Global 4D Trajectory Optimization Design for Lunar Vertical Soft Landing
-
摘要: 提出一种包含动态规划法与共轭梯度法的组合优化算法，求解月球探测器垂直软着陆问题. 其以动态规划法中求得的次优控制变量作为共轭梯度法的初始控制变量，求得更为精确的最优控制变量和最优轨道. 月球垂直软着陆的轨道可以分为两段，即制动段与着陆段. 以燃料消耗量最小为性能指标，采用该组合优化算法分别对两段轨道进行了4D全局优化. 数值仿真结果表明，该组合算法优化精度较高，收敛速度快，稳定性好，可用于机载计算机实时生成垂直软着陆4D轨道，同时还可推广到其他终端时间自由型两点边值问题.Abstract: A combinatorial algorithm, including dynamic programming and conjugate gradient, was proposed for 4D trajectory global optimization of the lunar probe vertical soft landing. By employing the suboptimum control variable calculated from dynamic programming as the initial control variable of conjugate gradient algorithm, the more precise optimum control variable and flight trajectories were obtained. The lunar probe vertical soft landing trajectory consists of two segments, i.e., the brake and landing segments. The performance index is to minimize fuel consumption of the lunar detector. The 4D trajectory of lunar vertical soft landing is optimized by this combinatorial optimization algorithm. Simulation results showed good accuracy, rapid convergence, and robustness with initial values for this combinatorial algorithm, which promise it to on-line generate a feasible vertical soft landing trajectory on the onboard computer. Meanwhile, the combinatorial algorithm could be extended to other two-point boundary value problems of terminal time uncontrolled type.
-
[1] Wang Pengji, Zhang He, Qu Guangji. Design and optimization of the descending trajectory and guidance of lunar soft-landing[J]. J. Astron., 2007, 28(5):1175-1179. In Chinese (王鹏基, 张熇, 曲广吉. 月球软着陆下降轨迹与制导律优化 设计研究[J]. 宇航学报, 2007, 28(5):1175-1179) [2] Nishio Y, Namura E, Itagaki H, et al. Outline of the experimental lunar lander in SELENE project[J]. Adv. Astron. Sci., 1997, 96:307-313 [3] Wang D Y, Li T S, Ma X R, et al. Neuro-optimal guidance control for lunar soft-landing[J]. J. Syst. Eng. Electron., 1999, 10(3):22-31 [4] Wang D Y, Qiao G D, Li T S. FNN guidance control for lunar optimal trajectory tracking descent[J]. J. Astron., 2007, 28(5):1149-1155 [5] Sun Junwei, Qiao Dong, Cui Pingyuan. Study on the Optimal Trajectories of Lunar Soft-Landing with Fixed-Thrust Using SQP Method[J]. J. Astron., 2006, 27(1):99-103. In Chinese (孙军伟, 乔栋, 崔平远. 基于 SQP方法的定常推力月球软着陆 轨道优化方法[J]. 宇航学报, 2006, 27(1):99-103) [6] Wang Mingguang, Pei Tingguo, Yuan Jianping. Legendre pseudospectral method for rapid lunar soft-landing trajectory optimization[J]. Chin. Space Sci. Technol., 2007, 27(5):27-32. In Chinese (王明光, 裴听国, 袁建平. 基于伪 光谱方法月球软着陆轨道快速优化设计[J]. 中国空间科学技术, 2007, 27(5):27-32) [7] Zhu Jianfeng, Xu Shijie. Optimization of lunar soft landing trajectory based on adaptive simulated annealing genetic algorithm[J]. Acta Aeron. Astron. Sin., 2007, 28(4):806-812. In Chinese (朱建丰, 徐世杰. 基于自适应模 拟退火遗传算法的月球软着陆轨迹优化[J]. 航空学报, 2007, 28(4):806-812) -
