光谱连续可调星敏感器地面标定系统设计

徐达 张国玉 孙高飞

徐达, 张国玉, 孙高飞. 光谱连续可调星敏感器地面标定系统设计[J]. 空间科学学报, 2017, 37(5): 608-615. doi: 10.11728/cjss2017.05.608
引用本文: 徐达, 张国玉, 孙高飞. 光谱连续可调星敏感器地面标定系统设计[J]. 空间科学学报, 2017, 37(5): 608-615. doi: 10.11728/cjss2017.05.608
XU Da, ZHANG Guoyu, SUN Gaofei. Design of Spectral Continuous Adjustable Star Sensor's Ground Calibration Systemormalsize[J]. Chinese Journal of Space Science, 2017, 37(5): 608-615. doi: 10.11728/cjss2017.05.608
Citation: XU Da, ZHANG Guoyu, SUN Gaofei. Design of Spectral Continuous Adjustable Star Sensor's Ground Calibration Systemormalsize[J]. Chinese Journal of Space Science, 2017, 37(5): 608-615. doi: 10.11728/cjss2017.05.608

光谱连续可调星敏感器地面标定系统设计

doi: 10.11728/cjss2017.05.608
基金项目:

吉林省重点科技攻关项目(20160204008GX)和长春理工大学科技创新基金项目(XJJLG-2016-15)共同资助

详细信息
    作者简介:

    徐达,E-mail:418168115@qq.com

  • 中图分类号: V524.3;TH744

Design of Spectral Continuous Adjustable Star Sensor's Ground Calibration Systemormalsize

  • 摘要:

    为解决由于色温不匹配对星敏感器光信号定标精度产生的影响,提出一种光谱连续可调星敏感器地面标定系统设计方案.该高精度准直光学系统的光谱范围为500~800nm,像质测试结果表明,全视场畸变小于0.08%,MTF在60lp·mm-1处大于0.6.基于DMD光源系统的组成和工作原理,对光谱分辨率和光谱曲线模拟精度进行分析,设计了一套光谱分辨率全谱段优于2nm的Czerny-Turner分光系统.测试结果表明,星点位置精度优于7";光谱分辨率为10nm和20nm时光谱曲线模拟精度分别优于2%和5%,有效降低了由于色温不匹配对星敏感器标定精度的影响.



  • [1] TRIVELLIN N, BARBISAN D, FERRETTI M, et al. Adaptive multi-wavelength LED star simulator for space life studies[C]//Proceedings of SPIE 9768, Light-Emitting Diodes:Materials, Devices, and Applications for Solid State Lighting XX. San Francisco, California:SPIE, 2016:976815
    [2] UMAMAHESWARAN S, NAGENDRA S. Microcontroller based multi-star simulator using controller area network (CAN)[C]//Proceedings of the IEEE 2009 National Aerospace & Electronics Conference (NAECON). Dayton, OH:IEEE, 2009:139-145
    [3] SUN Gaofei, ZHANG Guoyu, LIU Shi, et al. Star position correction of dynamic star simulator based on distortion effect[J]. Chin. J. Space Sci., 2014, 34 (6):887-893(孙高飞, 张国玉, 刘石, 等. 星敏感器光谱探测能力用地面模拟测试系统设计[J]. 空间科学学报, 2014, 34 (6):887-893)
    [4] FRYC I, BROWN S W, EPPELDAUER G P, et al. Led-based spectrally tunable source for radiometric, photometric, and colorimetric applications[J]. Opt. Eng., 2005, 44 (11):111309
    [5] ZHU Jiyi, REN Jianwei, LI Baoyong, et al. Synthesis of spectral distribution for LED-based source with tunable spectra[J]. Chin. J. Lumin., 2010, 31 (6):882-887(朱继亦, 任建伟, 李葆勇, 等. 基于LED的光谱可调光源的光谱分布合成[J]. 发光学报, 2010, 31 (6):882-887)
    [6] WALL C F, HANSON A R, TAYLOR J A F. Construction of a programmable light source for use as a display calibration artifact[C]//Proceedings of SPIE 4295, Flat Panel Display Technology and Display Metrology Ⅱ. San Jose, CA:SPIE, 2001:259-266
    [7] LIU Hongxing, REN Jianwei, LI Baoyong, et al. Spectrum-tunable distribution and spectral matching for integrating sphere light source based on bromine tungsten lamps and LEDs[J]. Chin. J. Lumin., 2011, 32 (10):1074-1080(刘洪兴, 任建伟, 李葆勇, 等. 基于溴钨灯和LED积分球光源的可调谐光谱分布及光谱匹配[J]. 发光学报, 2011, 32 (10):1074-1080)
    [8] LI Xiaoni, WU Cuigang, ZHAO Xin, et al. The research of the light source for star simulator with automatic calibration and adjustable spectrum[J]. Acta Photon. Sin., 2015, 44 (5):0522003(李晓妮, 吴璀罡, 赵昕, 等. 自动标定型光谱可调星模拟器光源系统[J]. 光子学报, 2015, 44 (5):0522003)
    [9] BEUTLER H G. The theory of the concave grating[J]. J. Opt. Soc. Am., 1945, 35 (5):0212003
    [10] LIU Hongxing, REN Jianwei, LIU Zexun, et al. LED-based single star simulator with multi-color-temperature and multi-star-magnitude output[J]. Acta Opt. Sin., 2015, 35 (2):0212003(刘洪兴, 任建伟, 刘则洵, 等. 基于 LED的多色温多星等单星模拟器[J]. 光学学报, 2015, 35 (2):0212003)
    [11] LIU Jianpeng, TANG Yi, HUANG Gang, et al. Design method of optical system of improved czerny-turner imaging spectrometer[J]. Acta Opt. Sin., 2012, 32 (3):0322007(刘健鹏, 唐义, 黄刚, 等. 改进型Czerny-Turner成像光谱仪光学系统设计方法[J]. 光学学报, 2012, 32 (3):0322007)
    [12] CHEN Feng, ZHENG Xiaobing. Influence of spectrum not-matching on calibration precision of remote sensor[J]. Opt. Precision Eng., 2008, 16 (3):415-419(陈风, 郑小兵. 光谱非匹配对光学遥感器定标精度的影响[J]. 光学精密工程, 2008, 16 (3):415-419)
  • 加载中
计量
  • 文章访问数:  1063
  • HTML全文浏览量:  63
  • PDF下载量:  1011
  • 被引次数: 0
出版历程
  • 收稿日期:  2017-03-27
  • 修回日期:  2017-06-27
  • 刊出日期:  2017-09-15
