暗物质粒子探测卫星的集中式载荷管理系统

王连国; 朱岩; 沈卫华; 梁耀明; 滕学剑; 周昌义

doi:10.11728/cjss2018.04.567

暗物质粒子探测卫星的集中式载荷管理系统

doi: 10.11728/cjss2018.04.567

1. 中国科学院国家空间科学中心复杂航天系统电子信息技术重点实验室北京 100190;
2. 中国科学院大学北京 100049

基金项目:

中国科学院空间科学战略性先导科技专项资助（XDA04040202-5）

详细信息

作者简介:
王连国,E-mail:wanglg@nssc.ac.cn

中图分类号: V11;TN39
计量
- 文章访问数: 1150
- HTML全文浏览量: 154
- PDF下载量: 1584
- 被引次数: 0
出版历程
- 收稿日期: 2017-04-14
- 修回日期: 2017-09-10
- 刊出日期: 2018-07-15

Centralized Payload Management System for Dark Matter Particle Explorer Satelliteormalsize

1. Key Laboratory of Electronics and Information Technology for Space Systems, National Space Science Center, Chinese Academy of Sciences, Beijing 100190;
2. University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 暗物质粒子探测卫星有效载荷由4种探测器组成，探测器的电子学前端共有28台设备.针对载荷设备数量多、接口复杂的特点，设计了一种通过载荷数管系统进行集中式载荷管理的方案，实现对探测器电子学前端的遥测、遥控、数据采集和二次电源供配电.同时，载荷数管系统具有大容量数据存储和高速数据复接功能，可分区存储科学数据和工程参数，在进入地面接收站时，将存储的科学数据和工程参数组成符合CCSDS协议的传输帧，经RS编码和加扰后发送给数传发射机.解决了突发式、多信源科学数据采集、存储，探测器在轨自主探测管理，大功率、低噪声二次电源配电等关键技术.该系统经过了在轨考核验证，结果表明控制和信息体系合理，自主探测管理和健康管理措施有效.
- 载荷数管 /
- 数据采集 /
- 二次电源供配电 /
- 自主探测管理
Abstract: The Dark Matter Particle Explorer (DAMPE) Satellite consists of 4 detectors. The total number of detector Front End Electronics (FEE) is 28. To satisfy the requirements for supporting large numbers of FEEs and complicated interface, a centralized management strategy is proposed. Telemetry and telecontrol, scientific data and housekeeping data collection, secondary power supply of all the payloads are realized by payload management system. In addition, the payload management system provides mass data storage and high data rate multiplex function. The scientific data and the housekeeping data can be stored separately by the mass data storage, which based on flash memory. When entering the ground receiving station, the stored data can be retrieved and formatted to CCSDS protocol frame, and then the frame is channel-coded and sent to X-band transmitter. The strategy solved several key technologies such as burst and multi-source scientific data collection and storage, onboard autonomous detection management, and distribution of large capacity and low-noise secondary power supplies. The system has undergone onboard assessment and verification. The results indicate that the control and information architectures are suitable, and the autonomous detection management and health management measures are effective.
- Payload management /
- Data collection /
- Secondary power supply /
- Autonomous detection management

HTML全文

参考文献(8)

[1]	CHANG Jin, FENG Lei, GUO Jianhua, et al. Dark matter particle explorer and nearby cosmic ray electron source[J]. Sci. Sin:Phys. Mech. Astron., 2015, 45(11):119510(常进, 冯磊, 郭建华, 等. 暗物质粒子探测卫星及邻近的电子宇宙射线源[J]. 中国科学:物理学力学与天文学, 2015, 45(11):119510)
[2]	DONG Lei, LI Huawang, ZHU Cheng, et al. Integrated design of payload based dark matter particle explorer[J]. Chin. J. Space Sci., 2017, 37(2):229-237(董磊, 李华旺, 诸成, 朱振才, 常亮. 以载荷为中心的暗物质探测卫星机电热一体化设计[J]. 空间科学学报, 2017, 37(2):229-237.)
[3]	ZHANG Meng, MENG Linzhi, HUANG Jiangchuan, et al. Design and implementation of Chang'e satellite's high reliable electronic information system based on multilevel control structure[J]. Sci. Sin:Technol., 2013, 43(7):739-747(张猛, 孟林智, 黄江川, 等. 基于多级控制结构的嫦娥卫星高可靠电子信息体制设计与实现[J]. 中国科学:技术科学, 2013, 43(7):739-747)
[4]	Telecommand Part 3 Data Management Service. CCSDS 203.0-B-2 Recommendation for space data system standards, blue book, issue 2[M]. Oxfordshire, UK, 2001
[5]	Packet Telemetry. CCSDS 102.0-B-5 Recommendation for space data system standards, blue book, Issue 5[M]. Boulder, Colorado, USA:National Aeronautics and Space Administration, 2000
[6]	AOS Space Data Link Protocol. CCSDS 732.0-B-2 Recommendation for space data system standards, blue book, issue 2[M]. Washington D C, USA:National Aeronautics and Space Administration, 2006
[7]	MA Yin, AN Junshe, WANG Lianguo, et al. SEU-tolerant System Design of SRAM FPGA Based on Scrubbing in Aerospace[J]. Chin. J. Space Sci., 2012, 32(2):270-276(马寅,安军社,王连国, 等. 基于Scrubbing的空间SRAM型FPGA抗单粒子翻转系统设计[J]. 空间科学学报, 2012, 32(2):270-276)
[8]	LIANG Yaoming, MA Miao, WANG Lianguo, et al. Designing and implementing of the payload self-exploration[J]. Chin. J. Space Sci., 2016, 36(2):209-214(梁耀明, 马苗, 王连国, 等. 星载有效载荷自主探测管理方案设计与实现[J]. 空间科学学报, 2016, 36(2):209-214)
