空间在轨流体输运稳定性落塔实验

陈小亮; 高源; 刘秋生

doi:10.11728/cjss2016.04.542

空间在轨流体输运稳定性落塔实验

doi: 10.11728/cjss2016.04.542

中国科学院力学研究所北京 100190

基金项目: 国家自然科学基金项目（11532015）和国家高技术研究发展计划项目（2014AA7045038）共同资助

详细信息

通讯作者:
刘秋生,E-mail:liu@imech.ac.cn

中图分类号: V524
计量
- 文章访问数: 1063
- HTML全文浏览量: 84
- PDF下载量: 1018
- 被引次数: 0
出版历程
- 收稿日期: 2015-11-10
- 修回日期: 2016-05-26
- 刊出日期: 2016-07-15

Drop Tower Experiment Study of Fluid Transport with Free Surface in Spacecraft

Key Laboratory of Microgravity, Institute of Mechanics, Chinese Academy of Sciences, Beijing 100190

摘要

摘要: 空间流体管理是微重力流体科学的重要研究方向之一，而有外力驱动的开口流道毛细流动界面稳定性研究是其重要的内容.设计研制了一种微重力双流道流体输运实验装置，采用的两个流道分别为截面相同的对称内角和非对称内角，并有相同的开口长度，在百米微重力落塔进行了10次双舱实验.通过分析不同流量下的液面特性，判定流动的类别，将流动形态分为亚临界、临界和超临界三种，确定了两个流道的临界流量，并对两个流道毛细流动的特征进行了比较.
- 开口流道 /
- 界面稳定性 /
- 临界流量 /
- 落塔实验
Abstract: With the development of the space industry, space liquid management become one of the important techniques in realizing in-orbit refueling of the spacecrafts, and free surface flow stability is the critical problem in this field. The experiment set-up is designed for microgravity fluid transport study with two channels. In the experiments, symmetrical channel and asymmetrical channel with identical open length for comparison are used, and 10 experiments in the drop tower of Chinese Academy of Sciences are performed. By analyzing the free surface characters, it is found that there exist three typical flow patterns:subcritical, supercritical and critical. Meanwhile, the critical flow rate is obtained. Finally, the free surface flow characteritics of two different channels are compared.
- Open channel /
- Capillary flow /
- Surface flow stability /
- Critical flow rate

HTML全文

参考文献(14)

[1]	ROLLINS J R, GROVE R K, JAEKLE D E. Twenty-three years of surface tension propellant management system design, development, manufacture, test, and operation[J]. AIAA J., 1985, 9:17-177
[2]	JAEKLE D E. Propellant management device conceptual design and analysis: Vanes[C]//27th Joint Propulsion Conference, Joint Propulsion Conferences. Sacramento:AIAA, 1991
[3]	ROSENDAHL U, OHLHOFF A, DREYER M E, et al. Investigation of forced liquid flows in open capillary channels[J]. Microgravity Sci. Technol., 2002, 4:53-60
[4]	HAEBERLE S, ZENGERLE R. Microfluidic platforms for lab-on-a-chip applications[J]. Lab Chip, 2007, 7:1094-1110
[5]	CONRATH M, CANFILD P J, BRONOWICKI P M, et al. Capillary channel flow experiments aboard the international space station[J]. Phys. Rev., 2013, 88:1-8
[6]	HAAKE D, ROSENDAHL U, OHLHOFF A, et al. Flow rate limitation in open capillary channel flows[J]. Ann. N. Y. Acad. Sci., 2006, 1077(1):443-458
[7]	KLATTE J. Capillary Flow and Collapse in Wedge-Shaped Channels. Bremen[D]. Bremen: University of Bremen, 2011
[8]	WEI Xingyue. Research on Flow Characteristics in the Process of Tank Propellant Management of Spacecraft under Microgravity Conditions[D]. Changsha: National University of Defense Technology, 2013(魏月兴. 微重力条件下航天器贮箱推进剂管理过程中的流动特性研究[D]. 长沙: 国防科学技术大学, 2013)
[9]	ROSENDAHL U, OHLHOFF A, DREYER M E. Choked flows in open capillary channels: Theory, experiment and computations[J]. J. Fluid Mech., 2004, 518:187-214
[10]	ROSENDAHL U, GRAH A, DREYER M E. Convective dominated flows in open capillary channels[J]. Phys. Fluids, 2010, 22:1-13
[11]	CANFILD P J, BRONOWICKI P M, CHEN Y, et al. The capillary channel flow experiments on the international space station: Experiment set-up and fist results[J]. Exp. Fluids, 2013, 54:1-14
[12]	HAAKE D, KLATTE J, GRAH A, et al. Flow rate limitation of steady convective dominated open capillary channel flows through a groove[J]. Microgravity Sci. Technol., 2010, 22:129-138
[13]	GRAH A, DREYER M E. Dynamic stability analysis for capillary channel flow: One-dimensional and three-dimensional computations and the equivalent steady state technique[J]. Phys. Fluids, 2010, 22:1-11
[14]	BRONOWICKI P, CANFILD P, GRAH A, DREYER M. Free surfaces in open capillary channels-parallel plates[J]. Phys. Fluids, 2015, 27:1-21
