第21～24太阳周4类空间天气事件爆发特征统计分析

苗娟; 李志涛; 任廷领; 王昕

doi:10.11728/cjss2021.06.849

第21～24太阳周4类空间天气事件爆发特征统计分析

doi: 10.11728/cjss2021.06.849 cstr: 32142.14.cjss2021.06.849

苗娟^1,2,
李志涛^1,2,
任廷领^1,2,
王昕^1,2,3

1. 中国科学院国家空间科学中心北京 100190;
2. 中国科学院空间环境态势感知技术重点实验室北京 100190;
3. 中国科学院大学北京 100049

详细信息

作者简介:

苗娟,E-mail:miaoj@nssc.ac.cn

中图分类号: P353
计量
- 文章访问数: 1289
- HTML全文浏览量: 279
- PDF下载量: 70
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2020-06-18
- 修回日期: 2021-04-06
- 刊出日期: 2021-11-15

Statistical Analysis on Four Kinds of Space Weather Events during Solar Cycles 21~24

MIAO Juan^1,2,
LI Zhitao^1,2,
REN Tingling^1,2,
WANG Xin^1,2,3

1. National Space Science Center, Chinese Academy of Sciences, Beijing 100190;
2. Key Laboratory of Science and Technology on Environmental Space Situation Awareness, Chinese Academy of Sciences, Beijing 100190;
3. University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 对第21～24太阳周不同等级的太阳X射线耀斑事件、太阳质子事件、地磁暴事件及高能电子增强事件的爆发频次特征进行统计，结果表明：太阳周耀斑爆发的总数量与该太阳周的黑子数峰值呈正比，耀斑总数、X级耀斑事件数与峰值的相关系数分别为0.974，0.997；太阳质子事件主要发生在峰年前后1～2年，约占总发生次数的80%，峰值通量大于10pfu （1 pfu=1 cm^-2·sr^-1·s^-1）的质子事件中，84%伴有耀斑爆发，并且主要伴随M或X级耀斑，少量伴随C级耀斑，峰值通量大于1000pfu的质子事件中，98%伴随M或X级耀斑，并且以X级耀斑为主；第21，22，23和24太阳周发生地磁暴最频繁的时间分别在1982，1991，2003年和2015年，分别滞后黑子数峰值时间3年、2年、2年和1年；72%的高能电子增强事件发生在太阳周下降期，24%的高能电子增强事件发生在太阳周上升期.
- 太阳周 /
- 太阳X射线耀斑 /
- 太阳质子事件 /
- 地磁暴 /
- 高能电子增强事件
Abstract: Based on the statistics of different intensity levels of solar X-ray flares, solar proton events, geomagnetic storms and relativistic electron flux enhancement of Solar Cycle 21~24, the following conclusions can be drawn. Firstly, the total number of X-ray flares in solar cycle is directly proportional to the number of sunspot maximum, and the correlation coefficients of the total number of flares, X-class flares and sunspot maximum are 0.974 and 0.997, respectively. Secondly, the solar proton events mainly occurred in the first two years before and after the peak year, accounting for 80% of the total number of events. 83% solar proton events with peak flux over 10 pfu (1 pfu=1 cm^-2·sr^-1·s^-1) were mainly accompanied by X-class and M-class flares, but also with a small number of M-class flares. For the solar proton events with the peak flux over 1000 pfu, about 98% of them were accompanied by C-class flares. Thirdly, the most frequent time of geomagnetic storms occurred during Cycle 21, 22, 23 and 24 was in 1982, 1991, 2003 and 2015, respectively, which lagged behind the peak time of sunspot maximum by three years, two years, two years and one year, respectively. Finally, 72% of the relativistic electron flux enhancement occurred in the declining phase of solar cycle, and 24% of them occurred in the rising phase.
- Solar cycle /
- Solar X-ray flares /
- Solar proton events /
- Geomagnetic storm /
- Relativistic electron flux enhancement

HTML全文

参考文献(25)

[1]	LINGRI D, MAVROMICHALAKI D, BELOV A, et al. Solar activity parameters and associated forbush decreases during the minimum between cycles 23 and 24 and the ascending phase of cycle 24[J]. Solar Phys., 2016, 291:1025-1041
[2]	NAT Gopalswamy, HONG Xie, SACHIKO Akiyama, et al. Major solar eruptions and high-energy particle events during solar cycle 24[J]. Earth, Planet. Space, 2014, 66:104
[3]	PRASANNA S S, SHANMUGARAJU A. Study of intensive solar flares in the rise phase of solar cycle 23 and 24 and other activities[J]. Astrophys. Space Sci., 2016, 361:78
[4]	YAN Xu, WERNER Pötzi, HEWEI Zhang, et al. Collective study of polar crown filaments in the past four solar cycles[J]. Astrophys. J. Lett., 2018, 862:23
[5]	LAMY P, FLOYD O, QUÉMERAIS E, et al. Coronal mass ejections and solar wind mass fluxes over the heliosphere during solar cycles 23 and 24(1996-2014)[J]. J. Geophys. Res., 2016, 122:50-62
[6]	LARIO D, DECKER R B, ROELOF E C, et al. Large energetic particle pressures in solar cycles 23 and 24[J]. J. Phys.:Conf. Ser., 2017, 900(1).DOI: 10.1088/17426596/900/1/012012
[7]	GOPALSWAMY N, YASHIRO S, XIE H S, et al. Properties and geoeffectiveness of magnetic clouds during solar cycles 23 and 24[J]. J. Geophys. Res. Space Phys., 2015, 120:9221-9245
[8]	LE Guiming, CAI Ziyu, WANG Huaning, et al. Solar cycle distribution of great geomagnetic storms[J]. Astrophys. Space Sci., 2012, 339:151-156
[9]	BILL Swalwell, SILVIA Dalla, STEPHEN Kahler, et al. The reported durations of GOES Soft X-Ray flares in different solar cycles[J]. Space Weather, 2018, 16:660-666
[10]	LE GuiMing, WANG Hongyan, BAI Tienan. Relationship between solar proton evens and the associated solar flares[J]. Chin. J. Space Sci., 2018, 38(4):437-443(乐贵明, 王鸿雁, 白铁南. 太阳质子事件与太阳耀斑的关系[J]. 空间科学学报, 2018, 38(4):437-443)
[11]	PAULIKAS G A, BLAICE J B. Efects of the solar wind on magnetospheric dynamics:energetic electrons at the 500 synchronous orbit[C]//Quantitative Modeling of Magnetospheric Processes. Washington:AGU, 1979:180-202
[12]	BAKER D N, LI X, TURNER N, et al. Recurrent geomagnetic storms and relativistic electron enhancements in the outer magnetosphere:ISTP coordinated measurements[J]. J. Geophys. Res., 1997, 102(A7):14141-14148
[13]	LI Xinlin, TEMERIN M, BAKER D N, et al. Quantitative prediction of radiation belt electrons at geostationary orbit based on solar wind measurements[J]. Geophys. Res. Lett., 2001, 28(9):1887-1890
[14]	ZHENG Jinlei, ZHONG Qiuzhen, CHEN Liangxu, et al. Analysis on relativistic electron flux enhancement event at GEO in April 2010[J]. Chin. J. Space Sci., 2012, 32(4):488-500(郑金磊, 钟秋珍, 陈良旭, 等. 2010年4月地球同步轨道相对论电子增强事件分析[J]. 空间科学学报, 2012, 32(4):488-500)
[15]	ALEXAKIS P, MAVROMICHALAKI H. Statistical analysis of interplanetary coronal mass ejections and their geoeffectiveness during the solar cycle 23 and 24[J]. Astrophys. Space Sci., 2019, 364:187
[16]	CARRINGTON R C. Description of a singular appearance seen in the sun on September 1, 1859[J]. Month. Not. Royal Astron. Soc., 1859, 20:13-15
[17]	HODGSON R. On a curious appearance seen in the sun[J]. Month. Not. Royal Astron. Soc., 1859, 20:15-16
[18]	GARCIA H A. Temperature and emission measure from GOES soft X-ray measurements[J]. Solar Phys., 1994, 154:275-308
[19]	CLIVER E. Solar flare classification[J]. Encyclopedia Astron. Astrophys., 2000. DOI: 10.1888/0333750888/2285
[20]	TU chuanyi. Solar Terrestrial Space Physics[M]. Beijing:Science Press, 1998(涂传诒. 日地空间物理[M]. 北京:科学出版社, 1998)
[21]	LI Rong, CUI Yanmei, HE Han. Statistic analysis on solar activity parameters with solar flare and solar proton event[J]. Sci. Technol. Eng., 2009, 9(15):4287-4291(李蓉, 崔延美, 贺晗. 太阳活动区参量与太阳耀斑和太阳质子事件的相关性统计分析[J]. 科学技术与工程, 9(15):4287-4291)
[22]	BAKER D N, PULKKINEN T I, LI X, et al. Coronal mass ejections, magnetic clouds, and relativistic magnetospheric electron events:ISTP[J]. J. Geophys. Res., 1998, 103(A8):17279-17291
[23]	BAKER D N. How to cope with space weather[J]. J. Sci., 2002, 297:1486-1487
[24]	LI Xinlin, BAKER D N, TEREMIN M, et al. Rapid enhancements of relativistic electrons deep in the magnetosphere during the May 15, 1997, magnetic storm[J]. J. Geophys. Res., 1999, 104(A3):4467-4476
[25]	XUE Bingsen, YE Zonghai. Forecast of the enhancement of relativistic electron at the geosynchronous orbit[J]. Chin. J. Space Sci., 2004, 24(4):283-288(薛炳森, 叶宗海. 地球同步轨道高能电子增强事件预报方法[J]. 空间科学学报, 2004, 24(4):283-288)
