Study of sodium layer density over Haikou by Lidar during the night of 4 May 2010
-
摘要: 使用Nd:YAG激光器和泵浦染料激光器产生的589nm激光, 与中高层大气中钠原子产生共振, 利用直径为1000mm的望远镜接收钠层的光子回波. 研究中国海口市2010年5月4日夜间的中高层大气中钠层密度分布, 计算钠层的相对密度和绝对密度, 研究钠层密度峰值变化. 观测到突发钠层出现在23:52LT, 持续12min.Abstract: The basic characters of the sodium layer density at a low-latitude location (Haikou, China, 20°N, 110°E) are described from analysis of sodium lidar observation data. A Nd:YAG laser pumped dye laser is used to generate the probing beam. The wavelength of the dye laser is set to 589nm by a sodium fluorescence cell. The energy and divergence of the beam are about 42mJ and 1mrad, respectively. The repetition rate of Nd:YAG laser is 30Hz. The backscattered fluorescence photons from the sodium layer are collected by a telescope with a 1000mm diameter primary mirror. A sodium layer density profile of upper atmosphere is derived from lidar files collected during the night of 4 May 2010 in Haikou, China. In this paper, the relative density and the absolute one for the sodium layer profile are studied. This result, shows a good correlation with that reported by Beatty at Arecibo, Puerto Rico (18°N, 67°W). A sporadic sodium layer is observed and lasted 12 minutes.
-
Key words:
- Lidar /
- Sodium layer density
-
[1] Megie G. Observations of trace metals in the upper atmosphere in laser remote chemical analysis[M]//Laser Remote Chemical Analysis. New York: John Wiley, 1988. 333-408 [2] Song Juan, Cheng Xuewu, Yang Guotao, et al. The investigation of gravity wave activities on mesopause over Wuhan by sodium lidar[J]. Chin. J. Space Sci., 2005, 25(6):522-528. In Chinese (宋娟, 程学武, 杨国韬, 等. 武汉上空中层顶大气重力波活动的钠层荧光 激光雷达观测研究[J]. 空间科学学报, 2005, 25(6):522-528) [3] Gardner C S. Sodium resonance fluorescence lidar applications in atmospheric science and astronomy[J]. Proc. IEEE, 1989, 77:408-427 [4] She C Y, Yu J R, Latifi H, et al. High-spectral-resolution fluorescence light detection and ranging for mesosphere sodium temperature measurements[J]. Appl. Opt., 1992, 31:2095-2106 [5] Nagasawa C, Abo M. Lidar observations of a lot of sporadic sodium layers in mid-latitude[J]. Geophys. Res. Lett., 1995, 22:263-266 [6] Batista P P, Clemesha B R, Batista I S, et al. Characteristics of the sporadic sodium layers observed at 23oS[J]. J. Geophys. Res., 1989, 94:15349-15358 [7] Batista P P, Clemesha B, Simonich D M. Orizontal structures in sporadic sodium layers at 23 degrees south[J]. Geophys. Res. Lett., 1991, 18:1027-1030 [8] Collins R L, Hallinan T J, Smith R W, et al. Lidar observations of large high-latitude sporadic Na layer during active aurora[J]. Geophys. Res. Lett., 1996, 23:3655-3658 [9] Cox R M, Plane J M C. An ion-molecule mechanism for the formation of neutral sporadic Na layers[J]. J. Geophys. Res., 1998, 103:6349-6359 [10] Gardner C S, Kane T J, Hecht J H, et al. Formation characteristics of sporadic Na layers observed simultaneously by lidar and airglow instruments during ALOHA-90[J]. Geophys. Res. Lett., 1991, 18:1369-1372 [11] Gong S S, Yang G T, Wang J M, et al. Occurrence and characteristics of sporadic sodium layer observed by lidar at a mid-latitude location[J]. J. Atmos. Solar-terr. Phys., 2002, 64:1957-1966 [12] Beatty T J, Collins R L, Gardner C S, et al. Simultaneous radar and lidar observations of sporadic E and Na layers at Arecibo[J]. Geophys. Res. Lett., 1989, 16:1019-1022 -
-
