Assessment of Thermosphere Models Based on Orbit Prediction
-
摘要: 在太阳活动高低年的地磁平静/扰动环境下，利用不同热层大气模式J77，DTM78，MSIS00，JB2008和CHAMP加速度计反演密度，分析有无先验信息条件下的轨道预报误差.结果表明无先验信息的精密轨道预报中，热层模式的性能可能被弹道系数等参数偏差干扰，此时预报误差不能作为模式性能的评价标准.先验信息对轨道预报精度提升非常明显，尤其是地磁扰动期先进热层模式性能得以展现，轨道预报误差为无先验信息情况下的10%～25%.目前热层模式的主要缺陷存在于地磁扰动期.各模式之间的差异是：JB2008模式可以通过线性和单一频率周期项补偿，而J77及DTM78等模式还存在更多频率的误差.本文对不同情况下精密轨道预报的研究结果可为空间碎片碰撞预警等工程实践提供参考.Abstract: The LEO prediction error was studied with thermosphere models including J77, DTM78, MSIS00, JB2008 and the CHAMP derived density. In precise orbit prediction without prior information, the performance of the thermosphere model may be erased by uncertainties of those parameters such as the area mass ratio, and the prediction error cannot be used as the criteria for performance evaluation of those models. The prior information can be used to improve the accuracy of those orbit predictions, especially during the geomagnetic disturbed period. The orbit prediction error is averagely about 10%~25% compared with the situation without prior information. The main defects of thermosphere models exist currently in the geomagnetic disturbed period. The difference between models is that JB2008 model can be compensated by single frequency plus linear items, but J77, DTM78 models can't. This paper introduces new insights to the precise orbit prediction under different conditions, which can be used as tutorial materials to provide reference for the engineering practice of space debris collision warning.
-
Key words:
- Thermosphere models /
- GPS data /
- Prediction error /
- Priori information
-
[1] ZHOU Shuai, CHENG Guosheng, LI Li, et al. Research on modification of atmospheric density[J]. Manned Spaceflight, 2014, 1:43-49(周率, 程国胜, 李黎, 等. 载人航天轨道大气密度模式修正研究[J]. 载人航天, 2014, 1:43-49) [2] BOWMAN B, TOBISKA W K, MARCOS F, et al. A new empirical thermospheric density model JB2008 using new solar and geomagnetic indices[C]//AIAA/AAS Astrodynamics specialist conference and exhibit. 2008:6438 [3] SEAN Bruinsma. The DTM-2013 thermosphere model[J]. J. Space Weather Space Clim., 2015, 5(A1):8 [4] LIU Wei, WANG Ronglan, LIU Siqing, et al. Error analysis of typical atmospheric density model[J]. Chin. J. Space Sci., 2017, 37(5):538-546(刘卫, 王荣兰, 刘四清, 等. 典型热层密度模式误差分析[J]. 空间科学学报, 2017, 37(5):538-546) [5] WU Yuan, LI Jiawei, ZHANG Xiaoxin, et al. Comparison and analysis of the thermospheric density between TIEGCM and CHAMP during a severe geomagnetic storm[J]. Chin. J. Space Sci., 2014, 34(1):81-88(吴媛, 李嘉巍, 张效信, 等. 强磁暴期间TIEGCM模式与CHAMP卫星热层大气密度的比较分析[J]. 空间科学学报, 2014, 34(1):81-88) [6] ZHOU Xu, WAN Weixing, ZHAO Biqiang, et al. Empirical Orthogonal Function (EOF) analysis on the thermospheric total mass density retrieved from CHAMP observation[J]. Chin. J. Space Sci., 2010, 30(3):228-234(周旭, 万卫星, 赵必强, 等. 基于CHAMP卫星观测数据对热层大气密度的经验正交分析[J]. 空间科学学报, 2010, 30(3):228-234) [7] ZHANG Xiaofang, LIU Libo, LIU Songtao, et al. A statistical study on the response of thermospheric total mass density to geomagnetic storms[J]. Chin. J. Geophys., 2015, 58(9):3023-3037(张晓芳, 刘立波, 刘松涛, 等. 磁暴期间热层大气密度变化[J]. 地球物理学报, 2015, 58(9):3023-3037) [8] WANG Hongbo, ZHAO Changyin. Use CHAMP/STAR accelerometer data to evaluate atmospheric density models during solar maximum year[J]. Acta Astronom. Sin., 2008, 49(2):168-178(汪宏波, 赵长印. 用CHAMP加速仪数据校验太阳活动峰年的大气模型精度[J]. 天文学报, 2008, 49(2):168-178) [9] LI Yongping, ZHU Guangwu, QIN Guotai, et al. Significant difference of the thermospheric density between the model and observation values of satellite during different geomagnetic storm events and different altitudes[J]. Chin. J. Geophys., 2014, 57(11):3703-3714(李永平, 朱光武, 秦国泰, 等. 不同高度和不同地磁扰动期间热层大气密度模式值与探测值的显著差异[J]. 地球物理学报, 2014, 57(11):3703-3714) [10] QIU Hongxing, WU Lianda, ZHANG Wei. Comparison of atmospheric density models for leo satellite orbit determination and orbit forecast[J]. J. Spacecraft Tt&c Technol., 2006, 25(4):12-18 [11] LIU Wei, WANG Ronglan, LIU Siqing, et al. Accuracy analysis of LEO forecast under four typical space environment[J]. Manned Spaceflight, 2017, 23:177-184 [12] XU Tianhe, YANG Yuanxi. Use and precision evaluation of CHAMP rapid science orbit[J]. J. Geodesy Geodynam., 2004, 1:81-84 -
-
