Trajectory Design for Solar Approaching Detection Mission Using Multiple Resonant Gravity Assists of the Venus
-
摘要: 对于太阳抵近探测任务,从地球直接发射探测器至太阳附近需要消耗巨大能量,通过多次金星借力飞行,可有效降低地球发射能量C3及中途变轨的燃料消耗.本文研究基于金星共振借力的太阳抵近探测任务轨道优化设计,建立了连续共振借力和混合共振借力的转移轨道优化设计模型,并针对2025—2028年的发射窗口开展太阳抵近探测任务轨道优化设计.仿真结果表明,相比连续共振借力,混合共振借力可以有效缩短太阳抵近探测任务的轨道转移时间,对于地球发射能量C3和中途变轨燃料消耗的影响未见明显的规律性,能量降低与序列中的共振比相关.Abstract: To approach close to the Sun, direct launch from the Earth costs a lot of energy, which can be effectively reduced by the gravity assist of the Venus. In this paper, interplanetary transfer trajectories with multiple resonant gravity assists of the Venus are designed for a solar approaching detection mission. And design models for the trajectories with continuous resonant gravity assists, as well as resonant and non-resonant gravity assists combined are built. A mission launched between 2025 and 2028 is studied. The study shows that, compared with trajectory with continuous resonant gravity assists, trajectory with resonant and non-resonant gravity assists combined is useful for reducing transfer time of solar approaching detection mission. And its impact on the energy cost is not universal, which is related to the resonance ratio in the trajectory.
-
Key words:
- Solar approaching detection /
- Resonant gravity assist /
- Trajectory design
-
[1] GALEEV A A, VAISBERG O L, ZAKHAROV A V, et al. Project Ziolkovsky-Solar Probe mission concept[J]. Adv. Space Res., 1996, 17(3):13-20 [2] TSURUTANI B T, VAISBERG O L. The Solar Probe mission and comments on plasma wave observations[C]//AIP Conference Proceeding. New York:AIP Press, 1996:255 [3] GUO Y. Trajectory design of Solar Probe+ using multiple Venus gravity assists[C]//AIAA/AAS Astrodynamics Specialist Conference and Exhibit. Honolulu, Hawaii:American Institute of Aeronautics and Astronautics, 2008:3029-3039 [4] SUKHANOV A A. Close approach to Sun using gravity assists of the inner planets[J]. Acta Astron., 1999, 45:177-185 [5] QIAO Dong. Study of Transfer Trajectory Design Method for Deep Space Exploration and Application to Small Body Exploration[D]. Harbin:Harbin Institute of Technology, 2007 (乔栋. 深空探测转移轨道设计方法研究及 在小天体探测中的应用[D]. 哈尔滨:哈尔滨工业大学, 2007) [6] LI Junfeng, BAOYIN Hexi, JIANG Fanghua. Dynamics and Control of Interplanetary Flight[M]. Beijing:Tsinghua University Press, 2014:110-127 (李俊峰, 宝音贺西,蒋方华. 深空探测动力学与控制[M]. 北京:清华大学出版社, 2014:110-127) [7] YUAN Jianping, ZHAO Yushan, TANG Geshi, et al. Spacecraft Deep Space Flight Trajectory Design[M]. Beijing:China Astronautic Publishing House, 2014:59-76 (袁建平, 赵育善, 唐歌实, 等. 航天器深空飞 行轨道设计[M]. 北京:中国宇航出版社, 2014:59-76) [8] HU Zhongbo. The Study of Differential Evolution Algorithm for the Function Optimization[D]. Wuhan:Wuhan University of Technology, 2006 (胡中波. 差分演化算法及其在函数优化中的应用研究[D]. 武汉:武汉理工大学, 2006) [9] Differential evolution (DE) for continuous function optimization (an algorithm by Kenneth Price and Rainer Storn)[OL].[2019-10-10] http://www1.icsi.berkeley.edu/~storn/code.html#tevc [10] LI Xiaoyu. Design and Optimization of Deep Space Trajectory on the Initial Design Stage[D]. Beijing:University of Chinese Academy of Sciences, 2012 (李小玉. 深空探测轨道的初始方案设计与优化[D]. 北京:中国科 学院大学, 2012)
