利用掩星温度数据推算大气月平均纬向风场

杜晓勇; 杜智涛; 郭粤宁; 符养

doi:10.11728/cjss2020.06.1030

利用掩星温度数据推算大气月平均纬向风场

doi: 10.11728/cjss2020.06.1030

北京应用气象研究所北京 100029

基金项目:

国家自然科学基金项目资助（41805026）

详细信息

作者简介:
杜晓勇,E-mail:duxy@pku.edu.cn

中图分类号: P352
计量
- 文章访问数: 386
- HTML全文浏览量: 14
- PDF下载量: 52
- 被引次数: 0
出版历程
- 收稿日期: 2020-05-18
- 修回日期: 2020-08-17
- 刊出日期: 2020-11-15

Research of Monthly Zonal Winds Derived from Radio Occultation Temperature Data

Beijing Institute of Applied Meteorology, Beijing 100029

摘要

摘要: 为了弥补中高层大气风场探测数据的不足，对2007年COSMIC全球掩星在20～60km高度内的温度数据进行网格化插值，利用梯度风计算方法，计算得到20～60km高度内的月平均纬向风场，分别与ECMWF再分析数据和HWM07模式进行对比分析.结果表明，利用COSMIC温度数据计算得出的纬向风与ECMWF的纬向风十分接近，而与HWM07结果有一定差异，但总体变化趋势一致.与ECMWF再分析数据相比，利用COSMIC温度数据计算的月平均纬向风场平均偏差为-1.50～-0.08m·^-1，标准差为1.50～11.95m·^-1.与HWM07模式风场相比，利用COSMIC温度计算的月平均纬向风场平均偏差为-0.83～1.21m·^-1，标准差为3.69～11.14m·^-1.
- COSMIC /
- 掩星 /
- 临近空间 /
- 风场 /
- ECMWF /
- HWM模式
Abstract: In order to make up for the lack of wind data in the middle and upper atmosphere, the gradient wind fields between altitude of 20km to 60km are calculated by interpolating COSMIC temperature data of year 2007 into gridded data. The derived wind fields are compared with ECMWF reanalyzed data and HWM07 model outputs. Results show that the characteristics of wind fields derived from COSMIC temperature data are more similar with that of the reanalyzed data and are similar with HWM07 output as a whole, while are different from HWM07 data in detail. Compared with the ECMWF reanalyzed data, the mean differences of the zonal wind fields are within -1.50～-0.08m·^-1, and the RMS are within 1.50～11.95m·^-1. Compared with HWM07 outputs, the mean differences of the zonal wind fields are within -0.83～1.21m·^-1, and the RMS are within 3.69m～11.14m·^-1.
- COSMIC /
- Occultation /
- Near space /
- Wind fields /
- ECMWF reanalyzed data /
- HWM model

HTML全文

参考文献(25)

[1]	CHEN Hongbin. An overview of the space based observations for upper atmospheric research[J]. Adv. Earth Sci., 2009, 24(3):229-241(陈洪滨. 中高层大气研究的空间探测[J]. 地球科学进展, 2009, 24(3):229-241)
[2]	LÜ Daren, CHEN Zeyu, GUO Xia, et al. Recent progress in near space atmospheric environment study[J]. Adv. Mech., 2009, 39(6):674-682(吕达仁, 陈泽宇, 郭霞, 等. 临近空间大气环境研究现状[J]. 力学进展, 2009, 39(6):674-682)
[3]	DU Xiaoyong, FU Yang, GUO Yuening, et al. The latest advancement of international GNSS-LEO occultation sounding and future plans[C]//The 25th Conference on Space Sounding. Hailar, 2012
[4]	SHENG Peixuan, MAO Jietai, LI Jianguo, et al. Atmospheric Phisics[M]. Beijing: Peking University Press, 2003
[5]	ANDREWS D G, HOLTON J R, LEOVY C B. Middle Atmosphere Dynamics[M]. Florida: Academic Press, 1987:114-125
[6]	RANDEL W J. The evaluation of winds from geopotential height data in the stratosphere[J]. Atmos. Sci., 1987, 44:3097-3120
[7]	HEDIN A E, FLEMING E L, MANSON A H, et al. Empirical wind model for the upper middle and lower atmosphere[J]. Atmos. Sol.: Terr. Phys., 1996, 58:1421-1447
[8]	FLEMING E L, CHANDRA S, BURRAGE M D, et al. Climatological mean wind observations from the UARS high resolution Doppler imager and wind imaging interfe rometer: comparison with current reference models[J]. J. Geophys. Res., 1996, 101:10455-10473
[9]	MILES T, GROSE W L. Comparison of geostrophic and nonlinear balanced winds from LIMS data and implications for derived dynamical quantities[J]. Pageoph, 1989, 130(2/3):320-342
[10]	FLEMING E L, CHANDRA S, BARNETT J J, et al. Zonal mean temperature, pressure, zonal wind and geopotential height as functions of latitude[J]. Adv. Space Res., 1990, 10(12):11-59
[11]	OBERHEIDE J, LEHMACHER G A, OFFERMANN D, et al. Geostrophic wind fields in the stratosphere and mesosphere from satellite data[J]. J. Geophys. Res., 2002, 107(D23):8175
[12]	REMSBERG E, LINGENFELSER G, HARVEY V L, et al. On the verification of the quality of SABER temperature, geopotential height, and wind fields by comparison with Met Office assimilated analyses[J]. J. Geophys. Res., 2003, 108(D20):4628
[13]	ZHENG W Z, ZOU C Z. An improved algorithm for atmospheric wind retrievals from satellite soundings over the polar regions[J]. Geophys. Res. Lett., 2006, 33:L06820
[14]	MA Ruiping, LIAO Huaizhe. The characteristic of winds at height of 20～80km in the Chinese area[J]. Chin. J. Space Sci., 1999, 19(4):334-341(马瑞平, 廖怀哲. 中国地区20～80km高空风的一些特征[J]. 空间科学学报, 1999, 19(4):334-341)
[15]	LIU Sanjun, XIONG Jiangang, WAN Weixing. Global background wind of middle atmosphere from Aura data[J]. Chin. J. Space Sci., 2007, 27(5):400-408(刘三军, 熊建刚, 万卫星, 等. 利用Aura卫星资料计算全球中层大气背景风场[J]. 空间科学学报, 2007, 27(5):400-408)
[16]	MANSON A H, MEEK C E, FLEMING E, et al. Comparisons between satellite-derived gradient winds and radar-derived winds from the CIRA-86[J]. J. Atmos. Sci., 1991, 48:411-428
[17]	OBERHEIDE J, LEHMACHER G A, OFFERMANN D, et al. Geostrophic wind fields in the stratosphere and mesosphere from satellite data[J]. J. Geophys. Res., 2002, 107(D23):8175
[18]	XIAO Cunying, HU Xiong, TIAN Jianhua. Analysis and comparison of deriving winds from satellite temperature data[J]. Chin. J. Geophys., 2008, 51(2):325-336(肖存英, 胡雄, 田剑华. 利用卫星温度资料计算风场的方法分析与比较[J]. 地球物理学报, 2008, 51(2):325-336)
[19]	XIAO Weihua, FU Yang, GAO Taichang, et al. Deriving atmospheric zonal mean winds from refractive index data[J]. J. Appl. Meteor. Sci., 2011, 22(3):346-355
[20]	XIAO Weihua, FU Yang, Du Xiaoyong, et al. Analysis of deriving stratospheric atmospheric winds from COSMIC radio occultation data[J]. Geomat. Inform. Sci. Wuhan Univ., 2012, 37(2):199-204
[21]	LIU Mohan, XU Jiyao, LIU Hanli, et al. Possible modulation of migrating diurnal tide by latitudinal gradient of zonal wind observed by SABER/TIMED[J]. Sci. China Earth Sci., 2016, 59:408-417
[22]	LING Chao, CHEN Zeyu, CHEN Hongbin. Global structure and variation of mesospheric and lower thermospheric zonal wind in 120°E meridian[J]. Acta Phys. Sin., 2012, 61(24):249201
[23]	ANTHES R A, BERNHARDT P A, CHEN Y, et al. The COSMIC/FORMOSAT-3 mission: early results[J]. Bull. Am. Meteor. Soc., 2008, 89:313-333
[24]	MICHELE Rienecker, MAX Suarez, RON Gelaro, et al. MERRA-NASA’s Re-analysis Overview & Status[OL]. http://www.emc.ncep.noaa.gov/seminars/old/presentations/2007/MERRA_NCEP.pdf
[25]	DROB D P, EMMERT J T, CROWLEY G, et al. An empirical model of the Earth’s horizontal wind fields: HWM07[J]. J. Geophys. Res. Atmos., 2008, 113(A12304):18
