基于小波变换熵值及高阶累积量联合的卫星信号调制识别算法

闫文康; 闫毅; 范亚楠; 姚秀娟; 高翔; 孙文

doi:10.11728/cjss2021.06.968

基于小波变换熵值及高阶累积量联合的卫星信号调制识别算法

doi: 10.11728/cjss2021.06.968

闫文康^1,2,
闫毅¹,
范亚楠¹,
姚秀娟¹,
高翔¹,
孙文^1,2

1. 中国科学院国家空间科学中心北京 100190;
2. 中国科学院大学北京 100049

基金项目:

中国科学院空间科学战略先导科技专项资助（XDA15060100）

详细信息

作者简介:
闫毅,E-mail:yanyi@nssc.ac.cn

中图分类号: P510.4
计量
- 文章访问数: 307
- HTML全文浏览量: 74
- PDF下载量: 24
- 被引次数: 0
出版历程
- 收稿日期: 2020-07-13
- 修回日期: 2021-03-31
- 刊出日期: 2021-11-15

A Modulation Recognition Algorithm Based on Wavelet Transform Entropy and High-order Cumulant for Satellite Signal Modulation

1. National Space Science Center, Chinese Academy of Sciences, Beijing 100190;
2. University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 调制识别是信号检测与解调的关键环节，针对卫星调制中采用的MAPSK，MQAM，MFSK，MPSK方式，提出了一种计算小波变换熵值并结合高阶累积量的联合调制识别算法.根据小波变换对时频信息敏感的特点，不同调制方式高阶累积量计算结果的区分性以及不同复杂度的调制信号熵值结果不同，分析了以上4类调制信号的计算结果，提出了基于小波变换熵值及高阶累积量联合的卫星信号调制识别算法.计算调制信号小波系数，据此计算熵值，实现对调制信号的类别划分，使用高阶累积量实现类别内的信号分类.经过仿真分析，可实现在8dB以上达到0.9识别率的效果，该方法对高阶（64阶调制）信号识别具有一定借鉴意义.
- 小波变换 /
- 熵 /
- 高阶累积量 /
- 调制识别
Abstract: Modulation recognition is the key link of signal detection and demodulation. Aiming at MAPSK, MQAM, MFSK and MPSK modes used in satellite modulation, a joint modulation recognition algorithm is proposed, which calculates the entropy of wavelet transform and combines highorder cumulant. According to the characteristics of the wavelet transform pair frequency sensitive information, different modulation method to distinguish the results of the calculation of higher-order cumulant and the modulation signal of different complexity entropy results, the calculation results of the above four 4 kinds of modulation signal are analyzed, and entropy is proposed based on wavelet transform and higher-order cumulants joint satellite signal modulation recognition algorithm. Based on the calculated wavelet coefficients of modulation signals, the classification of modulation signals is realized by calculating the entropy value, and the signal classification within the class is realized by using the high-order cumulant. Through simulation analysis, the recognition effect of 0.9 above 8 dB can be achieved. In addition, the method has reference significance for high order (64 order modulation) signals.
- Wavelet transform /
- Entropy /
- High-order cumulant /
- Modulation recognition

HTML全文

参考文献(21)

[1]	YIN C, LI B, LI Y, et al. Modulation classification of MQAM signals based on density spectrum of the constellations(A)[C]//Proceedings of the 20102nd International Conference on Future Computer and Communication. Wuhan:IEEE, 2010
[2]	DOBRE O A, ABDI A, BAR-NESS Y, et al. Survey of automatic modulation classification techniques:classical approaches and new trends[J]. IET Commun., 2007, 1(2):137-156
[3]	WANG Can, FAN Xiaoguang, GU Qiongqiong, et al. A modulation recognition method with low SNR[J]. Guid. Fuze, 2018, 39:15-20
[4]	ALI A K, ERĆ CELEBI E. Automatic modulation recognition of DVB-S2X standard-specific with an APSK-based neural network classifier[J]. Measurement, 2020, 107257:0263-2241
[5]	HAMEED F, DOBRE O A, POPESCU D C. On the likelihood-based approach to modulation classification[J]. IEEE Trans. Wireless Commun., 2009, 8(12):5884-5892
[6]	ZHANG Yanqiu. Modulation recognition of digital signals based on high order cumulants[J]. Inf. Commun., 2016, 2:27-30
[7]	ABDELMUTALAB A, ASSALEH K, EL-TARHUNI M. Automatic modulation classification based on high order cumulants and hierarchical polynomial classifiers[J]. Phys. Commun., 2016, 21:10-18
[8]	ALI A K, ERć CELEBI E. An M-QAM signal modulation recognition algorithm in AWGN channel[J]. Sci. Program., 2019, 2019:1-17
[9]	YUAN Lifen, NING Shuguang, HE Yigang, et al. Modulation recognition method basedon high-order cumulant feature learning[J]. Syst. Eng. Electron., 2019, 41(9):2122-2131
[10]	HO K C, PROKOPIW W, CHAN Y T. Modulation identification of digital signals by the wavelet transform[J]. IEEE Proceed. Radar Sonar Nav., 2000, 147(4):169-176
[11]	LI Xin, ZHANG Chuanwu, GAO Yong. Modulation mode recognition algorithm using logarithm in time-frequency domain[J]. Radio Eng., 2020, 50(12):1036-1041
[12]	TAN Xiaoheng, CHU Guoxing, ZHANG Xuejing, et al. Modulation recognition algorithm based on high-order cumulants and wavelet transform[J]. Syst. Eng. Elect., 2018, 40(1):171-177
[13]	SHU Chang, WANG Chenxue, GAO Yong. Modulation classification of MAPSK and QAM[J]. Commun. Technol., 2012, 45(12):37-40, 47
[14]	DOBRE O A, BAR-NESS Y, SU Wei. Higher-order cyclic cumulants for high order modulation classification[J]. IEEE Military Commun. Conference., 2003, 1:112-117
[15]	CHEN Huixin, PENG Jingjing, ZHENG Liming, et al. A modulation recognition algorithm based on the cumulant and entropy[J]. Guid. Fuze, 2018, 39(3):27-33, 55
[16]	HAZZA A, SHOAIB M, ALSHEBEILI S A, et al. An overview of feature-based methods for digital modulation classification[C]//20131st International Conference on Communications, Signal Processing, and their Applications (ICCSPA). Sharjah:IEEE, 2013
[17]	PARK C S, CHOI J H, NAH S P, et al. Automatic Modulation Recognition of Digital Signals using Wavelet Features and SVM[M]. Gangwon:IEEE, 2008
[18]	HASSAN K, DAYOUB I, HAMOUDA W, et al. Automatic modulation recognition using wavelet transform and neural networks in wireless systems January 2010 EURASIP[J]. J. Adv. Signal Process., 2010, 42. DOI: 10.1155/2010/532898
[19]	LI Yibing, GE Juan, LIN Yun. Modulation recognition using entropy features and SVM[J]. Syst. Eng. Elect., 2012, 34(8):1691-1695
[20]	ZHAO Xiongwen, GUO Chunxia, LI Jingchun. Mixed recognition algorithm for signal modulation schemes by high-order cumulants and cyclic spectrum[J]. J. Elect. Inform. Technol., 2016, 38(3):674-680
[21]	ZHANG Huadi, LOU Huaxun, Automatic modulation recognition algorithm for MQAM signal[J]. J. Commun., 2019, 40(8):200-211
