基于多源影像的探测器月面着陆点定位与精度验证

王镓; 辛鑫; 万文辉; 崔晓峰; 荣志飞; 游祎; 何锡明

doi:10.11728/cjss2021.02.320

基于多源影像的探测器月面着陆点定位与精度验证

doi: 10.11728/cjss2021.02.320

1. 北京航天飞行控制中心北京 100094;
2. 中国科学院空天信息创新研究院, 遥感科学国家重点实验室北京, 100101

基金项目:

国家自然科学基金项目资助（41771488）

详细信息

作者简介:
王镓,E-mail:15210106156@139.com

通讯作者:
辛鑫,E-mail:xinxin@tcu.edu.cn

中图分类号: V529
计量
- 文章访问数: 330
- HTML全文浏览量: 48
- PDF下载量: 52
- 被引次数: 0
出版历程
- 收稿日期: 2019-11-18
- 修回日期: 2020-10-20
- 刊出日期: 2021-03-15

Location and Accuracy Validation of Lunar Landing Point Based on Multi-source Imagesormalsize

1 Beijing Aerospace Control Center, Beijing 100094;
2 State Key Laboratory of Remote Sensing Science, Aerospace Information Research Institute, Chinese Academy of Sciences, Beijing 100101

摘要

摘要: 探测器月面着陆点高精度定位是探测器着陆的重要技术环节，也是地外天体探测器开展各项工作的重要前提.本文基于多源图像数据，利用图像特征匹配和多重覆盖影像定位技术，设计了探测器月面着陆点高精度定位方法，并使用嫦娥三号任务相关影像进行了定位实验与精度验证.在高精度图像匹配和几何变换的基础上，降落相机序列影像间的匹配精度达到子像素，LRO NAC影像与中分辨率降落图像的匹配精度优于1pixel，最终解算的嫦娥三号探测器着陆点坐标为（44.1196°N，19.5148°W）.本文方法综合利用了多源图像数据，不完全依靠着陆区DOM底图的制图精度，是对影像与DOM底图配准定位结果的进一步精化，在未来的月球着陆探测任务中具有应用价值.
- 多源影像 /
- 着陆点定位 /
- 降落影像 /
- LRO NAC /
- 特征匹配
Abstract: High-precision positioning of the landing site is a critical step in the mission and an important prerequisite for surface operations of the lander and rover. In this paper, a high-precision positioning method of the landing site was designed based on image feature matching and multiple image localization methods. And the positioning experiment and accuracy validation were carried out in Chang'E-3 landing site. On the basis of high-precision image matching and geometric transformation, the matching precision between the sequent descent images reached sub-pixel, and the matching accuracy between LRO NAC image and medium-resolution descent image was better than 1 pixel. The landing position was calculated to be (44.1196°N, 19.5148°W). This method comprehensively utilized multi-source images, and didn't entirely depend on the mapping accuracy of the landing base map. It was a further refinement of the matching results between the images and landing base map. So, this high-precision positioning method can be applied in future deep space exploration missions.
- Multi-source image /
- Landing site location /
- Descent image /
- LRO NAC /
- Feature matching

HTML全文

参考文献(18)

[1]	WANG Jia, WU Weiren, LI Jian, et al. Vision based Chang'E-4 landing point localization[J]. Sci. Sin. Tech., 2020, 50:41-53 (王镓, 吴伟仁, 李剑, 等. 基于视觉的嫦娥四号探测器着陆点定位[J]. 中国科学:技术科学, 2020, 50:41-53)
[2]	DI Kaichang, LIU Zhaoqin, LIU Bin, et al. Chang'E-4 lander localization based on multi-source data[J]. J. Remote Sens., 2019, 23(1):177-184. (邸凯昌, 刘召芹, 刘斌等. 多源数据的嫦娥四号着陆点定位[J]. 遥感学报, 2019, 23(1):177-184)
[3]	LIU Jianjun, REN Xin, YAN Wei, et al. Descent trajectory reconstruction and landing site positioning of Chang'E-4 on the lunar farside[J]. Nature Commun., 2019, 10(1):4229
[4]	WAN Wenhui, LIU Zhaoqin, LIU Yiliang, et al. Descent image matching based position evaluation for Chang'E-3 landing point[J]. Spacecraft Eng., 2014, 23(4):5-12 (万文辉, 刘召芹, 刘一良, 等. 基于降落图像匹配的嫦娥三号着陆点位置评估[J]. 航天器工程, 2014, 23(4):5-12)
[5]	JIA Yang, LIU Shaochuang, LI Minglei, et al. Chang'E-3 system pinpoint landing localization based on descent image sequence[J]. Chin. Sci. Bull., 2014, 59:1838-1843 (贾阳, 刘少创, 李明磊, 等. 利用降落影像序列实现嫦娥三号系统着陆点高精度定位[J]. 科学通报, 2014, 59:1838-1843)
[6]	NASA Images of Chang'E-3 Landing Site[EB/OL]. NASA/GSFC/Arizona State University.[2014-01-23]. http://www.nasa.gov/content/nasa-images-of-change-3-landing-site/
[7]	WAGNER R V, ROBINSON M S, SPEYERER E J, et al. Locations of anthropogenic sites on the Moon[C]//45th Lunar & Planetary Science Conference. The Woodlands, Texas:Universities Space Research Association, 2014:225
[8]	LIU Bin, DI Kaichang, WANG Baofeng, et al. Positioning and precision validation of Chang'E-3 Lander based on multiple LRO NAC images[J]. Chin. Sci. Bull., 2015, 60:2750-2757 (刘斌, 邸凯昌, 王保丰, 等. 基于LRO NAC影像的嫦娥三号着陆点高精度定位与精度验证[J]. 科学通报, 2015, 60:2750-2757)
[9]	LI CHunlai, LIU Jianjun, REN Xin, et al. Lunar Global High-precision terrain reconstruction based on Chang'E-2 stereo images[J]. Geomat. Inform. Sci. Wuhan Univ., 2018, 43(4):485-495 (李春来, 刘建军, 任鑫, 等. 基于嫦娥二号立体影像的全月高精度地形重建[J]. 武汉大学学报:信息科学版, 2018, 43(4):485-495)
[10]	ROBINSON M S, BRYLOW S M, TSCHIMMEL M, et al. Lunar Reconnaissance Orbiter Camera (LROC) instrument overview[J]. Space Sci. Rev., 2010, 150(1/2/3/4):81-124
[11]	LOWE D G. Object recognition from local scale-invariant features[C]//Proceeding of the International Conference on Computer Vision, Kerkyra:IEEE, 1999
[12]	LOWE D G. Distinctive image features from scale-invariant keypoints[J]. Int. J. Comput. Vision, 2004, 60(2):91-110
[13]	WANG Jia, WAN Wenhui, ZHAO Huanzhou, et al. Vision-based positioning method for Chang'E-4 lander[J]. Man. Spaceflight, 2019, 25(1):12-18 (王镓, 万文辉, 赵焕洲, 等. 基于视觉的嫦娥四号探测器着陆点定位方法[J]. 载人航天, 2019, 25(1):12-18)
[14]	XIN Xin. Research on Matching of Obiter Imagery and Digital Elevation Model[D]. Beijing:University of Chinese Academy of Sciences, 2019 (辛鑫, 月球轨道器影像与高程数据匹配方法研究[D]. 北京:中国科学院大学, 2019)
[15]	MAZARICO E, ROWLANDS D D, NEUMANN G A, et al. Orbit determination of the lunar reconnaissance orbiter[J]. J. Geod., 2012, 86(3):193-207
[16]	BARKER M K, MAZARICO E, NEUMANN G A, et al. A new lunar digital elevation model from the lunar orbiter laser altimeter and SELENE terrain camera[J]. Icarus, 2016, 273:346-355
[17]	MOREL J M, YU G. ASIFT:a new framework for fully affine invariant image comparison[J]. SIAM J. Imag. Sci., 2009, 2(2):438-469
[18]	YU G, MOREL J M. ASIFT:an algorithm for fully affine invariant comparison[J]. Image Proc. Line, 2011, 1:11-38
