Observations of the Prominent Sporadic Sodium Layer over Haikou
-
摘要: 海南激光雷达站(20°N,110°E)2011年11月2日观测到强烈的突发钠层(SSL).该SSL峰值密度达37087cm-3,半峰全宽仅为0.9km.对该SSL发生前后的钠层峰值密度和高度特性进行分析.统计激光雷达2010年5月至2013年12月共计377天观测到的SSL事件222次,其中仅有1次SSL峰值密度超过30000cm-3.对比距离最近的海南儋州(19.5°N,109.1°E)测高仪和VHF雷达观测到的突发E层(Es)事件,分析事件的相关性.Es最低高度与SSL峰值高度差均在5km以内,约有75%的Es与SSL时间差在±30min之内.实验中使用continuum的Nd:YAG激光器和泵浦染料激光器产生589nm激光,能量为45mJ,使用直径为1000mm的望远镜接收钠层的光子回波.Abstract: The prominent Sporadic Sodium Layer (SSL) were observed by the lidar over Haikou (20°N, 110°E) at 02:47LT on Nov. 2, 2011. The peak density of SSL was 37087cm-3, and its Full Width at Half Maximum (FWHM) was 0.9km. The characters of the peak density and altitude before and after the SSL occurrence were analyzed. 222 SSL events were detected in 377 observation days from 2010 to 2013. The SSL occurrence rate is 12.4h at our location, but only one SSL which peak density was beyond 30000cm-3. By comparing the corresponding data of the nearest ionosonde and VHF radar at Danzhou (19.5°N, 109.1°E), it was found that SSL is closely related to Es. Among the 8 pairs of SSL and Es events checked, all peaks of SSL were accompanied by the lowest Es within 5km in altitude, and 6 pairs of them were correlated within ±0.5h in time. A Nd:YAG laser and pumped dye laser were used to generate the probing beam. The wavelength of the dye laser was set to 589nm by a sodium fluorescence cell. The energy and divergence of the beam were 45mJ and 1mrad, respectively. The backscattered fluorescence photons from the sodium layer were collected by a telescope with a 1000mm diameter primary mirror.
-
Key words:
- Lidar /
- Mesosphere and lower-thermosphere /
- Sodium layer density
-
[1] SLIPHER, V M. Emission in the spectrum of the light of the night sky[J]. Publ. Astron. Soc. Pac., 1929, 41(1): 262-262 [2] BOWMAN M R, GIBSON A J, SANDFORD M C W. Observation of mesospheric Na atoms by tuner laser radar[J]. Nature, 1969, 221(1):456-458 [3] CLEMESHA, B R, KIRCHHOFF V W J H, SIMONICH, D M, et al. Evidence of an extra-terrestrial source for the mesospheric sodium layer[J]. Geophys. Res. Lett., 1978, 5(10):873-876 [4] GARDNER C S AND VOELZ D G. Lidar measurements of gravity wave saturation effects in the sodium layer[J]. Geophys Res. Lett., 1985, 12(11):765-768 [5] GARDNER C S, VOELZ D G, SECHRIST C F, et al. Lidar studies of the nighttime sodium layer over Urbana, Illinois: 1. Seasonal and nocturnal variations[J]. J. Geophys. Res., 1986, 91(A12):13659-13673 [6] KWON K H, GARDNER C S, SENFT D C, et al. Daytime lidar measurements of tidal winds in the mesospheric sodium layer at Urbana, Illinois[J]. J. Geophys. Res., 1987, 92(A8):8781-8786 [7] NAGASAWA C, ABO M. Lidar observations of a lot of sporadic sodium layers in mid-latitude[J]. Geophys. Res. Lett., 1995, 22(3):263-266 [8] GONG S S, YANG G T, WANG J M, et al. Occurrence and characteristics of sporadic sodium layer observed by lidar at a mid-latitude location[J]. J. Atmos. Terr. Phys., 2002, 64(18):1957-1966 [9] WANG J, YANG Y, CHEN X, et al. Double sodium layers observation over Beijing, China[J]. Geophys. Res. Lett., 2012, 39(15):L15801-1-5 [10] ZHANG T, WANG J, LIU H. Observation of sporadic sodium layer over Haikou, China in 2010[J]. Chin. J. Space Sci., 2015, 35(5):566-573 (张铁民, 王继红, 刘汉军. 2010年海口上空突发钠层事件观测[J]. 空间科学学报, 2015, 35(5):566-573) [11] KWON K H, SENFT D C, GARDNER C S. Lidar observations of sporadic sodium layers at Mauna Kea observatory, Hawaii[J]. J. Geophys. Res., 1988, 93(D11):14199-14208 [12] KIRKWOOD S, COLLIS P N. Gravity wave generation of simultaneous auroral sporadic-E layers and sudden neutral sodium layers[J]. J. Atmos. Terr. Phys, 1989, 51(4): 263-269 [13] VON ZAHN U, VON DER GATHEN P, HANSEN G. Forced release of sodium from upper atmospheric dust particles[J]. Geophys Res Lett, 1987, 14(1):76-79 [14] SHANG S, SHI J, YAN J, et al. Investigations of low latitude E region field-aligned irregularities with Hainan VHF radar[J]. Chin. J. Space Sci., 2014, 34(1):53-62 (尚社平,史建魁, 阎敬业, 等. 基于海南VHF雷达观测的低纬度E区场向不规则体研究[J]. 空间科学学报, 2014, 34(1):53-62) [15] BATISTA P P, CLEMESHA B R, SIMONICH D M, et al. Simultaneous lidar observation of a sporadic sodium layer, a "wall" event in the OH and OI5577 airglow images and the meteor winds[J]. J. Atmos. Terr. Phys., 2002, 64(12/13/14):1327-1335
