双储箱液体自衰减晃动分析

林柯成; 宋晓娟

doi:10.11728/cjss2019.06.824

双储箱液体自衰减晃动分析

doi: 10.11728/cjss2019.06.824 cstr: 32142.14.cjss2019.06.824

内蒙古工业大学机械学院呼和浩特 010051

基金项目:

国家自然科学基金项目（11962020，11502122，11862020，11402126）和内蒙古自然科学基金项目（2019MS05065）共同资助}

详细信息

作者简介:

宋晓娟,E-mail:xjsong0603@163.com

中图分类号: V527
计量
- 文章访问数: 1583
- HTML全文浏览量: 235
- PDF下载量: 84
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2018-10-26
- 修回日期: 2019-08-12
- 刊出日期: 2019-11-15

Analyses on Self-reduce Liquid Sloshing in Double Tank

College of Mechanical Engineering, Inner Mongolia University of Technology, Hohhot 010051

摘要

摘要: 航天器在轨运行过程中，液体燃料晃动是破坏航天器稳定性、威胁航天任务安全性的主要因素之一.为此，有必要对液体燃料晃动进行研究.自衰减晃动是一种常见的液体晃动.本文主要针对双并联圆柱形储箱内液体自衰减晃动动态特性进行研究，以有限体积法为计算方法，采用两相层流模型，分析了不同重力环境下，液体燃料晃动对储箱侧壁面及底面作用的晃动力、力矩和波高随时间变化的特性，进而计算出液体晃动等效力学模型的相关参数.采用解析法推导了等效力学模型参数的计算公式，将有限体积法所得仿真解与解析解进行对比分析，证明了双储箱液体晃动仿真计算的可行性，为携带多储箱充液航天器的动力学分析提供了一定的理论基础.
- 液体晃动 /
- 自衰减 /
- 双储箱 /
- 有限体积法
Abstract: Researches have shown that when spacecraft is in orbit, liquid fuel sloshing is one of the main factors that destroy the stability of spacecraft and threaten the safety of space missions. It is necessary to take research on liquid sloshing. Self-reduce sloshing is common in spaceflight missions, which is more complex than enforced sloshing. In this paper, the self-reduce sloshing characters of liquid fuel in the double parallel tanks are studied by FLUENT software and calculation formulas. Based on the Finite Volume Method and the two-phase laminar flow model, the effects of sloshing force, torque and wave height which liquid fuel acts on the tank's side wall and bottom wall under different gravities are analyzed. Each force and torque acts on side wall and bottom wall can be divided into horizontal and vertical direction, and components on both directions are obtained. The parameters of liquid sloshing equivalent model are calculated. The calculation formula of parameters of equivalent dynamic model is derived by analyzing method. By comparing the simulation results and analytical solutions, the feasibility of the simulation calculation is proved. The simulation method would provide a theoretical basis for dynamic analysis of spacecraft with multiple storage tanks.
- Liquid-sloshing /
- Self-reduce /
- Double tank /
- Finite volume method

HTML全文

参考文献(10)

[1]	MOON K K, KOO J R, BAE C H. Free vibration analysis of a hung clamped-free cylindrical shell partially submerged in fluid[J]. J. Fluid. Struct., 2011, 27:283-296
[2]	SANAPALA V S, VELUSAMY K, PATNAIK B S V. CFD simulations on the dynamics of liquid sloshing and its control in a storage tank for spent fuel applications[J]. Ann. Nucl. Energy, 2016, 94:494-509
[3]	BOROOMAND B, BAZAZZADEH S, ZANDI S M. On the use of Laplace's equation for pressure and a mesh-free method for 3d simulation of nonlinear sloshing in tanks[J]. Ocean. Eng., 2016, 122:54-67
[4]	LIU Bo, ZHANG Hao, QU Guangji. Liquid sloshing numerical simulation and experimental verification in liquid-filled spacecraft[C]//Beijing Structure Environment Engineer Major Information Net Conform Proceedings, 2003:118-123(刘波, 张熇, 曲广吉. 充液航天器液体晃动数值仿真与试验验证[C]//北京强度环境工程专业信息网会议论文, 2003:118-123)
[5]	LIN Hong, PENG Huilian, DONG Kai. Simulation and test verification for liquid sloshing of propellant tank[J]. Struct. Environ. Eng., 2011, 38(5):25-30(林宏, 彭慧莲, 董锴. 推进剂储箱液体晃动的仿真研究与验证[J]. 强度与环境, 2011, 38(5):25-30)
[6]	SHANG Chunyu, ZHAO Jincheng. Studies on liquid sloshing in rigid containers using Fluent code[J]. J. Shanghai Jiaotong Univ., 2008, 42(6):953-956(尚春雨, 赵金城. 用Fluent分析刚性容器内液面晃动问题[J]. 上海交通大学学报, 2008, 42(6):953-956)
[7]	CHEN Qingquan, LI Haiyang, LI Jiawen. Identification of equivalent mechanical model parameters based on result of fluent simulation[C]//14th Postgraduate Students' Academic Festival NUDT. Changsha:National University of Defense Technology, 2014(陈青全, 李海阳, 李家文. 基于Fluent仿真结果的液体晃动等效力学模型参数辨识[C]//国防科学技术大学第十四届研究生学术活动节. 长沙:国防科技大学, 2014)
[8]	WU Wenjun, HUANG Zhonglie, YUE Baozeng. Constant sensitivity analyzing for posture-orbit-liquid coupled system with multiple liquid-filled cylindrical tanks[J]. J. Guangxi Univ. Sci. Technol., 2018, 29(1):25-30(吴文军, 黄中烈, 岳宝增. 带多充液圆柱箱航天器姿-轨-液耦合系统参数灵敏度分析[J]. 广西科技大学学报, 2018, 29(1):25-30)
[9]	WU Wenjun, YUE Baozeng, HUANG Hua. Study on the rigid-liquid coupled dynamics for spacecraft with multiple partially liquid-filled cylindrical tanks[J]. J. Astron., 2015, 36(6):648-660(吴文军, 岳宝增, 黄华. 带多充液圆柱储箱航天器刚-液耦合动力学研究[J]. 宇航学报, 2015, 36(6):648-660)
[10]	WANG Zhaolin, LIU Yanzhu. Dynamics of Liquid-Filled System[M]. Beijing:Science Publishing House, 2002(王照林, 刘延柱. 充液系统动力学[M]. 北京:科学出版社, 2002)
