基于全相位FFT的感应式磁力仪频谱校正方法研究

任海燕; 曾立; 刘旭; 魏东; 王艳; 陈昱

doi:10.11728/cjss2016.03.366

基于全相位FFT的感应式磁力仪频谱校正方法研究

doi: 10.11728/cjss2016.03.366

北京航空航天大学宇航学院北京 100191

基金项目: 国家自然科学基金项目(41274190,41104121)和国家重点基础研究发展计划项目共同资助

详细信息

作者简介:
任海燕,E-mail:bhyhxy@sina.com

中图分类号: P351
计量
- 文章访问数: 1026
- HTML全文浏览量: 82
- PDF下载量: 1802
- 被引次数: 0
出版历程
- 收稿日期: 2015-05-26
- 修回日期: 2015-12-18
- 刊出日期: 2016-05-15

Research of Spectrum Correction Method Based on All Phase FFT for Induction Magnetometer

School of Astronautics, Beihang University, Beijing 100191

摘要

摘要: 基于法拉第电磁感应定律的感应式磁力仪是用于测量低频磁场的空间探测仪器,常具有在轨FFT频谱分析功能,直接获得波动磁场的频率及幅度等信息.利用FFT方法对截断信号进行计算时,整周期采样会产生频谱泄露和栅栏效应,频谱信息产生偏差,而影响实时监测磁场变化的准确性.全相位FFT与常规FFT相比,有相位不变性和良好的抑制频谱泄露能力.采用基于全相位FFT的时移相位差方法(apFFT/apFFT)校正在研的某卫星感应式磁力仪直接采集的波形数据.仿真和实验结果表明,apFFT/apFFT方法可有效提高感应式磁力仪低频磁场测量的频谱准确性.研究工作为提高感应式磁力仪科学数据的应用水平奠定了基础,为下一代星载感应式磁力仪在轨频谱分析提供了一种可能的新方法.
- 感应式磁力仪 /
- 谱泄露 /
- 相位FFT /
- apFFT/apFFT
Abstract: Induction magnetometer,based on Faraday's law,is used to measure the magnetic field changes with low frequency in space.It usually has the function of on-orbit FFT spectrum analysis, which can obtain the information of magnetic field fluctuation directly,such as frequency and amplitude.However,when using FFT to process the truncated signal,non-complete period sampling will cause spectrum leakage and fence effect.Namely the spectrum information will generate deviations, which affects the accuracy of real-time monitoring of magnetic field changes.Compared with traditional FFT,the all-phase FFT with phase invariability can effectively prevent spectrum leakage.In this paper,an all-phase time-shift phase difference method (apFFT/apFFT) is used to correct the aveform data of a satellite induction magnetometer.Simulation and experimental results indicate that this method can improve the measurement accuracy.This study also provides a method about on-orbit spectrum analysis for the next generation of spaceborne induction magnetometer.
- Induction magnetometer /
- Spectrum leakage /
- All-phase FFT /
- apFFT/apFFT

HTML全文

参考文献(13)

[1]	CORNILLEAU-WEHRLIN N, CHANTEUR G, PERRAUT S, et al. First results obtained by the Cluster STAFF experiment[J]. Ann. Geophys., 1999, 21(2):437-456
[2]	ELPHIC R C, MEANS J D, SNARE R C, et al. Magnetic field instruments for the fast auroral snapshot explorer[J]. Space Sci. Rev., 2001, 98(1/2):151-168
[3]	CAO J B, LIU Z X, YANG J Y, et al. First results of low frequency electromagnetic wave detector of TC-2/Double Star program[J]. Ann. Geophys., 2005(8):2803-281
[4]	TANG Ji, ZHAO Guoze, CHEN Xiaobin, et al. Introduction of payload for electromagnetic emissions on seismic satellite[J]. Prog. Geophys., 2007(3):679-686(汤吉, 赵国泽, 陈小斌, 等. 地震电磁卫星载荷及现状[J]. 地球物理学进展, 2007(3):679-686)
[5]	ROUX A, LECONTEL O, COILLOT C, et al. The search coil magnetometer for THEMIS[J]. Space Sci. Rev., 2008, 141(1):265-275
[6]	ZHU Xiaoyong, DING Kang. The synthetical comparison of correcting methods on discrete spectrum[J]. Sign. Proc., 2001(1):91-97(朱小勇,丁康. 离散频谱校正方法的综合比较[J]. 信号处理, 2001(1):91-97)
[7]	HUANG X, WANG Z, HOU G. New method of estimation of phase, amplitude, and frequency based on all phase FFT spectrum analysis[C]//IEEE International Symposium on Intelligent Signal Processing and Communication Systems. Xiamen:IEEE, 2007:284-287
[8]	HUANG Xiangdong, WANG Zhaohua, LUO Peng, LÜ Wei. Discrimination and correction for dense all-phase FFT spectrums[J]. Acta Electron. Sin., 2011(1):172-177(黄翔东, 王兆华, 罗蓬, 吕卫. 全相位FFT密集谱识别与校正[J]. 电子学报, 2011(1):172-177)
[9]	BYKOV M M, TYURIN V S, TYURIN S V. Signals mode-ling in laser distance measurements[C]//8th International Conference on Laser and Fiber-Optical Net-works Modeling. Kharkiv, Ukraine:IEEE, 2006
[10]	WU S C, MELBOURNE W G. An optimal GPS data processing technique for precise positioning[J]. IEEE Trans. Geosci. Remote Sens., 1993, 31(1):146-152
[11]	CAO Hao, LIU Dejun, FENG Ye, et al. Application of the all-phase time-shift phase difference method in the power harmonic detection[J]. Electr. Meas. Instrum., 2012, 49(7):24-28(曹浩, 刘得军, 冯叶, 等. 全相位时移相位差法在电力谐波检测中的应用[J]. 电测与仪表, 2012, 49(7):24-28)
[12]	HUANG Xiangdong, WANG Zhaohua. All-phase time-shift phase difference correcting spectrum method[J]. J. Tianjin Univ., 2008(7):815-820(黄翔东,王兆华. 全相位时移相位差频谱校正法[J]. 天津大学学报, 2008(7):815-820)
[13]	HUANG Xiangdong. All-phase Digital Signal Processing[D]. Tianjin:Tianjin University, 2007:70-73(黄翔东. 全相位数字信号处理[D]. 天津:天津大学, 2007:70-73)
