磁云边界层中的复合重联喷流观测分析

周梓露; 宋小健

doi:10.11728/cjss2020.03.323

磁云边界层中的复合重联喷流观测分析

doi: 10.11728/cjss2020.03.323

中国科学院国家空间科学中心北京 100190;中国科学院大学北京 100049

基金项目:

国家自然科学基金项目（41731067，41531073），国家重点实验室专项研究基金项目和中国科学院"十三五"信息化建设专项（XXH13505-04）共同资助

详细信息

作者简介:
周梓露,E-mail:zakhfly@outlook.com

中图分类号: P353
计量
- 文章访问数: 1051
- HTML全文浏览量: 147
- PDF下载量: 56
- 被引次数: 0
出版历程
- 收稿日期: 2019-05-20
- 修回日期: 2019-11-25
- 刊出日期: 2020-05-15

Observation of a Dual Reconnection Exhaust Inside the Boundary Layer of Magnetic Cloud at 1 AU

National Space Science Center, Chinese Academy of Sciences, Beijing 100190;University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 太阳风中的磁场重联通常与行星际日冕物质抛射有关.本文分析了1995年10月18日WIND飞船观测到的一例磁云前边界层中的复合重联喷流事件.该复合排空区由相邻两个不同方向的喷流构成，这两个喷流分别经过Walén关系的证认，符合行星际磁场重联排空区等离子体喷流的特征.结果表明，在磁云前端可能存在众多重联点，从而将磁云本体的磁场剥离，形成比单一重联喷流区更复杂的三维边界层结构.磁云边界层中可能发生多点多次重联，从而不表现出单点重联的排空区特征，这可能是行星际磁场重联排空区较少在ICME前端被观测到的原因之一.
- 磁云 /
- 磁云边界层 /
- 磁场重联
Abstract: Magnetic reconnection is prevalent in the low speed and low proton beta solar wind and is usually associated with Interplanetary Coronal Mass Ejections (ICME). In this paper, a dual reconnection exhaust in the front boundary of a Magnetic Cloud (MC) was observed by WIND spacecraft on 18 October 1995. The Alfvénic accelerated or decelerated plasma jets were examined using Walén relation near the boundary of the exhausts, which are consistent with the characteristics of the interplanetary reconnection exhausts reported in recent literatures. As a consequence, multiple reconnection exhausts could be abundant ahead of the MCs and complex 3D boundary layers would form instead of single reconnections exhausts. Such complex structures may bring some difficulties in searching for reconnection events in the magnetic cloud boundary layers.
- Magnetic cloud /
- Boundary layer /
- Magnetic reconnection

HTML全文

参考文献(38)

[1]	PASCHMANN G, SONNERUP B U Ö, PAPAMASTORAKIS I, et al. Plasma acceleration at the Earth's magnetopause:evidence for reconnection[J]. Nature, 1979, 282(5736):243-246
[2]	SONNERUP B U Ö, PASCHMANN G, PAPAMASTORAKIS I, et al. Evidence for magnetic field reconnection at the Earth's magnetopause[J]. J. Geophys. Res., 1981, 86(A12):49-67
[3]	GOSLING J T, ASBRIDGE J R, BAME S J, et al. Evidence for quasi-stationary reconnection at the dayside magnetopause[J]. J. Geophys. Res., 1982, 87(A4):2147-2158
[4]	Ø IEROSET M, PHAN T D, LIN R P, et al. Walén and variance analyses of high-speed flows observed by Wind in the midtail plasma sheet:evidence for reconnection[J]. J. Geophys. Res.:Space Phys., 2000, 105(A11):25247-25263
[5]	Ø IEROSET M, PHAN T D, FUJIMOTO M, et al. In situ detection of collisionless reconnection in the Earth's magnetotail[J]. Nature, 2001, 412(6845):414-417
[6]	GOSLING J T, SKOUG R M, MCCOMAS D J, et al. Direct evidence for magnetic reconnection in the solar wind near 1 AU[J]. J. Geophys. Res.:Space Phys., 2005, 110(A1).DOI: org/10.1029/2004JA010809
[7]	PETSCHEK H E. Magnetic Field Annihilation[M]. Washington:NASA Special Publication, 1964:425
[8]	DAVIS M S, PHAN T D, GOSLING J T, et al. Detection of oppositely directed reconnection jets in a solar wind current sheet[J]. Geophys. Res. Lett., 2006, 33(19). DOI: org/10.1029/2006GL026735
[9]	PHAN T D, GOSLING J T, DAVIS M S, et al. A magnetic reconnection X-line extending more than 390 Earth radii in the solar wind[J]. Nature, 2006, 439(7073):175-178
[10]	GOSLING J T, ERIKSSON S, BLUSH L M, et al. Five spacecraft observations of oppositely directed exhaust jets from a magnetic reconnection X-line extending >4.26×106km in the solar wind at 1AU[J]. Geophys. Res. Lett., 2007, 34(20).DOI: org/10.1029/2007GL031492
[11]	GOSLING J T, ERIKSSON S, PHAN T D, et al. Direct evidence for prolonged magnetic reconnection at a continuous X-line within the heliospheric current sheet[J]. Geophys. Res. Lett., 2007, 34(6).DOI:org/10. 1029/2006GL029033
[12]	GOSLING J T, PHAN T D, LIN R P, et al. Prevalence of magnetic reconnection at small field shear angles in the solar wind[J]. Geophys. Res. Lett., 2007, 34(15). DOI: org/10.1029/2007GL030706
[13]	XU X, WANG Y, WEI F, et al. Direct evidence for kinetic effects associated with solar wind reconnection[J]. Sci. Rep., 2015, 5:8080
[14]	GOSLING J T, ERIKSSON S, MCCOMAS D J, et al. Multiple magnetic reconnection sites associated with a coronal mass ejection in the solar wind[J]. J. Geophys. Res.:Space Phys., 2007, 112(A8). DOI: org/10.1029/2007JA012418
[15]	GOSLING J T, SZABO A. Bifurcated current sheets produced by magnetic reconnection in the solar wind[J]. J. Geophys. Res.:Space Phys., 2008, 113(A10).DOI: org/10.1029/2008JA013473
[16]	WANG Y, WEI F S, FENG X S, et al. Energetic electrons associated with magnetic reconnection in the magnetic cloud boundary layer[J]. Phys. Rev. Lett., 2010, 105(19):195007
[17]	LUGAZ N, MANCHESTER IV W B, GOMBOSI T I. Numerical simulation of the interaction of two coronal mass ejections from sun to earth[J]. Astrophys. J., 2005, 634(1):651-662
[18]	XU X, WEI F, FENG X. Observations of reconnection exhausts associated with large-scale current sheets within a complex ICME at 1AU[J]. J. Geophys. Res.:Space Phys., 2011, 116:A05105
[19]	PHAN T D, GOSLING J T, PASCHMANN G, et al. The dependence of magnetic reconnection on plasma β and magnetic shear:evidence from solar wind observations[J]. Astrophys. J., 2010, 719(2):199-203
[20]	GOSLING J T. Magnetic reconnection in the solar wind[J]. Space Sci. Rev., 2012, 172(1):187-200
[21]	BURLAGA L, SITTLER E, MARIANI F, et al. Magnetic loop behind an interplanetary shock:voyager, helios, and IMP 8 observations[J]. J. Geophys. Res., 1981, 86(A8):6673-6684
[22]	MARSDEN R G, SANDERSON T R, TRANQUILLE C, et al. ISEE 3 observations of low-energy proton bidirectional events and their relation to isolated interplanetary magnetic structures[J]. J. Geophys. Res., 1987, 92(A10):11009-11019
[23]	GOSLING J T, BAKER D N, BAME S J, et al. Bidirectional solar wind electron heat flux events[J]. J. Geophys. Res., 1987, 92(A8):8519-8535
[24]	VANDAS M, FISCHER S, PELANT P, et al. Spheroidal models of magnetic clouds and their comparison with spacecraft measurements[J]. J. Geophys. Res., 1993, 98(A7):11467-11475
[25]	BURLAGA L. Interplanetary Magnetohydrodynamics[M]. Oxford:Oxford University Press, 1995
[26]	WEI F S, LIU R, FAN Q L, et al. Identification of the magnetic cloud boundary layers[J]. J. Geophys. Res.:Space Phys., 2003, 108(A6):1263
[27]	WEI F S, LIU R, FENG X S, et al. Magnetic structures inside boundary layers of magnetic clouds[J]. Geophys. Res. Lett., 2003, 30(24):2283
[28]	WEI F, FENG X, YANG F, et al. A new non-pressure-balanced structure in interplanetary space:boundary layers of magnetic clouds[J]. J. Geophys. Res., 2006, 111(A3).DOI: org/10.1029/2005JA011272
[29]	RUFFENACH A, LAVRAUD B, OWENS M J, et al. Multispacecraft observation of magnetic cloud erosion by magnetic reconnection during propagation[J]. J. Geophys. Res.:Space Phys., 2012, 117(A9).DOI: org/10.1029/2012JA017624
[30]	LOPEZ R. Solar cycle invariance in solar wind proton temperature relationships[J]. J. Geophys. Res.:Space Phys., 1987, 92(A10):11189-11194
[31]	RICHARDSON I, CANE H. Regions of abnormally low proton temperature in the solar wind (1965-1991) and their association with ejecta[J]. J. Geophys. Res.:Space Phys., 1995, 100(A12):23397-23412
[32]	LEPPING R P, BURLAGA L F, SZABO A, et al. The wind magnetic cloud and events of October 18-20, 1995:interplanetary properties and as triggers for geomagnetic activity[J]. J. Geophys. Res.:Space Phys., 2013, 102(A7):14049-14063
[33]	JANOO L, FARRUGIA C J, TORBERT R B, et al. Field and flow perturbations in the October 18-19, 1995, magnetic cloud[J]. J. Geophys. Res.:Space Phys., 1998, 103(A8):17249-17259
[34]	PASCHMANN G, SCHWARTZ S. Analysis methods for multi-spacecraft data[C]//Proceedings of the Cluster-II Workshop Multiscale/Multipoint Plasma Measurements, Paris:European Space Agency (ESA),2000
[35]	HUDSON P D. Discontinuities in an anisotropic plasma and their identification in the solar wind[J]. Planet. Space Sci., 1970, 18(11):1611-1622
[36]	PASCHMANN G, PAPAMASTORAKIS I, BAUMJOHANN W, et al. The magnetopause for large magnetic shear:AMPTE/IRM observations[J]. J. Geophys. Res., 1986, 91(A10):1099-1115
[37]	WANG Y, WEI F S, FENG X S, et al. Energy dissipation processes in solar wind turbulence[J]. Astrophys. J. Suppl. Ser., 2015, 221(2).DOI: 10.1088/0067-0049/221/2/34
[38]	CHIAN A C L, MUÑOZ P R. Detection of current sheets and magnetic reconnections at the turbulent leading edge of an interplanetary coronal mass ejection[J]. Astrophys. J., 2011, 733(2):L34
