国际参考电离层模型输出参数峰值高度性能

唐丝语; 周春红; 黄智; 袁洪

doi:10.11728/cjss2021.06.898

国际参考电离层模型输出参数峰值高度性能

doi: 10.11728/cjss2021.06.898

1. 江苏师范大学物理与电子工程学院徐州 221116;
2. 中国科学院空天信息创新研究院北京 100094

基金项目:

国家自然科学基金项目（41104096）和徐州科技计划项目（KC21159）共同资助

详细信息

作者简介:
黄智,E-mail:huangz@jsnu.edu.cn

中图分类号: P352
计量
- 文章访问数: 350
- HTML全文浏览量: 62
- PDF下载量: 17
- 被引次数: 0
出版历程
- 收稿日期: 2020-07-16
- 修回日期: 2021-04-22
- 刊出日期: 2021-11-15

Ionosphere Peak Height Prediction Performance of International Reference Ionosphere Model

1. School of Physics and Electronic Engineering, Jiangsu Normal University, Xuzhou 221116;
2. Aerospace Information Research Institute, Chinese Academy of Sciences, Beijing 100094

摘要

摘要: 电离层峰值高度H_mF₂是描述电离层形态的重要参数之一，国际参考电离层模型IRI-2016中融入了大量电离层测高仪和无线电掩星探测数据，用以提升H_mF₂的预测精度.本文利用太阳活动低年（2007—2010年）气象、电离层和气候卫星联合观测系统COSMIC探测数据描述全球范围内COSMIC H_mF₂的三维形态变化，对比分析了IRI-2016与IRI-2012模型的预测结果，同时分析了IRI-2016模型输出H_mF₂的性能.结果表明，IRI模型在中高纬度地区的输出结果高于COSMIC反演结果，而赤道及低纬地区则大都偏低.与IRI-2012模型相比，IRI-2016模型的输出结果在夜间至凌晨时段呈现较为明显的纬向梯度变化且大部分区域输出值偏高，但在白天时段赤道附近区域的输出值大都偏低.上述结果为电离层IRI模型的完善提供了一定参考.
- COSMIC /
- 电离层 /
- IRI模型 /
- 峰值高度
Abstract: Because ionospheric peak height H_mF₂ is one of the important parameters describing the ionospheric morphology, new models based on digisonde station data and radio occultation data was included in the latest version IRI-2016, and the changes and improvements of the H_mF₂ prediction would be expected. In this work, Global three dimension variations of H_mF₂ from the Constellation Observing System for Meteorology, Ionosphere and Climate (COSMIC) are described using the 4- year dataset during the period of 2007-2010. Meanwhile, H_mF₂ predictions by the model IRI-2016 and IRI-2012 are analyzed in order to evaluate the performance of IRI-2016. Comparisons between COSMIC and IRI show that IRI-derived H_mF₂ values are high in the middle and high latitude regions and whereas they are relatively low in the equator and low latitude regions. During the period of midnight, H_mF₂ by IRI-2016 is characteristic of latitudinal gradient, and notably is higher than that by IRI-2012 in the part of the mid-high and the low-latitude regions. However, H_mF₂ from model IRI-2016 in most equator regions and low-latitudes is lower than IRI-2012 in the daytime. Analysis of ionospheric H_mF₂ provides valuable references for the future improvement of ionosphere model.
- COSMIC /
- Ionosphere /
- IRI model /
- H_mF₂

HTML全文

参考文献(20)

[1]	LIU Lei, ZOU Shasha, YAO Yibin, et al. Forecasting global ionospheric TEC using deep learning approach[J]. Space Weather, 2020, 18(11).DOI: 10.1029/2020SW002501
[2]	MADEEHA Talha, NABEEL Ahmed, MUNEEZA M A, et al. Variability of H_mF₂ during solar minima at the Equatorial Ionization Anomaly crest region[J]. Adv. Space Res., 2019, 64(11):2321-2330
[3]	YANG K F, CHU Y H, SU C L, et al. An examination of FORMOSAT-3/COSMIC ionospheric electron density profile:data quality criteria and comparisons with the IRI model[J]. Terrestrial, 2009, 20(1).DOI:10. 3319/TAO.2007.10.05.01
[4]	WU Mengjie, XU Xu, LI Fenghui, et al. Plasmaspheric scale height modeling based on COSMIC radio occultation data[J]. J. Atmos. Sol.:Terr. Phys., 2021, 217.DOI: 10.1016/J.JASTP.2021.105555
[5]	GUO Zihuai, YAO Yibin, KONG Jian, et al. Accuracy analysis of international reference ionosphere 2016 and NeQuick2 in the Antarctic[J]. Sensors, 2021, 21(4):1551
[6]	BILITZA D, ALTADILL D, TRUHLIK V, et al. International reference ionosphere 2016:from ionospheric climate to real-time weather predictions[J]. Space Weather, 2017, 15(2):418-429
[7]	SUN Fangfang, LUO Jia, XU Xiaohua, et al. Comparisons of ionospheric peak parameters from radio occultation observations and IRI-2016 model outputs over China[J]. Geomat. Inform. Sci. Wuhan Univ., 2020, 45(3):403-410(孙方方, 罗佳, 徐晓华, 等. 中国区域掩星观测与IRI-2016电离层峰值参数的比较[J]. 武汉大学学报:信息科学版, 2020, 45(3):403-410)
[8]	LEI J H, SYNDERGAARD S, BURNS A G, et al. Comparison of COSMIC ionospheric measurements with ground based observations and model predictions:preliminary results[J]. Geophys. Res., 2007, 112(A7):A07308
[9]	LIU J Y, LEE C C, YANG J Y, et al. Electron density profiles in the equatorial ionosphere observed by the FORMOSAT-3/COSMIC and a digisonde at Jicamarca[J]. GPS Solut., 2010, 14(1):75-81
[10]	CHUO Y J, LEE C C, CHEN W S, et al. Comparison between bottomside ionospheric profile parameters retrieved from FORMOSAT3 measurements and ground-based observations collected at Jicamarca[J]. Atmos. Sol. Terr. Phys., 2011, 73(13):1665-1673
[11]	HUANG Zhi, YUAN Hong. An analysis of ionospheric characteristic parameters retrieved from COSMIC and IRI at Jicamarca during the period of 2007-2013[J]. Chin. J. Geophys., 2016, 59(7):2333-2343(黄智, 袁洪. 磁赤道地区2007-2013年COSMIC掩星反演和国际参考电离层模型输出结果分析[J]. 地球物理学报, 2016, 59(7):2333-2343)
[12]	POTULA B S, CHU Y H, UMA G, et al. A global comparative study on the ionospheric measurements between COSMIC radio occultation technique and IRI model[J]. J. Geophys. Res., 2011, 116(A2):A02310
[13]	RAO S S, CHAKRABORTY M, PANDEY R. Ionospheric variations over Chinese EIA region using f₀F₂ and comparison with IRI-2016 model[J]. Adv. Space Res., 2018, 62(1):84-93
[14]	MOSES Mefe, BILITZA Dieter, KUMAR Panda Sampad, et al. Assessment of IRI-2016 H_mF₂ model predictions with COSMIC observations over the African region[J]. Adv. Space Res., 2021, 68(5):2115-2123
[15]	GUO P, XU X, ZHANG G X. Analysis of the ionospheric equivalent slab thickness based on ground-based GPS/TEC and GPS/COSMIC RO measurements[J]. Atmos. Sol. Terr. Phys., 2011, 73(7):839-846
[16]	SUN Xiaoxiao, ZHONG Wenxuan, MA Ping. An asymptotic and empirical smoothing parameters selection method for smoothing spline ANOVA models in large samples[J]. Biometrika, 2021, 1(108):149-166
[17]	CHENG Huhua, ZHAN Caiju, ZHAO Liang, et al. Accuracy analysis of IRI2016 international reference ionosphere at altitude of 60-100km[J]. Acta Geod. Cartograph. Sin., 2020, 49(01):43-57(程胡华, 詹彩菊, 赵亮, 等. IRI2016参考电离层模型在高度60-100km的精度分析[J]. 测绘学报, 2020, 49(01):43-57)
[18]	WANG Ning, GUO Lixin, ZHAO Zhenwei, et al. Analyzing peak height and thickness variation characteristics of ionospheric F-layer in middle and low latitude[J]. Chin. J. Geophys., 2017, 60(4):1268-1275(王宁, 郭立新, 赵振维, 等. 中低纬电离层F层峰高和厚度的变化特征分析[J]. 地球物理学报, 2017, 60(4):1268-1275)
[19]	ZHANG Jing, LIU Jingnan, LI Cong. Research and discussion on the International Reference Ionosphere model[J]. J. Guilin Univ. Technol., 2017, 37(1):114-119
[20]	ALTADILL D, MAGDALENO S, TORTA J M, et al. Global empirical models of the density peak height and of the equivalent scale height for quiet conditions[J]. Adv. Space Res., 2013, 52(10):1756-1769
