基于RVE模型的空间天线结构热稳定性优化设计与热变形分析

马健; 肖刚; 肖鹏飞; 蔡亚宁; 冉治国

doi:10.11728/cjss2016.03.386

基于RVE模型的空间天线结构热稳定性优化设计与热变形分析

doi: 10.11728/cjss2016.03.386

1.
北京空间飞行器总体设计部北京 100094
2.
北京机械设备研究所北京 100854

基金项目: 国家自然科学基金项目资助(2011CB606105)

详细信息

作者简介:
马健,E-mail:majian0508@163.com

中图分类号: V414
计量
- 文章访问数: 868
- HTML全文浏览量: 36
- PDF下载量: 927
- 被引次数: 0
出版历程
- 收稿日期: 2015-04-08
- 修回日期: 2016-01-05
- 刊出日期: 2016-05-15

Thermal Stability Optimization Design and Thermal Deformation Analysis of Space Antenna Structure Based on Representative Volume Element Method

1.
Beijing Institute of Spacecraft System Engineering, Beijing 100094
2.
Beijing Institute of Mechanical Equipment, Beijing 100854

摘要

摘要: 空间环境温度变化会使空间天线支撑结构产生热变形,影响其使用性能,因此进行天线热稳定性设计及热变形分析具有重要的意义.基于代表性体积单元(Representative Volume Element,RVE)方法对空间天线结构进行热稳定性设计与热变形分析.通过建立纤维随机分布并含有材料孔隙的RVE,得到纤维热膨胀系数.对M40/TDE85单向复合材料的热膨胀性能进行实验测试,计算结果与测试结果吻合良好,验证了RVE模型的正确性与准确性.建立了复合材料圆管参数化模型,根据计算得到的热膨胀系数及优化算法,对天线支撑结构进行热稳定性优化设计,并对优化后的天线结构进行热致变形分析,结果表明优化后的结构具有很高的热稳定性.
- 空间天线 /
- 代表性体积单元 /
- 热稳定性 /
- 优化设计 /
- 热致变形
Abstract: High temperature gradient and severe temperature variation in spacecraft will induce spacecraft thermal expansion and deformation.Thermally induced deflections of reflector have much effect on the electric performance of antenna on satellite that has a great limit in surface precision. Obviously,the research of in-orbit temperature and thermal distortion for antennas on satellites is very important.In this paper,the thermal stability of space antenna structure is designed and analyzed by RVE (Representative Volume Element) method.The Coefficient of Thermal Expansion (CTE) is predicted by RVE mode and experiment is also carried out.Comparison between the predicted results and experimental data verifies the rightness of this model.Optimization models for space antenna structure are created,and both the longitudinal and transverse CTE are considered. Analyzed results show that this optimized support structure and the whole antenna have an excellent thermal dimensional stability.
- Space antenna structure /
- Representative Volume Element (RVE) /
- Thermal stability /
- Optimization /
- Thermal deformation

HTML全文

参考文献(15)

[1]	YUAN Jiajun. Design and Analysis of Satellite Structures[M]. Beijing:China Astronautic Press, 2004(袁家军. 卫星结构设计与分析[M]. 北京:中国宇航出版社, 2004)
[2]	LIU Zhenyu, FENG Jisheng, ZHANG Qingjun. Optimization design for coefficient of thermal expansion of a space deployable truss[J]. Spacecraft Eng., 2012, 21(3):35-40(刘振玉, 冯纪生, 张庆君. 一种空间可展开桁架结构杆件热膨胀系数的优化设计[J]. 航天器工程, 2012, 21(3):35-40)
[3]	LIU Guoqing, RUAN Jianhua, LUO Wenbo, et al. Research on thermal deformation analysis and test verification method for spacecraft high-stability structure[J]. Spacecraft Eng., 2014, 23(2):64-70(刘国青, 阮剑华, 罗文波, 等. 航天器高稳定结构热变形分析与试验验证方法研究[J]. 航天器工程, 2014, 23(2):64-70)
[4]	MA Huitao LI Jindong. Integrated thermal-structural analytical technology for space structure with large-scale and complicated construction[J]. J. Astron., 2008, 29(2):413-419(麻慧涛, 李劲东. 大型复杂空间结构机-热集成分析技术研究[J]. 宇航学报, 2008, 29(2):413-419)
[5]	ISLAM M D R, SJ"OLIND S G, PRAMILA A. Finite ele-ment analysis of linear thermal expansion coefficients of unidirectional cracked composites[J]. J. Compos. Mater., 2001, 35:1762-76
[6]	DAVIS H. Microstructure organization in para-aramid fibers[J]. Textile Res. J., 2000, 70(11):945-950
[7]	RUPNOWSKI P, GENTZA M, SUTTERB J K, et al. An evaluation on the elastic properties and thermal expansion coefficients of medium and high modulus graphite fi-bers[J]. Composites: A, 2005, 36(3):327-38
[8]	SHEN Y L. Thermal expansion of metal-ceramic composites:a three dimensional analysis[J]. Mater. Sci. Eng., 1998, 252:269-275
[9]	MOHAJERJASBI S. Prediction for coefficients of thermal expansion of 3-D braided composites[C]//37th Structure, Structural Dynamics and Materials Conference. Salt Lake City:AIAA, 1996:1812-1817
[10]	MITAL W K, MURTHY P L N. Characterizing the properties of a C/SiC composite using micromechanics ana-lysis[C]//19th AIAA Applied Aerodynamics Conference, 2001. DOI: 10.2514/6.2001-1363
[11]	FAROOQU J K, SHEIKH M A. Modeling the composite unit cell for predicting thermal transport[C]//47th AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics, and Materials. Newport, Rhode Island:AIAA, 2006. DOI: 10.2514/6.2006-2197
[12]	LUA J, SANKAR J, PAI D. A four cell decomposition model for unbalanced woven fabric composites subjected to thermal-mechanical loading[C]//47th AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics, and Materials Conference, Structures, Structural Dynamics, and Materials and Co-located Confe-rences. Newport, Rhode Island:AIAA, 2006:1-22
[13]	WONGSTO A, LI S. Micromechanical finite element analysis of unidirectional fiber reinforced composites with fibres distributed at random over the transverse cross section[J]. Composites:A, 2005, 36(9):1246-1266
[14]	KRACH A, ADVANI S G. Influence of void shaper, void volume and matrix anisotropy on effective thermal conductivity of a three phase composite[J]. J. Compos. Mater., 1996, 30:933-946
[15]	MORENA L C, JAMES K V, BECK J. An introduction to the RADARSAT-2 mission[J]. Canada J. Remote Sens., 2004, 30(3):221-234
