CsI(Eu)晶体空间生长地面实验

刘锦峰; 许桂生; 朱秀; 田彦峰

doi:10.11728/cjss2016.04.428

CsI(Eu)晶体空间生长地面实验

doi: 10.11728/cjss2016.04.428 cstr: 32142.14.cjss2016.04.428

1.
中国科学院上海硅酸盐研究所中国科学院透明光功能无机材料重点实验室上海 201899
2.
中国科学院大学北京 100049

基金项目: 中国载人空间站工程项目资助（TGJZ800-2-RW024）

详细信息

作者简介:

许桂生,gshxu@mail.sic.ac.cn

中图分类号: V524
计量
- 文章访问数: 2043
- HTML全文浏览量: 282
- PDF下载量: 877
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2015-11-10
- 修回日期: 2016-05-11
- 刊出日期: 2016-07-15

Ground Experiment of CsI(Eu) Single Crystal Space Growth

1.
Key Laboratory of Transparent Opto-Functional Advanced Inorganic Materials, Shanghai Institute of Ceramics, Chinese Academy of Sciences, Shanghai 201899
2.
University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 人工晶体在高技术领域具有十分重要的应用.在多组分晶体生长过程中，由于分凝的存在，会导致成分沿晶体生长方向产生变化，从而影响到晶体性能的均匀性，对应用产生不利影响.为研究微重力对多组分晶体分凝的影响，利用天宫二号卫星进行空间晶体生长实验.结合晶体生长特性和天宫二号综合材料实验装置的技术条件，确定以铕掺杂CsI晶体为研究对象.在地面研制阶段，CsI（Eu）晶体样品顺利通过力学环模试验，并在地面实验中生长出质量较高的CsI晶体，样品中存在明显的组分分凝.
- 组分分凝 /
- 微重力 /
- CsI(Eu)晶体
Abstract: Single crystals play quite an important role in material applications. In the process of single crystals growth, ingredients of crystals vary along its growth orientation because of the segregation. Consequently, uniformity of the crystal may be affected, which add to the disadvantage of its application. In order to study the influence of microgravity on the segregation of multicomponent crystal, the crystal growth through the platform of Tiangong-2 is planned. Considering the growth properties and the condition of Tiangong-2, Eu²⁺ doped CsI is chosen as the study object. The inner structure of quartz ampoule is designed, which passes the vibration experiment successfully. Moreover, the high quality single crystal is grown in the laboratory, and the concentration segregation is found obviously in the specimen.
- Concentration segregation /
- Microgravity /
- CsI(Eu) single crystal

HTML全文

参考文献(18)

[1]	XU Guisheng, YANG Danfeng, LIU Jinfeng, et al. The growth status of relaxor-based ferroelectric crystals and their development trends[J]. J. Adv. Dielect., 2014, 4:1450002
[2]	XU Guisheng, WANG Xiaofeng, YANG Danfeng, et al. Peculiar temperature aging effects on the piezoelectric constant of Pb(Mg_1/3Nb_2/3)O₃-PbTiO₃ single crystal near the morphotropic phase boundary[J]. Appl. Phys. Lett., 2005, 86:032902
[3]	LIU Ying, XU Guisheng, LIU Jinfeng, et al. Dielec-tric, piezoelectric properties of MnO₂-doped (K_0.5Na_0.5)NbO₃-0.05LiNbO₃ crystal grown by flux-Bridgman method[J]. J. Alloys. Comp., 2014, 603:95-99
[4]	WANG Xian, ZHANG Haiwu, LIN Di, et al. An effective growth method to improve the homogeneity of relaxor ferroelectric single crystal Pb(In_1/2Nb_1/3)O₃-Pb(Mg_1/3Nb_2/3)O₃-PbTiO₃[J]. Cryst. Res. Technol., 2014, 49(2/3):122-128
[5]	JIE Wanqi. Solute partition and segregation in Bridgman growth process[J]. Mat. China, 2009, 28(2):19-25
[6]	CHEN Kai, XUGuisheng, YANG Danfeng, et al. Dielectric and piezoelectric properties of leadfree 0.95(K_0.5Na_0.5)NbO₃~0.05LiNbO₃ crystals grown by the Bridgman method[J]. J. Appl. Phys., 2007, 101:044103
[7]	REN Guohao, CHEN Xiaofeng, LI Huaying, et al. Non-uniformity of luminescence of φ300mm CsI(Tl) scintillation crystals and its growth interface[J]. J. Syn. Cryst., 2015, 44(12):3375-3378
[8]	YANG Fan, ZHAO Beijun, ZHU Shifu, et al. Study of In segregation phenomena duringAgGa1-xIn_xSe₂ crystal growth[J]. J. Xinjiang Univ. (Nat. Sci. Ed.), 2009, 26(1):78-81
[9]	CHEN Wanchun. Research of crystal growth in space under microgravity[J]. J. Chin. Ceram. Soc., 1995, 23(4):421-429
[10]	LI Kai, XU Ziliang. Effect of microgravity environment and externally applied magnetic field on dopant segregation of crystal growth[J]. Adv. Mech., 1999, 29(2):221-231
[11]	CHEN Wanchun, SONG Youting. Progresses in crystal growth under microgravity in space[J]. Sci. Guide, 2012, 30(2):46-57
[12]	YUE J T, VOLTMER F W. Influence of gravity-free solidification on solute microsegregation[J]. J. Cryst. Growth, 1975, 29:329-341
[13]	LI Yijun, HUANG Liangfu, TAN Xiaochen, et al. Bridgman growth of HgCdTe under microgravity in space[J]. Chin. Space Sci. Tech., 1997, 4:49-55(李毅军, 黄良甫, 谈晓臣, 等. 空间微重力条件下碲镉汞晶体的布里支曼生长[J]. 中国空间科学技术, 1997, 4:49-55)
[14]	YAKOVLEV V, TREFILOVA L, KARNAUKHOVA A, OVCHARENKO N. Energy transfer mechanism in CsI:Eu crystal[J]. J. Lumin., 2014, 148:274-276
[15]	GEKTIN A, SHIRAN N, VASYUKOV S, et al. Europium emission centers in CsI:Eu crystal[J]. Opt. Mater., 2013, 35:2613-2617
[16]	YAKOVLEV V, TREFILOVA L, KARNAUKHOVA A, OVCHARENKO N. Luminescence of Eu²⁺-v_c^- dipoles and their associates in CsI: Eu crystals[J]. J. Lumin., 2012, 132:2476-2478
[17]	YAKOVLEV V, TREFILOVA L, KARNAUKHOVA A, OVCHARENKO N. Spectral-kinetics properties of activator emission centers in CsI:Eu[J]. J. Lumin., 2013, 144:146-148
[18]	LEBEDYNSKIY A M, SHIRAN N V, GEKTIN A V, et al. Structure and luminescence of Cs:Eu columnar fi-lms[J]. J. Appl. Spectrosc., 2012, 79:583-588
