Numerical Investigation on Collector of Asteroid's Particles with Various Sizes
-
摘要: 采集小天体表面的样品并返回是当前小天体探测的核心目标之一,样品容器流域设计是氮气激励采样技术的关键.为了保证样品容器具备高效的收集性能,要求样品容器的流域设计能够对样品颗粒形成陷阱效应,并对样品颗粒进行有效的分级.旋风式样品收集容器方案利用旋风离心力和引导叶片的共同作用对样品颗粒进行收集和分级.为了验证这种方案在微重力环境下的性能和可行性,本文利用Fluent软件进行了流域的数值模拟.模拟结果表明:在确定容器的结构下,样品容器的最优氮气入口速度为0.6 m·s-1,容器在该速度下的样品收集效率达到99.7%.样品容器的流域具备很好的颗粒分级功能,对小于2mm的样品颗粒的捕获率超过了90%,其压力损失也在合理的范围之内.本文研究结果可为小天体采样任务提供借鉴.Abstract: Collecting and returning samples from the asteroid's surface is one of the significant targets of the current asteroid detection. The key issue of the nitrogen purge sampling technology is the flow field design of the sample container. In order to ensure that the sample container has an efficient collection performance, the flow field design of the sample container must solve two key problems, one problem is the flow field how to form a trap effect on the sample particles, and another problem is the flow field how to effectively classify the sample particles. Therefore, the researchers proposed a scheme of the sample container, which uses the combined effect of centrifugal force and guide blade to collect and classify the sample particles. For verifying the performance and feasibility of this scheme in a microgravity environment, the researchers carried out the numerical simulation with Fluent software. Under the boundary conditions of the container, the simulation program calculated the velocity of nitrogen at the inlet, and the optimal value is 0.6 m·s-1, the efficiency of the container at this velocity reaches 99.7%, the flow field of the sample container also has a good particle classification function, and its capture rate of particles that less than 2mm exceeds 90%. Its pressure loss is also within a reasonable range, the research results of this paper can provide a reference for the upcoming asteroid's sampling task in China.
-
Key words:
- Asteroid /
- Sample collector /
- Multiple particles /
- Numerical investigation
-
[1] KATSUHIKO Tsuno, EISUKE Okumura. Lidar on Board Asteroid Explorer Hayabusa[R]. Tokyo:Institute of Space and Astronautical Science, 2006 [2] HIROTAKA Sawada, RYUJI Okazaki, SHOGO Tachibana, et al. Hayabusa2 sampler:collection of asteroidal surface material[J]. Space Sci. Rev., 2017, 208:81-106 [3] BIERHAUS E B, CLARK B C, HARRIS J W, et al. The OSIRIS-REx spacecraft and the Touch-and-Go Sample Acquisition Mechanism (TAGSAM)[J]. Space Sci. Rev., 2018, 214:80-107 [4] LI Chunlai, LIU Jianjun, YAN Wei, et al. Overview of scientific objectives for minor planets exploration[J]. J. Deep Space Explor., 2019, 6(5):24-36 [5] ZHAO YuHui, WANG Su, HU ShouCun, et al. A research on imaging strategy and imaging simulation of Toutatis in the Chang'E-2 Flyby mission[J]. Acta Astron. Sin., 2013, 54(5):45-52 [6] YU Dengyun, ZHANG Xingwang, ZHANG Ming, et al. Development status and prospect of small celestial body sampling exploration techniques[J]. Spacecraft Eng., 2020, 29(2):9-18 [7] DU Yonggang, YANG Zhenchun, FU Zhaohui. Technology of a sample vacuum encapsulation for deep space exploration[J]. Spacecraft Eng., 2014, 23(5):47-53 [8] DU Yonggang, WANG Xuesong, YAN Chunjie, et al. The parameter calculation of the metal seal structure for the lunar sample encapsulation[J]. Chin. J. Vacuum Sci. Technol., 2021, 41(5):32-34 [9] JI Jianghui, HU Shoucun. A review of the surface environment of small bodies in solar system[J]. Spacecraft Eng., 2019, 36(6):529-531 [10] BORISOV N D, ZAKHAROV A V. Electrostatic charging and motion of dust near the surface of an asteroid[J]. Sol. Syst. Res., 2014, 48(1):22-32 [11] SUGITA S, HONDA R, MOROTA T, et al. The geomorphology, color, and thermal properties of Ryugu:implications for parent-body processes[J]. Science, 2019, 364(6437):398-422 [12] DELLAGIUSTINA D N, EMERY J P, GOLISH D R, et al. Properties of rubble-pile asteroid (101955) Bennu from OSIRIS-REx imaging and thermal analysis[J]. Nat. Astron., 2019, 3(4):341-346 [13] CUI Pingyuan, YUAN Xu, ZHU Shengying, et al. Research progress of small body autonomous landing techniques[J]. J. Astronaut., 2016, 37(7):5-13 [14] SAITO J, MIYAMOTO H, NAKAMURA R, et al. Detailed images of asteroid 25143 Itokawa from Hayabusa[J]. Science, 2006, 312(5778):1341-1344 [15] ZHENG Gangbiao, KANG Tianhe, CHAI Zhaoyun, et al. Applied the Rosin-Rammler distribution function to study on the law of coal dust particle-size distribution[J]. J. Taiyuan Univ. Technol., 2006, 37(5):317-319
