Survey on the Magnetic Structure of the Neutral Sheets in Earth's Magnetotail

XIAO Chao SHEN Chao CHENG Guosheng ZHANG Hua ZHANG Ting CARR C M

XIAO Chao, SHEN Chao, CHENG Guosheng, ZHANG Hua, ZHANG Ting, CARR C M. Survey on the Magnetic Structure of the Neutral Sheets in Earth's Magnetotail[J]. 空间科学学报, 2016, 36(6): 837-848. doi: 10.11728/cjss2016.06.837
引用本文: XIAO Chao, SHEN Chao, CHENG Guosheng, ZHANG Hua, ZHANG Ting, CARR C M. Survey on the Magnetic Structure of the Neutral Sheets in Earth's Magnetotail[J]. 空间科学学报, 2016, 36(6): 837-848. doi: 10.11728/cjss2016.06.837
XIAO Chao, SHEN Chao, CHENG Guosheng, ZHANG Hua, ZHANG Ting, CARR C M. Survey on the Magnetic Structure of the Neutral Sheets in Earth's Magnetotail[J]. Chinese Journal of Space Science, 2016, 36(6): 837-848. doi: 10.11728/cjss2016.06.837
Citation: XIAO Chao, SHEN Chao, CHENG Guosheng, ZHANG Hua, ZHANG Ting, CARR C M. Survey on the Magnetic Structure of the Neutral Sheets in Earth's Magnetotail[J]. Chinese Journal of Space Science, 2016, 36(6): 837-848. doi: 10.11728/cjss2016.06.837

Survey on the Magnetic Structure of the Neutral Sheets in Earth's Magnetotail

doi: 10.11728/cjss2016.06.837
基金项目:

Supported by the National Natural Science Foundation of China (41231066), Ministry of Science and Technology of China (2011CB811404), the Specialized Research Fund for State Key Laboratories of the CAS, and the Scientific Research Staring Foundation for Nanjing University of Information Science and Technology (2013x030)

详细信息
    通讯作者:

    XIAO Chao,E-mail:xc@nuist.edu.cn

    SHEN Chao,E-mail:sc@nssc.ac.cn

  • 中图分类号: P353

Survey on the Magnetic Structure of the Neutral Sheets in Earth's Magnetotail

Funds:

Supported by the National Natural Science Foundation of China (41231066), Ministry of Science and Technology of China (2011CB811404), the Specialized Research Fund for State Key Laboratories of the CAS, and the Scientific Research Staring Foundation for Nanjing University of Information Science and Technology (2013x030)

  • 摘要: Based on the multipoint magnetic observations of Cluster from 2001 to 2004, the magnetic field structure in magnetotail Neutral Sheet (NS) is statistically surveyed. The results are as follows. In NS, a cubic function is selected to reveal the relation between y (GSM) and positional parameter z. The relation between y and magnetic field values indicates that the magnetic field is weak at midnight region and strengthens gradually at the duskside and dawnside. The relation between y and curvature radius is expressed by a quadratic function. And Rc of flattened CS is less than that of the normal CS. By determines the orientation of MFLs' configuration. The polar angle of the curvature vector is affected by the NS configuration. In addition, the correlation between the polar angle of the curvature vector and z is higher. The polar angle of the normal of the osculating plane is uncertain in the center area. The relation between the azimuthal angles of the curvature vector (the normal of the osculating plane) and y is negatively correlated. An empirical model applied to yz plane of the three-dimensional structure of the magnetic field lines in the NS are developed, and it is represented as a function of the positional parameter y. Finally, the current density is also statistically surveyed.



  • [1] NESS N F. The Earth's magnetotail[J]. J. Geophys. Res., 1965, 70(13):2989-3005
    [2] NESS N F. The geomagnetic tail[J]. Rev. Geophys., 1969, 7(1/2):97-127
    [3] BEHANNON K. Geometry of the geomagnetic tail[J]. J. Geophys. Res., 1970, 75(4):743-753
    [4] SPEISER T W. Magnetospheric current sheets[J]. Radio Sci., 1973, 8(11):973-977
    [5] BAKER D, PULKKINEN T, ANGELOPOULOS V, et al. Neutral line model of substorms:Past results and present view[J]. J. Geophys. Res., 1996, 101(A6):12975-13010
    [6] BAUMJOHANN W, HESSE M, KOKUBUN S, et al. Substorm dipolarization andrecovery[J]. J. Geophys. Res., 1999, 104(A11):24995-25000
    [7] MIURA A. Ballooning instability as a mechanism of the near-Earth onset of substorms[J]. Space Sci. Rev., 2001, 95(1-2):387-398
    [8] LUI A T Y. Cause of magnetospheric substorms[J]. Plasma Phys. Contr., 2003, 45(6):841-852
    [9] SHEN C, LI X, DUNLOP M, et al. Analyses on the geometrical structure of magnetic field in the current sheet based on cluster measurements[J]. J. Geophys. Res., 2003, 108(A5):1168-1186
    [10] BAME S J. The near-parth cross-tail current sheet:detailed ISEE 1 and 2 case studies[J]. J. Geophys. Res., 1986, 91(A4):4287-4301
    [11] SERGEEV V A, MITCHELL D G, RUSSELL C T, et al. Structure of the tail plasma/current sheet at 11 Re and its changes in the course of a substorm[J]. J. Geophys. Res., 1993, 98(A10):17345-17365
    [12] SHEN C, DUNLOP M W. Geometric structure analysis of the magnetic field//Multi-Spacecraft Analysis Methods Revisited[R]. Switzerland:ISSI. 2008:27-32
    [13] SHEN C, LI X, DUNLOP M W, et al. Magnetic field rotation analysis and the applications[J]. J. Geophys. Res., 2007, 112(A06):211
    [14] SHEN C, LIU Z X, LI X, et al. Flattened current sheet and its evolution in substorms[J]. J. Geophys. Res., 2008, 113(A7):S21
    [15] NAKAMURA R, BAUMJOHANN W, RUNOV A, et al. Thin current sheet in the magnetotail observed by Cluster[J]. Space Sci. Rev., 2006, 122(1/2/3/4):29-38
    [16] PETRUKOVICH A A, BAUMJOHANN W, NAKAMURA R, et al. Oscillations of flux tube slippage in the quiet plasma sheet[J]. Ann. Geophys., 2006, 24(1):1695-1704
    [17] RUNOV A, SERGEEV V A, BAUMJOHANN W, et al. Electric current and magnetic field geometry in flapping magnetotail current sheets[J]. Ann. Geophys., 2005, 23(4):1391-1403
    [18] RUNOV A, et al. Local structure of the magnetotail current sheet:2001 Cluster observations[J]. Ann. Geophys., 2006, 24(1):247-262
    [19] SHEN C, RONG Z J, LI X, et al. Magnetic configurations of the tilted current sheets in magnetotail[J]. Ann. Geophys., 2008, 26(11):3525-3543
    [20] Rong Z J, Shen C, Petrukovich A A, et al. The analytic properties of the flapping current sheets in the Earth magnetotail[J]. Planet. Space Sci., 2010, 58(10):1215-1229
    [21] Rong Z J, Shen C, Lucek E, et al. Statistical survey on the magnetic field in magnetotail current sheets:Cluster observations[J]. Chin. Sci. Bull., 2010, 55(23):2542-2547
    [22] RONG Z J, WAN W X, SHEN C, et al. Statistical survey on the magnetic structure in magnetotail current sheets[J]. J. Geophys. Res., 2011, 116(A09):218
    [23] RONG Z J, WAN W X, SHEN C, et al. Radial distribution of magnetic field in earth magnetotail current sheet[J]. Planet. Space Sci., 2014, 103(1):273-285
    [24] FAIRFIELD D H. A statistical determination of the shape and position of the geomagnetic neutral sheet[J]. J. Geophys. Res., 198085(A2):775-780
    [25] TSYGANENKO N A, FAIRFIELD D H. Global shape of the magnetotail current sheet as derived from Geotail and Polar data[J]. J. Geophys. Res., 2004, 109(A03):218
    [26] TSYGANENKO N A, P KARLSSON S B, KOKUBUN S, et al. Global configuration of the magnetotail current sheet as derived from Geotail, Wind, IMP8, and ISEE 1/2 data[J]. J. Geophys. Res., 1998, 103(A4):6827-6841
    [27] SHEN C, RONG Z J, DUNLOP M W, et al. Spatial gradients from irregular, multiple-point spacecraft configurations[J]. J. Geophys. Res., 2012, 117(A11):207
    [28] FAIRFIELD D H, NESS N F. Magnetic field measurements with the IMP 2 satellite[J]. J. Geophys. Res., 1967, 72(9):2379-2402
    [29] Colburn D S, Currie R G, Mihalov J D, et al. Configuration and reconnection of the geomagnetic tail[J]. J. Geophys. Res., 1968, 73(3):943-959
    [30] HARVEY C C. Spatial gradients and the volumetric tensor[J]. Issi Sci. Rep., 1998, 1(1):307-322
  • 加载中
计量
  • 文章访问数:  855
  • HTML全文浏览量:  43
  • PDF下载量:  883
  • 被引次数: 0
出版历程
  • 收稿日期:  2015-09-02
  • 修回日期:  2016-03-26
  • 刊出日期:  2016-11-15
