Simulation and Ground Experiment Investigation of Material Experimental Furnace in Space
-
摘要: 空间材料实验炉的温度分布对空间材料制备至关重要.通过对用于天宫二号空间实验室材料实验炉的物理模型进行合理简化,建立了三维传热数值计算模型,测量了实验炉材料的热物性参数,并根据地面试验工况进行模拟热分析计算,其结果能够很好地与地面试验结果吻合.采用模拟计算的方法分析样品物性参数对炉膛和样品中温度分布的影响,对实验炉的隔热部件进行优化设计,进而对炉体外表面温度进行了预测.数值仿真计算弥补了实验中测温点不足的问题,有助于进一步了解样品的温度分布,同时为实验炉隔热优化设计和安全运行提供了依据.Abstract: The temperature distribution of material experimental furnace is critical to materials preparation and the safety operation of furnace in space. For example, it directly affect the growth process of crystals. On the basis of reasonable simplification of the physical model of material experimental furnace that will be carried by Tiangong-2, a 3D heat transfer numerical model is established, and thermophysical parameters of the furnace material are measured. Using the heat transfer model, the thermophysical parameters is simulated. The simulation results coincide well with the ground experimental results. The influence of specimen thermophysical parameters on the furnace and specimen temperature distribution is analyzed by simulation. Moreover, an optimal design is carried out for heat insulation parts of the furnace, and surface temperature distribution of the furnace is predicted. The inadequacy of temperature measuring point can be compensated by the simulating calculation. The simulation can help to obtain the specimen temperature distribution, and can provide foundation for optimal design of the furnace heat insulation and its safe operation.
-
[1] LU Jun, BAI Bofeng, GUO Liejin. Thermosolutal convection during the vertical Bridgman directional solidification of binary alloy I-prototype furnace[J]. J. Cryst. Growth, 2008, 37(3):561-567 [2] MIN Guirong, GUO Shun. Spacecraft Thermal Control Technologies[M]. Beijing: Science Press, 1998(闵桂荣, 郭舜. 航天器热控制[M]. 北京: 科学出版社, 1998) [3] ZHANG Jiayu, WANG Huanyu, ZHANG Chengmo, et al. Thermal control design and Simulation calculation of the Alpha Particle X-ray spectrometer[J]. Chin. J. Space Sci., 2013, 33(6):672-677(张家宇, 王焕玉, 张承模, 等. 粒子激发X射线谱仪的热设计和热仿真计算[J]. 空间科学学报, 2013, 33(6):672-677) [4] JI Chaoyue, REN Jianxun, LIANG Xingang, et al. Numerical correlation of convections in an enclosure under micro-gravity and terrestrial gravity[J]. Space Med. Med. Eng., 2000, 13(4):281-285 [5] LIU Yunlong, LIANG Xingang, REN Jianxun, et al. Ground thermal scale modeling of radiation-convective heat and mass transfer system in microgravity environment[J]. Chin Space Sci. Technol., 1997, 27(2):8-15 [6] JI Yan, LIU Qiusheng, ZHU Zhiqiang. Numerical simulation of thermocapillary convection in an evaporating liquid layer under microgravity condition[J]. Chin. J. Space Sci., 2008, 28(4):350-355(纪岩, 刘秋生, 朱志强. 微重力环境下蒸发液层热毛细对流的数值模拟[J]. 空间科学学报, 2008, 28(4):350-355) [7] LI Jindong, SHAO Dongbin. Numeric analysis on a micro-Gravity heat convection for a spacecraft pressured cabin[J]. J. Eng. Thermophys., 2002, 23(3):333-335
