Experimental Facility for Ignition and Burning of Solid Materials aboard SJ-10 Satellite
-
摘要: 为对微重力条件下固体材料着火和火焰传播特性进行研究，研制了实践十号（SJ-10）卫星固体材料燃烧实验装置.利用空间高真空条件，采用实验段内气体环境更新和控制技术，实现了在有限实验空间内对多个实验样品进行研究，并提供准确可控的实验环境条件（氧气浓度和气流速度）.通过地面试验验证，该装置可通过实验样品、氧气浓度、气流速度、点火方式等实验参数的灵活组合，实现空间实验机会的充分利用和预定科学目标.Abstract: Ignition of solid fuels and subsequent transition to flame spread is of fundamental interest and practical importance for fire safety. Motivated primarily by fire safety of spacecraft, a renewed interest in microgravity flame spread over solid materials has arisen. With few exceptions, however, research on microgravity flame spread has been focused on thermally thin fuels due to the constraint on available test time. Till now still little is known about flame spread over thick fuels in microgravity. A facility is described, which has been designed to examine the ignition and burning behaviors of thick solids onboard SJ-10 satellite of China. The combustion experiments will be conducted with varying low velocity flow and varying ambient oxygen concentration. Other variables to be tested are the effects of fuel type and geometry. The important observations from space experiments include flame behavior and appearance as a function of oxygen concentration and flow velocity, temperature variation in gas and solid phases, and flame spread rate. The research will focus on:(i) finding a limiting oxygen concentration or flow velocity where a flame will propagate in microgravity, and comparing the limits with those on Earth, (ii) evaluating effects of flow velocity, oxygen percentage and material shape on flame spread modes, and (iii) improving the prediction model of solid material combustion.
-
Key words:
- Microgravity experiment /
- Combustion /
- Solid material /
- SJ-10 satellite
-
[1] ZHANG Xia. Progress in fire safety research for manned spacecraft[J]. Adv. Mech., 2006, 35(1):100-115(张夏. 载人航天器火灾安全研究进展[J]. 力学进展, 2006, 35(1):100-115) [2] KUMAR A, SHIH H Y, T'IEN J S. A comparison of extinction limits and spreading rates in opposed and concurrent spreading flames over thin solids[J]. Combust. Flame, 2003, 132:667-677 [3] FRIEDMAN R. Fire safety in spacecraft[J]. Fire Mater., 1996, 20:235-243 [4] FRIEDMAN R, ROSS H D. Combustion technology and fire safety for human-crew space missions[C]//Microgra-vity Combustion: Fire in Free Fall. San Diego: Academic Press, 2001:525-562 [5] FRIENDS R, URBAN D L. Progress in Fire Detection and Suppressions Technology for Future Space Mis-sions: AIAA-2000-5251[R]. Long Beach: AIAA, 2000 [6] OLSON S L, MILLER F J, WICHMAN I S. Characteri-zing fingering flamelets using the logistic model[J]. Combust. Theory Model, 2006, 10:323-347 [7] LONG Y, WICHMAN I S. Theoretical and numerical analysis of a spreading opposed-flow diffusion flame[J]. Proc. Roy. Soc., 2009, 465:3209-3238 [8] WANG Shuangfeng, XIAO Yuan. A ground-based experimental method for solid material flammability simulation in microgravity environment[J]. Manned Spacef., 2012, 18(4):70-74(王双峰, 肖原. 微重力下固体材料燃烧特性的地面实验模拟方法研究[J]. 载人航天, 2012, 18(4):70-74 [9] DU Wenfeng, HU Wenrui. Effect of pressure and radiation on the propagation of flame along a thin fuel surface under microgravity environment[J]. Sci. China: E, 2003, 33(5):405-412(杜文锋, 胡文瑞. 微重力下环境压力和辐射再吸收对火焰沿薄燃料表面传播的影响[J]. 中国科学(E辑), 2003, 33(5):405-412) [10] OLSON S L, MILLER F J, JAHANGIRIAN S, WHICHMAN I S. Flame spread over thin fuels in actual and simu-lated microgravity conditions[J]. Combust. Flame, 2009, 156(6):1214-1226 [11] WANG Shuangfeng, YIN Yongli. Microgravity smoldering combustion experiments aboard the China recoverable satellite SJ-8[J]. Chin. J. Space Sci., 2008, 28(1) 6-27(王双峰, 尹永利. 卫星搭载聚氨酯泡沫闷烧实验[J]. 空间科学学报, 2008, 28:6-27) [12] HU W R, Zhao J F, Long M, et al. Space program SJ-10 of microgravity research[J]. Microgravity Sci. Technol., 2014, 26:159-169 -
-
