北京上空冬季潮汐波活动特征全天时激光雷达探测研究

鲁正华; 杨国韬; 王继红; 焦菁; 荀宇畅

doi:10.11728/cjss2020.02.215

北京上空冬季潮汐波活动特征全天时激光雷达探测研究

doi: 10.11728/cjss2020.02.215 cstr: 32142.14.cjss2020.02.215

1. 中国科学院国家空间科学中心空间天气学国家重点实验室北京 100190;
2. 中国科学院大学北京 100049

基金项目:

国家自然科学基金项目（41474130，41627804，41604130），北京市科技计划项目（Z181100002918001），中国科学院国家空间科学中心重点培育项目和国家重点实验室专项项目共同资助

详细信息

作者简介:

鲁正华,E-mail:gtyang@spaceweather.ac.cn

中图分类号: P351
计量
- 文章访问数: 1070
- HTML全文浏览量: 153
- PDF下载量: 74
- 被引次数:
  0(来源:Crossref)

  0(来源:其他)
出版历程
- 收稿日期: 2019-03-25
- 修回日期: 2019-12-06
- 刊出日期: 2020-03-15

Daytime Sodium Lidar Observations and Studies of the Tidal Characteristics in Winter over Beijingormalsize

1 State Key Laboratory of Space Weather, National Space Science Center, Chinese Academy of Sciences, Beijing 100190;
2 University of Chinese Academy of Sciences, Beijing 100049

摘要

摘要: 利用北京延庆子午工程激光雷达对北京上空钠层进行长期连续观测，分析研究钠层及其相关参数的周日变化.提取钠层各个高度上的相位信息，与同时段经向风潮汐信息进行比较发现：在各个高度上，二者周日相位数值基本一致.半日相位对比结果表明，虽然存在差异，但整体仍保持较好的一致性.此外，从2014年至2016年每年10月到第二年1月共4个月的钠层连续观测数据中提取钠层周日和半日的振幅和相位，探究北京上空冬季的潮汐特征.结果显示：周日潮的相位自上向下传播，且无明显的季节变化特征，其垂直波长在40～50km的范围；周日潮较强，半日潮较弱.
- 激光雷达 /
- 连续观测 /
- 潮汐波
Abstract: Based on continuous observation of the sodium layer from lidar located in Yanqing, Beijing, the diurnal variation of the sodium layer and its relevant parameters can be analyzed. Comparing the phase information of sodium density from every altitude with the information from meridian wind at the same time, it can be found that the two diurnal phases are consistent with each other. Although the two semi-diurnal phases exist a little bit difference, as a whole, they two agree very well. Extracting the phase and amplitude from continuous sodium observation data from October to January from 2014 to 2016, tidal characters in fall over Beijing can be studied. The results show diurnal tide phases have unobvious seasonal variation and propagate upward with vertical wavelengths between 30 and 50km. Besides, the diurnal tide is stronger than the semidiurnal tide.
- Lidar /
- Continuous observation /
- Tide wave

HTML全文

参考文献(20)

[1]	PLANE J M C, GARDNER C S, YU J, et al. Mesospheric Na layer at:modeling and observations[J]. J. Geophys. Res.:Atoms., 1999, 104(D3):3773-3788
[2]	KANE T J, GARDNER C S. Lidar observations of the meteoric deposition of mesospheric metals[J]. Science, 1993, 259:1297-1300
[3]	BATISTA P, CLEMESHA B, SIMONICH D, et al. Tidal oscillations in the atmospheric sodium layer[J]. J. Geophys. Res.:Atoms., 1985, 90:3881-3888
[4]	GARDNER C S, VOELZ D G. Lidar studies of the nighttime sodium layer over Urbana Illinois, 2, Gravity waves[J]. J. Geophys. Res.:Space Phys., 1987, 92:4673-4693
[5]	GARDNER C S. Sodium resonance fluorescence lidar applications in atmospheric science and astronom[J]. Proc. IEEE, 1989, 77:408-418
[6]	YANG G, CLEMESHA B, BATISTA P, et al. Gravity wave parameters and their seasonal variations derived from Na lidar observations at 23°S[J]. J. Geophys. Res.:Atoms.,2006, 111(D21).DOI: org/10.1029/2005JD006900
[7]	GIBSON A J, SANDFORD M C W. Day-time laser radar measurement of the atmospheric sodium layer[J]. Nature, 1972, 239:509-511
[8]	GRANIER C, MEGIE G. Daytime lidar measurement of the mesospheric sodium layer[J]. Planet. Space Sci., 1982, 30:169-177
[9]	CLEMESHA B, SIMONICH D, BATISTA P, et al. The diurnal variation of atmospheric sodium layer[J]. J. Geophys. Res. Space Phys., 1982, 87:181-186
[10]	SHE C Y. Tidal perturbations and variability in the mesopause region over Fort Collins, CO (41°N,105°W)[J]. Geophys. Res. Lett., 2004, 31:L24111
[11]	YUAN T, SHE C Y, KAWAHARA T D, et al. Seasonal variations of mid-latitude mesospheric Na lidar and their tidal period perturbations based on full diurnal cycle Na lidar observations of 2002-2008[J]. J. Geophys. Res.:Atoms., 2012, 117:D11304
[12]	JIANG Guoying, XU Jiyao, et al. The first observation of the atmospheric tides in the mesosphere and lower thermosphere over Hainan[J]. Chin. Sci Bull., 2010, 55(10):923-930(姜国英, 徐寄遥. 我国海南上空中高层大气潮汐风场的首次观测分析[J]. 中国科学, 2010, 55(10):923-930)
[13]	XIONG J G, WAN W, NING B, et al. First results of the tidal structure in the MIT revealed by Wuhan meteor radar[J]. J. Atmos. Sol.:Terr. Phys., 2004, 66:675-682
[14]	BATISTA P P, CLEMESHA B R, TOKUMOTO A S, et al. Structure of the mean winds and tides in the meteor region over Cachoeira Paulista, Brazil (22.7°S, 45°W) and its comparison with models[J]. J. Atmos. Sol.:Tberr. Phys., 2004, 66(6-9):623-636
[15]	CHENG X, GONG S, Li F, et al. 24h continuous observation of sodium layer over Wuhan by lidar[J]. Sci. China Ser. G:Phys. Mech. Astron., 2007, 50:287-293
[16]	GARDNER C S, SHELTON J D. Density response of neutral atmospheric to gravity wave perturbations[J]. J. Geophys. Res.:Space Phys., 1985, 90:1745-1754
[17]	SONG Juan, CHENG Xuewu, YANG Guotao, et al. The investigation of gravity wave activities on mesopause over Wuhan by sodium lidar[J]. China. J. Space Sci., 2005, 25(6):522-528(宋娟, 程学武, 杨国韬, 等. 武汉上空中层顶大气重力波活动的钠层荧光激光雷达观测研究[J]. 空间科学学报, 2005, 25(6):522-528)
[18]	KWON K, GARDNER C, SENFT D, et al. Daytime lidar measurements of tidal winds in the mesospheric sodium layer at Urbana, Illinois[J]. J. Geophys. Res.:Space Phys., 1987, 92:8781-8786
[19]	CLEMESHA B R, BATISTA P P, SIMONICH D M. Tide induced oscillations in the atmospheric sodium layer[J]. J. Atmos. Sol.:Terr. Phys., 2002, 64:1321-1325
[20]	LU Honghui, YANG Guotao, WANG Jihong, et al. Investigation of tidal wave activities over Wuhan by daytime sodium lidar[J]. Chin. J. Quant. Electron., 2013, 30(1):17-24(卢洪辉, 杨国韬, 王继红, 等. 武汉上空潮汐波活动的全天时钠激光雷达研究[J]. 量子电子学报, 2013, 30(1):17-24)
