Seasonal Variations of Mesospheric Densities Observed by Rayleigh Lidar at Golmud, Qinghai
doi: 10.11728/cjss2020.02.207
Seasonal Variations of Mesospheric Densities Observed by Rayleigh Lidar at Golmud, Qinghai
-
摘要: From Aug. 2013 to Oct. 2015, a Rayleigh lidar has been used to study the middle atmosphere at Golmud (36.25°N, 94.54°E), Qinghai, located in the northeastern part of the Tibetan Plateau. Mesospheric density profiles from 50 to 90 km were retrieved based on 205 nights of lidar observation, with a total of 1616 hours of operation. We compared our lidar density measurements with SABER observations onboard TIMED satellite and MSIS-00 model data. The results showed that the annual mean density measured by lidar agreed well with SABER data, but both were lower than that of MSIS-00. All datasets exhibited dominant annual oscillation in the mesosphere. From 63 to 85 km, the annual amplitude of lidar density is larger than those of SABER and MSIS-00. PDD (Percentage of Density Difference) was calculated to investigate the mesospheric density climatology. The largest density variations of lidar, MSIS-00, and SABER occurred at around 72 km. Both lidar and SABER PDD reached their maximum in May, about one month earlier than the MSIS-00; while the minimum PDD appeared in late December for all datasets.
-
关键词:
- Lidar /
- SABER /
- MSIS model /
- Mesospheric density /
- Seasonal variations
Abstract: From Aug. 2013 to Oct. 2015, a Rayleigh lidar has been used to study the middle atmosphere at Golmud (36.25°N, 94.54°E), Qinghai, located in the northeastern part of the Tibetan Plateau. Mesospheric density profiles from 50 to 90 km were retrieved based on 205 nights of lidar observation, with a total of 1616 hours of operation. We compared our lidar density measurements with SABER observations onboard TIMED satellite and MSIS-00 model data. The results showed that the annual mean density measured by lidar agreed well with SABER data, but both were lower than that of MSIS-00. All datasets exhibited dominant annual oscillation in the mesosphere. From 63 to 85 km, the annual amplitude of lidar density is larger than those of SABER and MSIS-00. PDD (Percentage of Density Difference) was calculated to investigate the mesospheric density climatology. The largest density variations of lidar, MSIS-00, and SABER occurred at around 72 km. Both lidar and SABER PDD reached their maximum in May, about one month earlier than the MSIS-00; while the minimum PDD appeared in late December for all datasets.-
Key words:
- Lidar /
- SABER /
- MSIS model /
- Mesospheric density /
- Seasonal variations
-
[1] LABITZKE K. Temperature changes in the mesosphere and stratosphere connected with circulation changes in winter[J]. J. Atmos. Sci., 1972, 29(4):756-766 [2] ROBLE R G, DICKINSON R E. How will changes in carbon dioxide and methane modify the mean structure of the mesosphere and thermosphere[J]. Geophys. Res. Lett., 1989, 16:1441-1444 [3] HOLTON J R. The influence of gravity wave breaking on the general circulation of the middle atmosphere[J]. J. Atmos. Sci., 1983, 40(10):2497-2507 [4] LIU H L, ROBLE R G. A study of a self-generated stratospheric sudden warming and its mesospheric lower thermospheric impacts using the coupled TIME-GCM/CCM3[J]. J. Geophys. Res., 2002, 107(D23):4695 [5] YUAN T, THURAIRAJAH B, SHE C Y, et al. Wind and temperature response of midlatitude mesopause region to the 2009 Sudden Stratospheric Warming[J]. J. Geophys. Res., 2012, 117:D09114 [6] SOX L, WICKWAR V, FISH C, et al. Temperature deviations in the midlatitude mesosphere during stratospheric warmings as measured with Rayleigh-scatter lidar[C]//The 27th International Laser Radar Conference. New York:the International Laser Radar Conference, 2015:1441-1444 [7] HEDIN A E, SALAH J E, EVANS J V, et al. A global thermospheric model based on mass spectrometer and incoherent scatter data, MSIS 1. N2 density and temperature[J]. J. Geophys. Res., 1977, 82:2139-2147 [8] PICONE J M, HEDIN A E, DROB D P, et al. NRLMSISE-00 empirical model of the atmosphere:statistical comparisons and scientific issues[J]. J. Geophys. Res., 2002, 107(A12):1468 [9] LING C, CHEN Z. Monthly averaged atmospheric conditions in the transition flow region of China based on the NRLMSISE-00 model[J]. Spacecraft Environ. Eng., 2015, 32(3):236-242 [10] MCLRESS C, SHEPHERD G G, SOLHEIM B H, et al. Combined mesosphere/thermosphere winds using WINDII and HRDI data from the Upper Atmosphere Research Satellite[J]. J. Geophys. Res., 1996, 1011(D6):10441-10454 [11] SHE C Y, CHEN S, HU Z, et al. Eight-year climatology of nocturnal temperature and sodium density in the mesopause region (80 to 105 km) over Fort Collins, Co (41°N, 105°W)[J]. Geophys. Res. Lett., 2000, 27(20):3289-3292 [12] SIVAKUMAR V, PRASANTH P V, KISHORE P, et al. Rayleigh LIDAR and satellite (HALOE, SABER, CHAMP and COSMIC) measurements of stratospheremesosphere temperature over a southern sub-tropical site, Reunion (20.8°S; 55.5°E):climatology and comparison study[J]. Ann. Geophys., 2011, 29(4):649-662 [13] BRUINSMA S, FORBES J M, NEREM R S, et al. Thermosphere density response to the 20-21 November 2003 solar and geomagnetic storm from CHAMP and GRACE accelerometer data[J]. J. Geophys. Res., 2006, 111:A06303 [14] EMMERT J T, PICONE J M, MEIER R R. Thermospheric global average density trends, 1967-2007, derived from orbits of 5000 near-Earth objects[J]. Geophys. Res. Lett., 2008, 35:L05101 [15] SOLOMON S C, QIAN L, DIDKOVSKY L V, et al. Causes of low thermospheric density during the 2007-2009 solar minimum[J]. J. Geophys. Res., 2011, 116:A00H07 [16] QIAN L, SOLOMON S C. Thermospheric density:an overview of temporal and spatial variations[J]. Space Sci. Rev., 2012, 168(1/2/3/4):1-27 [17] JONES L M, PETERSON J W, SCHAEFER E J, et al. Upper-air density and temperature:some variations and an abrupt warming in the mesosphere[J]. J. Geophys. Res., 1959, 64(12):2331-2340 [18] THIELE O W. Observed diurnal oscillations of pressure and density in the upper stratosphere and lower mesosphere[J]. J. Atmos. Sci., 1966, 23(4):424-430 [19] YI W, XUE X, REID I M, et al. Climatology of the mesopause relative density using a global distribution of meteor radars[J]. Atmos. Chem. Phys., 2019, 19:7567-7581 [20] RUSSELL J M, MLYNCZAK M G, GORDLEY L L. Overview of the Sounding of the Atmosphere Using Broadband Emission Radiometry (SABER) experiment for the Thermosphere-Ionosphere-Mesosphere Energetics and Dynamics (TIMED) mission[J]. Opt. Photonics, 1994. DOI: 10.1117/12.187579 [21] FECHINE J, WRASSE C M, TAKAHASHI H, et al. Lower-mesospheric inversion layers over Brazilian equatorial region using TIMED/SABER temperature profiles[J]. Adv. Space Res., 2007, 41(9):1447-1453 [22] XIAO C, HU X, YANG J, et al. Characteristics of atmospheric density at 38°N in near space and its modeling technique[J]. J. Beijing Univ. Aeronaut. Astronaut., 2017, 43(9):1757-1765 [23] HAUCHECORNE A, CHANIN M L. Density and temperature profiles obtained by lidar between 35 km and 70 km[J]. Geophys. Res. Lett., 1980, 7:565-568 [24] SHIBATA T, KOBUCHI M, MAEDA M. Measurements of density and temperature profiles in the middle atmosphere with a XeF lidar[J]. Appl. Optics, 1986, 25(5):685-688 [25] DAO P, KLEMETTI W, SIPLER D, et al. Density measurements with combined Raman-Rayleigh lidar[J]. Proc. SPIE Int. Soc. Opt. Eng., 1988, 1062:138-143 [26] WU Y, HU H, HU S, et al. Atmospheric density and temperature measurement with lidar in the middle and upper stratosphere[J]. Chin. J. Quant. Electron., 2000, 17(5):426-431 [27] BARTON D L, WICKWAR V B, HERRON J P, et al. Variations in mesospheric neutral densities from rayleigh lidar observations at Utah State University[C]//The 27th International Laser Radar Conference. New York:the International Laser Radar Conference, 2015 [28] QIAO S, PAN W, ZHU K, et al. Initial results of lidar measured middle atmosphere temperatures over Tibetan Plateau[J]. Atmos. Oceanic Sci. Lett., 2014, 7:213-217 [29] QIAO S, PAN W, BAN C, et al. Mesospheric density measured by Rayleigh lidar over Golmud[J]. Infrared Laser Eng., 2018, 47(S1):S106005-1-6 [30] LOMB N R. Least-squares frequency analysis of unequally spaced data[J]. Astrophys. Space Sci., 1976, 39, 447-462 [31] PAN W, GARDNER C S. Seasonal variations of the atmospheric temperature structure at South Pole[J]. J. Geophys. Res., 2003, 108(D18):4564
