and its applications[J]. Chin. J. Space Sci., 2010, 30(6):601-606 (白彦峥, 田蔚, 周泽兵, 等.高精度空间加速度计及其应用[J].空间科学学报, 2010, 30(6):601-606) [5] EVERITT C W F, DEBRA D B, PARKINSON B W, et al. Gravity probe B: final results of a space experimentto test general relativity[J]. Phys. Rev. Lett., 2011, 106(22): 221101 [6] SOFFEl M H, KLIONER S A, PETIT G, et al. The IAU 2000 resolutions for astrometry, celestial mechanics, and metrology in the relativistic framework: Explanatory supplement[J]. Astron. J., 2003, 126:2687-2706 [7] FEI Baojun, PAN Gaotian, XIAO Yu, et al. Motion equation of satellite in XNAV[J]. Chin. J. Space Sci., 2011, 31(2):254-259 (费保俊, 潘高田, 肖昱, 等.X射线脉冲星自主导 航的卫星运动方程[J].空间科学学报, 2011, 31(2):254-259) [8] FEI Baojun. Application of Relativity in Modern Navigation[M]. 2nd ed. Beijing: National Defense Industry Press, 2015:236-239 (费保俊.相对论在现代导航中的应用[M].2版. 北京: 国防工业出版社, 2015:236-239) [9] ZORN A H. A merging of system technologies: all-accelerometer inertial navigation and gravity gradiometry[C]//Proceedings of IEEE Position, Location, and Navigation Symposium. Palm Springs: IEEE, 2002:66-73 [10] LIU Fengming, ZHAO Lin, LIU Fanming. Design of all-accelerometer-based inertial navigation and gravity gradient measurement[J]. J. Chin. Inert. Technol., 2009, 17(2):132-135 (刘凤鸣, 赵琳, 刘繁明. 全加速度计惯性 导航与重力梯度测量系统设计[J]. 中国惯性技术学报, 2009, 17(2):132-136)
