利用青海湖对FY-1C、FY-2B气象卫星热红外通道进行在轨辐射定标
doi: 10.11728/cjss2001.04.20010412 cstr: 32142.14.cjss2001.04.20010412
IN-FLIGHT RADIOMETRIC CALIBRATION FOR THERMAL CHANNELS OF FY-1C AND FY-2B METEOROLOGICAL SATELLITE SENSORS USING QINGHAI LAKE
-
摘要: 介绍利用青海湖水面辐射校正场对FY-1C、FY2B气象卫星热红外通道进行在轨辐射定标.先用CE312野外热红外辐射计在水面测量水表辐亮度,再经大气订正传递到卫星入瞳处,大气订正包括大气吸收削弱和大气产生热发射影响,这两部分对卫星信号的贡献通过辐射传输模式MODTRAN37计算出来.同时进行CE312与卫星通道光谱响应匹配,最终得到卫星入瞳处的表观辐亮度.这个辐亮度与卫星通道的计数值得到该通道绝对定标系数.我们对两颗卫星进行了多次定标,结果表明利用青海湖进行的在轨定标与星上定标系数相差5%左右,相当于3K的亮温差.Abstract: This Paper describe the in-flight radiometric calibration for thermal channels of FY-1C and FY-2B meteorological satellite sensors using Qinghai lake, water surface radiometric calibration site. The radiance of water surface measured by CE312, and then performed atmosphere correct including gas absorption and path radiance which computed by radiance transfer code MODTRAN37, predict the radiance in the satellite sensor entrance pupil. At the same time the spectral response of Satellite sensor and that of ground-based sensor are coupled. At last the apparent radiance of sensor spectral channels are compared to the digital count of satellite's output to give the calibration coefficient. Several calibration is conducted for the satellite thermal sensors of FY serial satellites. The result show the difference between in-flight and on-board calibration is about 5%, equivalent to a brightness temperature of 3 K.
-
-
