行星际磁场对磁尾场向电流发生率的影响

程征伟; 史建魁; 张子迎; 刘振兴

doi:10.11728/cjss2013.04.396

行星际磁场对磁尾场向电流发生率的影响

doi: 10.11728/cjss2013.04.396

中国科学院空间科学与应用研究中心空间天气学国家重点实验室北京 100190

基金项目: 国家自然科学基金项目(41274146, 41074114)和国家重点实验室专项基金共同资助

详细信息

作者简介:
程征伟, zwcheng@spaceweather.ac.cn

中图分类号: P353.2
计量
- 文章访问数: 2249
- HTML全文浏览量: 88
- PDF下载量: 1190
- 被引次数: 0
出版历程
- 收稿日期: 2012-08-29
- 修回日期: 2013-03-04
- 刊出日期: 2013-07-15

Effect of Interplanetary Magnetic Field on the Field-aligned Currents Occurrence in the Magnetotail

State Key Laboratory of Space Weather, Center for Space Science and Applied Research, Chinese Academy of Sciences, Beijing 100190

摘要

摘要: 利用Cluster卫星的磁场和等离子体探测数据, 研究了行星际磁场(IMF)时钟角(clock angle) Φ和锥角(cone angle) θ对磁尾等离子体片边界层(PSBL)区场向电流发生率的影响. 当时钟角Φ >0时, 磁尾场向电流的发生率较高, 这表明磁尾场向电流的发生与昏向太阳风条件更为密切; 当 90°<|Φ|<180°时, 场向电流的发生率较高, 这表明场向电流的发生与南向IMF更为密切. 当锥角θ <30°时(即IMF与日地连线夹角较小时)场向电流的发生率较低. 而当θ> 30°时, 场向电流在90°<|Φ|<180°的情况下发生率明显增大, 这说明南向IMF情况下, 场向电流发生率明显增大. 但是当|Φ|<90°时 (北向IMF情况下), 尽管θ很大, 场向电流的发生率并未明显增大. 当θ>70°时, 且在140°< < i>Φ<160°的行星际磁场条件下, 磁尾等离子体片边界层区场向电流的发生率最大.
- 场向电流 /
- 等离子体片边界层 /
- 行星际磁场 /
- 时钟角 /
- 锥角
Abstract: Using the magnetic field and plasma data from Cluster spacecraft, the effect of Interplanetary Magnetic Field (IMF) clock angle Φ and cone angle θ on the Field-Aligned Currents (FAC) occurrence rate at the Plasma Sheet Boundary layer (PSBL) in the magnetotail is investigated. There were more FAC cases occurred when IMF was within the 0°< Φ< 180° clock angle range comparing with the range of -180°< Φ<0°. It indicated that FAC occurrences were associated with duskward IMF (IMF B_y>0). Also, there were more FAC cases occurred when the IMF was within the 90° < |Φ|< 180° clock angle range. It supported that FAC occurrences were associated with southward IMF (IMF B_z<0). Most of the FAC cases occurred when IMF was within the θ>30° cone angle. In addition, A few of FAC cases occurred when the IMF clock angle was in the θ<30° range regardless of the value of Φ. The occurrence rate of FAC was the largest when θ> 30° and 140°< Φ<160°.
- Field-aligned currents /
- Plasma sheet boundary layers /
- Interplanetary magnetic field /
- Clock angle /
- Cone angle

HTML全文

参考文献(28)

[1]	Zmuda A J, Martin J H, Heuring F T. Transverse magnetic disturbances at 1100 kilometers in the auroral region[J]. J. Geophys. Res., 1966, 66:5033-5045
[2]	Cummings W D, Dessler A J. Field-aligned currents in the magnetosphere[J]. J. Geophys. Res., 1967, 72:1007-1013
[3]	Yamauchi M, Araki T. The interplanetary magnetic field by-dependent field-aligned current in the dayside polar cap under quiet conditions[J]. J. Geophys. Res., 1989, 94:2684-2690
[4]	Zhou X W, Russell C T, Le G. Local time interplanetary magnetic field by dependence of field-aligned currents at high altitudes[J]. J. Geophys. Res., 2000, 105:2533-2539
[5]	Iijima T, Shibaji T. Global characteristics of northward IMF associated (NBZ) field-aligned currents[J]. J. Geophys. Res., 1987, 92:2408-2424
[6]	Erlandson R E, Zanetti L J, Potemra T A, et al. IMF B_y dependence of region 1 Birkeland currents near noon[J]. J. Geophys. Res., 1988, 93:9804-9814
[7]	Weimer D R. Maps of ionospheric field-aligned currents as a function of the interplanetary magnetic field derived from Dynamics Explorer 2 data[J]. J. Geophys. Res., 2001, 106:12889-12902
[8]	Le G, Russell C T, Kuo H. Flux transfer events: Spontaneous or driven[J]. Geophys. Res. Lett., 1993, 20:791-794
[9]	Kullen A, Brittnacher M, Cumnock J A, et al. Solar wind dependence of the occurrence and motion of polar auroral arcs: A statistical study[J]. J. Geophys. Res., 2002, 107(A11), 1362, doi: 10.1029/2002JA009245
[10]	Grocott A, Milan S E, Yeoman T K. Interplanetary magnetic field control of fast azimuthal flows in the nightside high-latitude ionosphere[J]. Geophys. Res. Lett., 2008, 35, L08102, doi: 10.1029/2008GL033545
[11]	Le G, Russell C T. Solar wind control of upstream wave frequency[J]. J. Geophys. Res., 1996, 101:2571-2575
[12]	Chi P J, Russell C T, Bloom R M, et al. Solar wind control of ultralow-frequency wave activity at L=3[J]. J. Geophys. Res., 1998, 103(A12):29467-29477
[13]	Chi P J, Russell C T, Le G. Pc3 and Pc4 activity during a long period of low interplanetary magnetic field cone angle as detected across the Institute of Geological Sciences array[J]. J. Geophys. Res., 1994, 99:11127-11139
[14]	Hu Hongqiao, Liu Ruiyuan, Yang Huigen, et al. Dependence of the postnoon auroral intensity upon the IMF[J]. Chin. J. Geophys., 2002, 45(4):445-452. In Chinese (胡红桥, 刘瑞源, 杨慧根, 等. 午后极光强度与行星际磁场的相关[J]. 地球物理学报, 2002, 45(4):445-452)
[15]	Shi J K, Cheng Z W, Zhang T L, et al. Properties of field-aligned current in plasma sheet boundary layers in magnetotail: Cluster observation[J]. Chin. Phys. Lett., 2009, 26(2):029401
[16]	Cheng Z W, Shi J K, Zhang T L, et al. The relations between density of FACs in the plasma sheet boundary layers and Kp index[J]. Sci. Chin. Tech. Sci., 2011, 54:2987-2992, doi: 10.1007/s11431-011-4545-3
[17]	Cheng Z W, Shi J K, Zhang T L, et al. Field-aligned currents at the PSBL on 17 August 2001 storm: Relationships with solar wind conditions[J]. Chin. Phys. Lett., 2011, 28(9):099401
[18]	Dunlop M W, Balogh A, lassmeier K H. Four-point Cluster application of magnetic field analysis tools: The Curlometer[J]. J. Geophys. Res., 2002, 107(A11):1384-1397
[19]	Robert P, Dunlop M W. Analysis Methods for Multi-Spacecraft Data[M]. Netherlands: ESA Publications Division, 1998. 395-418
[20]	Xiao Chijie, Pu Zuyin, Huang Zongying, et al. Multiple flux rope events at the high latitude magnetopause on January 26, 2001: Current density calculating[J]. Chin. J. Geophys. 2004, 47(4):555-561. In Chinese (肖池阶, 濮祖荫, 黄宗英, 等. 2001年1 月26日磁层顶多重磁通量管事件的观测研究---空间电流密度计算及分析[J]. 地球物理学报, 2004, 47(4):555-561)
[21]	Ohtani S, Kokubun S, Elphic R C, et al. Field-aligned current signatures in the near-tail region 1. ISEE observations in the plasma sheet boundary layer[J]. J. Geophys. Res., 1988, 93:9709-9720
[22]	Shi J K, Cheng Z W, Zhang T L, et al. South-north asymmetry of field-aligned currents in the magnetotail observed by Cluster[J]. J. Geophys. Res., 2010, 115, A07228, doi: 10.1029/2009JA014446
[23]	Ueno G, Ohtani S, Saito Y, et al. Field-aligned currents in the outermost plasma sheet boundary layer with Geotail observation[J]. J. Geophys. Res., 2002, 107:1399-1408
[24]	Jiao Weixin, Pu Zuyin. Dependence of field-aligned currents on the orientation of the interplanetary magnetic field[J]. Chin. J. Space Sci., 2000, 20(2):144-149. In Chinese (焦维新, 濮祖荫. 大尺度场向电流的控制因素[J]. 空间科学学报, 2000, 20(2):144-149)
[25]	Taguchi S. By-controlled field-aligned currents near midnight auroral oval during northward interplanetary magnetic field[J]. J. Geophys. Res., 1992, 97(A8):12231-12243
[26]	Russell C T. The configuration of the magnetosphere[C]//Critical Problems of Magnetospheric Physics. Madrid: IUCSTP, Nat Acad, 1972. 116
[27]	Kaymaz Z, Siscoe G L, Luhmann J G, et al. Interplanetary magnetic field control of magnetotail magnetic field geometry: IMP 8 observations[J]. J. Geophys. Res., 1994, 99: 11113-11126
[28]	Yan G Q, Shen C, Liu Z X, et al. A statistical study on the correlations between plasma sheet and solar wind based on DSP explorations[J]. Ann. Geophys., 2005, 90:2961-2966
