嫦娥四号着陆器载荷电控箱地面测试系统设计

崔天舒; 安军社; 吴琦

doi:10.11728/cjss2021.02.342

嫦娥四号着陆器载荷电控箱地面测试系统设计

doi: 10.11728/cjss2021.02.342 cstr: 32142.14.cjss2021.02.342

崔天舒^1,2,
安军社^1,2,
吴琦¹

1. 中国科学院国家空间科学中心复杂航天系统电子信息技术重点实验室北京 100190;
2. 中国科学院大学北京 100049

详细信息

作者简介:

崔天舒,E-mail:cuits@nssc.ac.cn

中图分类号: V447
计量
- 文章访问数: 1045
- HTML全文浏览量: 104
- PDF下载量: 72
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2019-11-14
- 修回日期: 2020-06-07
- 刊出日期: 2021-03-15

Design of Ground Test System for Chang'E-4 Lander Load Electric Control Box

1 Key Laboratory of Electronics and Information Technology for Space Systems, National Space Science Center, Chinese Academy of Sciences, Beijing 100190;
2 University of Chinese Academy of sciences, Beijing 100149

摘要

摘要: 航天器电子设备的地面综合测试是航天器研制过程中的重要环节，对设备功能验证及性能评估具有重要作用.传统的地面综合测试系统可重用性差，导致研制周期长且人力、设备投入较大.嫦娥四号着陆器载荷电控箱的地面测试系统采用模块化、可重用和CPU+FPGA单机集成体系结构，是集供配电测试、1553B通信总线仿真测试、间接指令测试、异步串口通信测试、实时数据处理等功能于一体的综合测试系统，适用于航天器电子设备单板调试、单机测试、软件配置项测试以及环境模拟试验等不同类型的测试.通过嫦娥四号着陆器载荷电控箱各项接口、功能、性能指标等的测试，证明该系统满足支持设备单机调试、软件配置项测试、状态确认和问题排查等测试需求，有力支撑了嫦娥四号着陆器载荷电控箱的单机设备研发，为嫦娥四号着陆器任务实施提供了有效保障.
- 嫦娥四号着陆器 /
- 航天器电子设备 /
- 地面测试系统 /
- LabVIEW
Abstract: The ground comprehensive test of spacecraft electronic equipment is an important part in the development of spacecraft. It plays an important role in equipment function verification and performance evaluation. The ground test system of the Chang'E-4 lander load electric control box adopts modular, reusable design and CPU+FPGA single-machine integrated architecture. It can provide power supply test, 1553B communication bus simulation test, indirect command test, asynchronous serial communication test, real-time data processing and other functions in one integrated system, is suitable for spacecraft electronic equipment single machine debugging, configuration test and environmental simulation test and other types of test requirements. The test of each interface, function and performance of the load electric control box indicates that the system meets the test requirements of stand-alone debugging, status confirmation and troubleshooting of the spaceborne equipment, which strongly supports the successful on-orbit operation of the Chang'E-4 lander load electric control box.
- Chang'E-4 Lander /
- Spacecraft electronic equipment /
- Ground test system /
- LabVIEW

HTML全文

参考文献(9)

[1]	FENG Hua, LIU Shiyao. Chang'E-4 Successfully Landed on the Back of the Moon. The World's First Close-up Image of the Back of the Moon was Returned[OL].[2019-01-03]. http://news.china.com.cn/2019-01/03/content_74337087.html
[2]	CUI Xia, WU Jie, WANG Shiyu, et al. The Yutu 2 Patrol was Walking on the Moon, and Part of the Chang'E-4 Payload was Turned on[OL].[2019-01-04]. http://www.chinanews.com/gn/2019/01-04/8720470.html
[3]	CHEN Fang, HU Zhe, JIN Liwang. Good news! The Mission of Chang'E-4 was a Complete Success[OL].[2019-01-11]. http://www.xinhuanet.com/politics/2019-01/11/c_1123978466.html
[4]	DU Xue, ZHANG Jun. Design and implementation on integrated testing system for Beidou Navigation Satellite[J]. Comput. Meas. Control, 2015, 23(11):3616-3618, 3622 (杜雪, 张军. 北斗导航卫星地面综合测试系统设计与实现[J]. 计算机测量与控制, 2015, 23(11):3616-3618, 3622)
[5]	BAO Weimin. Present situation and development tendency of aerospace control techniques[J]. Acta Automat. Sin., 2013, 39(6):697-702 (包为民. 航天飞行器控制技术研究现状与发展趋势[J]. 自动化学报, 2013, 39(6):697-702)
[6]	ZHANG Jinxing, AN Junshe. Study and implementation of automatic ground testing software system based on LabVIEW[J]. J. Comput. Appl., 2016, 36(S2):256-258 (张进兴, 安军社. 基于LabVIEW的自动化地面测试软件系统[J]. 计算机应用, 2016, 36(S2):256-258)
[7]	LI Shan, AN Junshe. Design of ground test system based on PCI bus[J]. Missil. Space Vehicle, 2014, 2:65-70 (李姗, 安军社. 基于PCI总线的航天设备地面测试系统设计[J]. 导弹与航天运载技术, 2014, 2:65-70)
[8]	YU Qiang, WANG Xiaoqing, GENG Baoming, et al. Universal testing system for space science experimental facilities[J]. Chin. J. Space Sci., 2016, 36(4):577-583 (于强, 王小庆, 耿宝明, 等. 空间科学实验通用地面检测系统研制[J]. 空间科学学报, 2016, 36(4):577-583)
[9]	GAO Xiang, YAO Xiujuan, YAN Yi, et al. Design of general ground integrated test intermediate frequency receiver for satellite transmission system[J]. Chin. J. Space Sci., 2018, 38(1):109-117 (高翔, 姚秀娟, 闫毅, 等. 卫星数传分系统通用地检测试中频接收机设计[J]. 空间科学学报, 2018, 38(1):109-117)
