Discussion on SFODB Application for Spacecraft Data Management
-
摘要: SFODB(Spaceborne Fiber Optic Data Bus)的提出主要是为解决飞行器内部有效载荷数据率日益提高这一迫切问题,它是一种基于商用异步传输模式(ATM)的高速航天数据总线技术,适合于空间探测器的海量数据包传输.其物理拓扑是由光纤链路连接多个FBIU单元以及单个CFBIU单元组成的环形网络,各节点之间的距离不超过100m,基本数据率可从200Mbit·s-1变化至1Gbit·s-1,并具有极高的实时性和可靠性,相比其他总线网络规模小,性能更优.针对SFODB的特性,分析了其发展现状和技术途径,提出了一种在飞行器内部采用SFODB总线作为主干网的数据网络架构,该网络能完成飞行器内部不同数据率载荷的分类分层可靠传输.在此基础上对SFODB的研究与应用提出了建议.Abstract: SFODB is used to solve the data exchange for payload of high data rates in spacecraft and transmit mass detector data, which is proposed by the United States Department of Defense. It is a high-speed aerospace data bus based on commercial Asynchronous Transfer Mode (ATM). In its physical layer, the fiber link connects many FBIU units and single CFBIU unit to compose a ring network. The distance between each node cannot exceed 100m, and the data rate ranges from 200Mbit·s-1 to 1Gbit·s-1. The data bus has very high real-time performance and reliability, and its network size as well as the performance is better than others. This paper introduces the characteristics and latest development status as well as the technical approach of SFODB up to now. It is suggested that an spacecraft internal data bus should be designed as the backbone data network architecture based on SFODB, such as for the satellites and other spacecrafts. The network can complete spacecraft internal reliable data transmission with hierarchical classification for payload. Finally, we give some guidance for research and application of SFODB in the future, some highly reliable design concepts about internal bus in spacecraft may refer SFODB.
-
[1] Chen Zhiguo, Zhang Qiang. Study on international space station information system architecture[J]. Manned Spacefl., 2011(1):5-9. In Chinese (陈志国, 张强. 国际空间站信息系统架构综述[J]. 载人航天, 2011(1):5-9) [2] Buchner S. QSS Group Inc/NASA-GSFC. Evaluation of Commercial Communication Network Protocols for Space Application[R]. Los Angeles: SEEWG, 2003 [3] IEEE 1393-1999. IEEE Standard for Spaceborne Fiber-Optic Data Bus[S], 1999 [4] Zheng Guangwei, Zhao Shanghong, Zhang Hu, et al. Analysis of spaceborne fiber-optic data bus[J]. Opt. Commun. Tech., 2006(1):31-32. In Chinese (郑光威, 赵尚弘, 张虎, 等. 航天光纤数据总线分析[J]. 光通信技术, 2006(1):31-32) [5] Wei Minfeng. The newest technology of data bus in launch vehicle control system[J]. Aeros. Contr., 2007, 25(4):92-96. In Chinese (韦闽峰. 新一代运载火箭控制系统总 线[J]. 航天控制, 2007, 25(4):92-96) [6] Zheng Guangwei. The research evolution of military avionics data bus[J]. Mod. Def. Tech., 2006, 34(4):74-77. In Chinese (郑光威. 军用航空数据总线研究进展[J]. 现代防御技术, 2006, 34(4):74-77) [7] Ni Qiufu. Autopilot of a Model 1553B Interface Design[D]. Beijing: Beijing University of Aeronautics and Astronautics, 2007. In Chinese (黎秋甫. 某型号自动驾驶仪1553B接 口设计[D]. 北京: 北京航空航天大学, 2007) [8] Andrucyk D J , Orlando F J, Charles H. IEEE 1393 Spaceborne Fiber Optic Data Bus ——A Standard Approach to On-board Payload Data Handling Networks[R]. NASA, 99-4507, 1999 [9] Zhou Qingrui, Sun Huixian. On Reliability of Physical Topology for IEEE1394[J]. J. Astron., 2008, 29(4):1408-1413. In Chinese (周庆瑞, 孙辉先. IEEE1394网络拓 扑结构的可靠性研究[J]. 宇航学报, 2008, 29(4):1408-1413) [10] Tan Qinggui, Xu Zhengfang. Space and environment detection satellite borne high data rate fiber-optic data bus[J]. Space Elec. Tech., 2010(1):55-59. In Chinese (谭庆贵, 徐争放. 空间与环境探测星载高速光纤数据总线[J]. 空间电 子技术, 2010(1):55-59) [11] Orlando & Associates, Inc. SFODB Operational & Interface Description[OL]. 1998. http://www.spacephotonics. com/pdfs/white_papers/SFODB_Operational_Interface_ Description_1998.pdf [12] Smith T, Kessler J. Earth orbiter 1-Wide band advanced recorder and processor[C]//Government Microelectronics and Applications. United States, 1999 -
-
