空间惯性定向姿态卫星数传链路设计

熊蔚明; 程鑫; 叶云裳; 姚晔

doi:10.11728/cjss2014.04.483

空间惯性定向姿态卫星数传链路设计

doi: 10.11728/cjss2014.04.483

熊蔚明^1, ,,
程鑫¹,
叶云裳²,
姚晔³

1.
中国科学院空间科学与应用研究中心北京 100190
2.
中国空间技术研究院神舟学院北京 100191
3.
上海微小卫星工程中心上海 200050

基金项目: 国家高技术研究发展计划项目资助（2009AA7080306）

详细信息

通讯作者:
熊蔚明,E-mail:xwm@nssc.ac.cn

中图分类号: V443
计量
- 文章访问数: 1658
- HTML全文浏览量: 96
- PDF下载量: 1648
- 被引次数: 0
出版历程
- 收稿日期: 2013-09-10
- 修回日期: 2014-03-19
- 刊出日期: 2014-07-15

Payload Data Transmission Link Design for the Satellite with Attitude of Inertial Space Orientation

1.
Center for Space Science and Applied Research, Chinese Academy of Sciences, Beijing 100190
2.
Shengzhou Institute of China Academy of Space Technology, Beijing 100191
3.
Shanghai Engineering Center for Microsatellites, Shanghai 200050

摘要

摘要: 对于采用空间惯性定向姿态的卫星，其在数传设备工作期间不能保证固定安装在星体上的发射天线波束准确指向地面站，这给有效载荷高速数传提出更高技术要求. 研究了这类卫星在轨运行时其姿态相对地面站的变化规律，利用STK软件提供的卫星轨道仿真分析结果，寻找数传天线波束中心轴的较好指向，得到不同天线波束宽度能够实现的卫星对地数传时间. 通过研制140°波束范围内0dBi增益天线，在链路设计上保证了传输速率85Mbit·s^-1时有足够的余量. 在星载设备小型化约束（质量10kg、功耗80W）条件下，采用小型化宽波束天线以及固态功放解决了空间惯性定向姿态卫星的有效载荷数据传输问题，设计方案满足相关任务要求.
- 有效载荷数据传输 /
- 惯性空间定向 /
- 卫星 /
- 轨道仿真 /
- 天线波束 /
- 天线增益
Abstract: Satellites whose attitude is inertial space orientation cannot keep the transmitting antenna beam accurately pointing to the ground stations when the data transmitting device in the satellite is working. As a result, a new technical challenge of transmitting the payload data from the satellite to the ground stations in a high speed is brought forward. In this paper, a method using the transmitting antenna whose beam has proper width and pointing direction to resolve the problem is dedicated. For this aim, by simulating the satellite orbit with STK software, variation of the relative attitude of such satellites to the ground stations, as well as comparison on the data transmission time from the satellite to the ground stations at different beam width of the transmitting antenna, are researched. The key research is to develop an antenna whose gain is 0dBi in 140° angle of beam, and the link is designed to ensure a sufficient margin at the transmission rate of 85Mbit·s^-1. As a result, under the constraint of space avionics miniaturization (10kg of mass, 80W of power consumption), the miniaturized antenna with wide beam and the solid-state power amplifier are designed to solve the problem of payload data transmission of satellites whose attitude is inertial space orientation.
- Payload data transmission /
- Inertial space orientation /
- Satellite /
- Orbit simulation /
- Antenna beam /
- Antenna gain

HTML全文

参考文献(4)

[1]	Jiang Chang, Fan Xiaoling. Space Communication Tracking Technology Introduction[M]. Beijing: Beijing University of Technology Press, 2003: 163-182. In Chinese (姜昌, 范晓玲. 航天通信跟踪技术导论[M]. 北京: 北京工业大学出版社, 2003: 163-182)
[2]	Han Congying. Researches on the Attitude Determination and Control System of a Small Astronomical Satellite[D]. Xi'an: Northwestern Polytechnical University, 2004. In Chinese (韩聪颖. 小型天文卫星高精度姿态确定和控制技术研究[D]. 西安: 西北工业大学, 2004)
[3]	Yang Ying, Wang Qi. Application of STK in Computer Simulation[M]. Beijing: National Defense Industry Press, 2005: 69-99. In Chinese (杨颖, 王琦. STK在计算机仿真中的应用[M]. 北京: 国防工业出版社, 2005: 69-99)
[4]	Chen Yiyuan, Yin Liming. Satellite Radio Telemetry, Tracking and Control Technology[M]. Beijing: China Astronautic Publishing House, 2007: 1-42. In Chinese (陈宜元, 殷礼明. 卫星无线电测控技术[M]. 北京: 中国宇航出版社, 2007: 1-42)
